3.1. Menu

10
Item
Port No.
Baudrate
After setting, click 'Connect' button, and the drive module will try to connect 16 drives from 0 to 15
(firmware of same level version) at the setting speed through a pertinent communication port.
Attention
3.

Main Window

This is the basic window to operate the program. Each window is displayed in this window. The user
can open each window with a toolbar.
3.1
Menu
There are 'View' menu to display other windows simply and 'File' menu which the user can connect
and disconnect communication.
To assign the port number of RS-232 or USB which is connected with drive
module at the PC .
This should correspond to the setting which sets the controller communication
speed.
(Drive : adjusted to 115200[bps] at the
 The communication speed of drive modules connected with one
network must be set to the same value.
 When they are not connected, the user needs to check the port or
the baudrate.
Description
factory).
