Introduction
Our Contractor CMX88AB 4K HDMI Matrix offers unprecedented performance and value for the custom
installation market. The CMX88AB supports HDMI2.0 with HDCP2.2, allowing distribution of eight HDMI
sources to eight displays. This enables all sources to be viewed as required within a matrix configuration. The
unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 8-Way matrix also includes audio
breakout, EDID management and a web browser interface module for control and configuration of the matrix.
Key Features:
• Features 8x HDMI inputs which can be independently routed to 8x HDMI outputs
• Supports 4K UHD video including HDR (up to 4K @60Hz 4:4:4)
• Independent video down conversion on all HDMI outputs allowing a display only capable of supporting
lower 4K video resolutions (4K 60Hz 4:2:0) to receive 4K 60Hz 4:4:4 video content while still showing
maximum original 4K UHD resolution on remaining outputs
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
• Web interface module for control and configuration of the Matrix
• Control via front panel, IR, RS-232 & TCP/IP
• 3rd party drivers available for all major home control brands
• Advanced EDID management
• HDCP 2.2 compliant
01
CMX88AB
Quick Reference Guide
CMX88AB
QUICK REFERENCE GUIDE
www.blustream.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BluStream Contractor CMX88AB
Summary of Contents for BluStream Contractor CMX88AB
- Page 1 Quick Reference Guide Introduction Our Contractor CMX88AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market. The CMX88AB supports HDMI2.0 with HDCP2.2, allowing distribution of eight HDMI sources to eight displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4.
-
Page 2: Panel Description
The Matrix does not down-mix multi-channel audio signals. IR control - IR input for Martrix control. Connect 5V TCP/IP connection - Connect to local network. Default Blustream IR receiver. network setting is DHCP. Power port - Use included 12V/3A DC power adaptor Note: If Matrix is not connected to a router the default IP address is 192.168.0.200... -
Page 3: Rs-232 Control Port
CMX88AB QUICK REFERENCE GUIDE RS-232 Control Port The Matrix can be controlled via 9-pin serial RS-232 cable. RS-232 COMMAND DESCRIPTION BLUSTREAM RS-232 REMOTE CONTROL CONSOLE Print Help Information Assignment Assignment Print Help Information HELP STATUS Print System Status And Port Status... -
Page 4: Specifications
• 1x 12V/3A DC power supply • 1x Remote control • 1x IR receiver • 1x 1x IR control cable - 3.5mm to 3.5mm cable • 1x Mounting kit • 1x Quick reference guide contact support@blustream.co.uk / support@blustream.com.au RevA2_QRG_CMX88AB_190123_Web Layout... - Page 5 To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmentally safe recycling. www.blustream.co.uk...
-
Page 6: Installer Notes
CMX88AB QUICK REFERENCE GUIDE Installer Notes contact support@blustream.co.uk / support@blustream.com.au... - Page 7 CMX88AB QUICK REFERENCE GUIDE Installer Notes www.blustream.co.uk...
- Page 8 www.blustream.co.uk...
