Controls - Lippert Level-Up Owner's Manual

Controls

Callout
A
B
C
D
E
F
G
H
I
J
K
Rev: 06.29.2022
A
E
B
C
F
D
Description
Up Arrow - Scrolls up through the menu on LCD.
Down Arrow - Scrolls down through the menu on LCD.
Enter - Activates modes and procedures indicated on LCD.
Retract - Places leveling system into retract mode. - Manual mode ONLY
LCD Display - Displays procedures and results.
Auto Level - Places leveling system into auto level mode.
Front Jack Button - Activates both front jacks in manual mode.
Left Jack Button - Activates both left jacks in manual mode.
Right Jack Button - Activates both right jacks in manual mode.
Rear Jack Button - Activates both rear jacks in manual mode.
Power Button - Turns leveling system on and off.
Fig. 5
K
H
G
Page 7
J
i
CCD-0001536
