MT-6210W
Mobile Terminal System
User Manual
MT-6210W is required to be charged over 8
hours when used for the first time.
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user
must follow the specific operating instructions for satisfying RF exposure compliance.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause
radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet équipement
peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized
technicians. The user should consult his/her dealer for the problem happening. Warranty voids if the user does
not follow the instructions in application of this merchandise. The manufacturer is by no means responsible for
any damage or hazard caused by improper application.
Package Contents
MT-6210W (x 1)
45W power adaptor (x 1)
Protection case with rotatable hand strap, shoulder
strap and stylus (for option, x 1)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-6200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX MT-6200

  • Page 1 MT-6210W Mobile Terminal System User Manual Package Contents  MT-6210W (x 1)  45W power adaptor (x 1)  Protection case with rotatable hand strap, shoulder strap and stylus (for option, x 1) MT-6210W is required to be charged over 8 hours when used for the first time.
  • Page 2 LIMITES DE GARANTIE La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé...
  • Page 3: Revision History

    Revision History Date Version Description 2024/06/05 For Preliminary Release 2024/07/16 Add installation guide of replacing battery 2024/08/06 Add charging time in spec. table...
  • Page 4 Views of MT-6210W Front View Front Camera LED Indicator Window Function Key Function Key for Home Page for Program Menu Projected Capacitive Touch Screen Rear View Rear Camera NFC Icon Window (Optional) Expansion Slot for Optional Attachment Speaker Bottom Side View Type-C Connector Top Side View Scanner Window (Optional)
  • Page 5: Charging The Battery

    Left Side View Power Button Volume Adjustment Button “+” Volume Adjustment Button “-“ Mic-in/Line-out Micro SD Combo Jack Card Slot Charging the Battery Below are some cautionary advices you need to keep in mind while you attempt to charge the battery. MT-6210W is required to be charged over 8 hours when used for the first time.
  • Page 6: Status Led Indicator

    Status LED Indicator LED indicator is specially designed to deliver special message regarding the current system status and battery life. The blow chart enumerates all the possible LED indicators and its meaning for your reference. LED Status System Status Descriptions ■...
  • Page 7 To do the further setting of the scanner engine, please find the relevant user manual on Posiflex Global Website, (https://www.posiflex.com/document/user- manual/?pmid=94,110&pid=1055 ) or contact the service team for technical support. Operating the Rotatable Hand Strap (Optional, bundled with Protection Case) Install the protection case.
  • Page 8 Installation completed. Replacing the Battery of MT-6210W Remove 4 sponges on the rear cover by a pair of tweezers. Remove 12 screws on the rear cover.
  • Page 9 Remove the 2 screws on the rear cover and then disassemble the rear cover. Disconnect all the cables which connected to the main board. Please note that there will be a latch on the cable connector of main board.
  • Page 10 Lift the latch on the cable connector of main board to disconnect the cable. Latch Disconnect Disconnect. Latch...
  • Page 11 Carefully peel the NFC antenna (if there is.) away from the battery. There is a double-sided tape on each corner of the battery. Pull the four tapes outwards to remove the tapes. Remove the original battery.
  • Page 12 Tear off the four pieces of double-sided tape. 10. Install the new battery into the tablet. 11. Attach the NFC antenna (if there is.) to the top of the battery, and then connect the relevant cables to the main board. In the end, use anti-static tape to secure the cables.
  • Page 13 Connect. Connect. Connect.
  • Page 14 12. Fix the rear cover with 2 screws and then fix the attachment cover with the other two screws. 13. Fix the rear cover with 10 screws. 14. Tuck the 4 sponges into the four screw holes on the rear cover.
  • Page 15: Installing An Operating System

    Please be advised to contact your service center for further assistance with system recovery. Installing Optional Upgrade Kits Posiflex MT-6210W can work with multiple optional upgrade kits, such as MSR, Smart Card Reader and the like. For the detailed instructions, refer to the user manual related to each peripheral devices.
  • Page 16 MT-6210W OS Support OS Support Windows 10 IoT / Windows 11 IoT Display & Monitor Display 10.1” TFT LCD with LED backlight, 1280 x 800 Touch Screen P-CAP touch with multi-touch support Expansion Wireless connectivity WiFi IEEE 802.11a/b/g/n/ac/ax (WiFi6) + BT 5.2 Power Power adapter: 45W (Type-C connector) Power Supply...
  • Page 17: Outline Dimension

    Outline Dimension ※ The product information and specifications are subject to change without prior notice.
