TO PREVENT POSSIBLE TIPPING, BOLT THIS UNIT TO THE
EXERCISE FLOOR USING MINIMUM 4 - 1/2" LONG BOLTS. FAILURE TO
DO SO MAY RESULT IN SERIOUS INJURY OR DEATH.
Note: Both Serial Number and Model Number are Required when Ordering Parts
RECORD SERIAL NUMBER HERE
MACHINE CODE
A03
RS-2700
CHIN-DIP ASSIST
**WARNING!**
Customer Service
(800) 548-5438
(858) 578-7676
Fax
(858) 578-9558
