Specifications
Specifications are for CUSTOMPRO-HUB modular chassis only
Audio Input Connections:
8x 3.5mm stereo jack
RS-232 serial port:
1x DB-9, female, 8x 3 pin Phoenix
TCP/IP Control:
1x RJ45, female
Rack-Mountable:
2U rack height, rack ears included
Casing Dimensions (W x H x D):
Dimensions (W x D x H):
440mm x 291mm x 94mm, with feet
Shipping Weight:
5.5kg
Operating Temperature:
32°F to 104°F (0°C to 40°C)
Storage Temperature:
-4°F to 140°F (-20°C to 60°C)
Power Supply:
1x 24V/8A DC
Package Contents
• 1 x CUSTOMPRO-HUB
• 1 x Rack mounting kit
• 1 x 24V/8A power supply
• 1 x Remote control
• 1 x Quick reference guide
Note: PRO Matrix input/output cards are sold separately
Pro Matrix Solution Modular options
Custom Pro Chassis
CUSTOMPRO-HUB
Custom Pro Matrix Hub
Custom Pro Feature Boards
PRO-8IR
8-Way IR Control Board
PRO-8RS232
8-Way RS-232 Control Board
PRO-8AB
8-Way Audio Breakout Board
PRO-8ABV
8-Way Audio Breakout Board with Volume Control
Custom Pro Video Input Boards
PRO-IN2H
2 Input HDMI Board
PRO-IN4H
4 Input HDMI Board
PRO-IN2H2V
4 Input HDMI 2.0 & VGA Board
PRO-IN2HAB
2 Input HDMI Board with Audio Breakout
PRO-IN4HAB
4 Input HDMI Board with Audio Breakout
For the full Blustream ProMatrix User Manual please visit the download area of our website www.blustream.co.uk
04
440mm x 283mm x 87mm, without feet
Custom Pro Video Output Boards
PRO-OUT2H
2 Output HDMI Board
PRO-OUT4H
4 Output HDMI Board
PRO-OUT2TL
2 Output HDBaseT™ Lite Board (70m)
PRO-OUT4TL
4 Output HDBaseT™ Lite Board (70m)
PRO-OUT4TLS
4 Output HDBaseT™ Lite / HDMI Board (70m)
PRO-OUT2H-V2
2 Output HDMI 2.0 Board
PRO-OUT4H-V2
4 Output HDMI 2.0 Board
PRO-OUT2TL-V2
2 Output HDBaseT™ Lite CSC Board (70m)
PRO-OUT4TL-V2
4 Output HDBaseT™ Lite CSC Board (70m)
PRO-OUT4TLS-V2
4 Output Dual HDMI 2.0/HDBaseT™ Lite CSC Board (70m)
PRO-OUT2TCS
2 Output HDBaseT™ CSC Board (100m)
PRO-OUT4TCS
4 Output HDBaseT™ CSC Board (100m)
PRO-OUT4HTCS
4 Output Dual HDMI 2.0/HDBaseT™ CSC Board (100m)
PRO MATRIX
QUICK REFERENCE GUIDE
www.blustream.co.uk
RevA1_QRG_ProMatrix_1130
