Level Zero Point Calibration

Before auto-leveling features are available, the Level Zero Point must be set. This is the point to which the system
will return when an auto leveling cycle is initiated.
To set the Zero Point (controller module must be fully secured in production-intent location), first run a manual
leveling sequence to get the vehicle to the desired level point. Then activate the Level Zero Point configuration
mode.
This mode is enabled by performing the following sequence:
1. Turn panel off.
2.
Perform the following:
3.
Press the "FRONT" button (Fig. 5H) 5 times.
4. Press the "REAR" button (Fig. 5I) 5 times.
5.
At this point, an alarm will sound and the display will read "**ZERO POINT CALIBRATION**" ENTER to
Set, POWER to Exit."
6. Press ENTER (Fig. 5C) to set the Zero Point.
7.
Screen will then display "PLEASE WAIT".
8.
Alarm will sound and the screen will display "ZERO POINT SUCCESSFUL".
9. Control will then turn "OFF".
For DIESEL UNITS with Air Bag Suspensions ONLY:
NOTE: The leveling control will automatically program for air bag control. The option will not be present if
no dump valve coil resistance is detected.
