IEI Technology DM-F19A/PC-R31 User Manual

8" ~ 23.8" lcd monitor displayport, hdmi, vga, ip 65 protection, rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DM-F Series Monitor
DM Series Industrial Monitor
MODEL:
DM-F Series
8" ~ 23.8" LCD Monitor
DisplayPort, HDMI, VGA, IP 65 Protection, RoHS
User Manual
Page I
Rev. 2.10 – January 31, 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-F19A/PC-R31 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology DM-F19A/PC-R31

Summary of Contents for IEI Technology DM-F19A/PC-R31

  • Page 1 DM-F Series Monitor DM Series Industrial Monitor MODEL: DM-F Series 8" ~ 23.8" LCD Monitor DisplayPort, HDMI, VGA, IP 65 Protection, RoHS User Manual Page I Rev. 2.10 – January 31, 2024...
  • Page 2 DM-F Series Monitor Revision Date Version Changes January 31, 2024 2.10 Updated DM-F08's power connector spec. Updated Appendix C.2: smart OSD Pre-installation Notice May 7, 2021 2.01 Updated Chapter 4: On-Screen-Display (OSD) Controls Updated Chapter 6: AD Boards Updated Section 2.3: Optional Items Modified the max.
  • Page 3 DM-F Series Monitor Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 DM-F Series Monitor Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 DM-F Series Monitor Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6 DM-F Series Monitor Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 7: Table Of Contents

    DM-F Series Monitor Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 M ....................3 ODEL ARIATIONS 1.4 A ......................3 PPLICATIONS 1.5 F ......................4 RONT 1.6 R ........................ 5 1.7 C ......................
  • Page 8 DM-F Series Monitor 3.1 I ................... 26 NSTALLATION RECAUTIONS 3.2 E ............27 XTERNAL ERIPHERAL EVICE ONNECTION 3.2.1 DC- ....................... 27 3.2.2 9 V–36 V T ) ............27 ERMINAL LOCK PTIONAL 3.2.3 USB ..............28 OUCH ANEL ONNECTOR 3.2.4 VGA C ....................
  • Page 9 DM-F Series Monitor 5.5 C ................70 ALIBRATING THE OUCHSCREEN 6 AD BOARDS ........................ 73 6.1 AD B ..................... 74 OARD VERVIEW 6.2 AV-2525 AD B ....................74 OARD 6.2.1 AV-2525 P ..........75 ERIPHERAL NTERFACE ONNECTORS 6.2.2 B (INVERTER1)..........76 ACKLIGHT NVERTER ONNECTOR...
  • Page 10 DM-F Series Monitor List of Figures Figure 1-1: DM-F Series ......................... 2 Figure 1-2: Typical Monitor Front View ..................4 Figure 1-3: DM-F08A Rear View ....................5 Figure 1-4: DM-F12A/15A/W15A/17A/19A/W19A/22A/24A Rear View ........5 Figure 1-5: Bottom Panel Connectors (DM-F08A) ............... 6 Figure 1-6: Side Panel Connectors (DM-F08A) ................
  • Page 11 DM-F Series Monitor Figure 3-13: Mounting Clamps Holder ..................35 Figure 3-14: Mounting Clamps ....................35 Figure 3-15: DM-F08A Cutout Dimensions (Unit: mm) .............36 Figure 3-16: DM-F12A Cutout Dimensions (Unit: mm) .............36 Figure 3-17: DM-F15A Cutout Dimensions (Unit: mm) .............36 Figure 3-18: DM-FW15A Cutout Dimensions (Unit: mm) ............37 Figure 3-19: DM-F17A Cutout Dimensions (Unit: mm) .............37 Figure 3-20: DM-F19A Cutout Dimensions (Unit: mm) .............37 Figure 3-21: DM-FW19A Cutout Dimensions (Unit: mm) ............38...
  • Page 12 DM-F Series Monitor Figure 4-4: Display Menu ......................58 Figure 4-5: Color Menu ........................59 Figure 4-6: Input Menu .........................60 Figure 4-7: Other Menu ........................61 Figure 4-8: Information Menu ......................62 Figure 5-1: Welcome Screen .......................67 Figure 5-2: License Agreement ....................68 Figure 5-3: Initiate Install ......................68 Figure 5-4: Installation Starts ......................69 Figure 5-5: Finish Installation ......................69 Figure 5-6: PenMount Monitor Icon ....................70...
  • Page 13 DM-F Series Monitor List of Tables Table 1-1: DM-F Series Model Variations ..................3 Table 1-2: DM-F08A ~ DM-F(W)15A Specifications ..............9 Table 1-3: DM-F17A ~ DM-F24A Specifications .................11 Table 2-1: Packing List .........................23 Table 3-1: USB Touch Panel Connector Pinouts ..............28 Table 3-2: VGA Connector Pinouts .....................28 Table 3-3: DVI-D Connector Pinouts ...................29 Table 3-4: DisplayPort Connector Pinouts ................30...
  • Page 14 DM-F Series Monitor Table 6-18: Touchscreen Connector (J1) Pinouts ..............83 Table 6-19: VGA Connector (VGA2) Pinouts ................83 Table C-1: SmartOSD Menu Structure ..................98 Page XIV...

  • Page 15: Introduction

    DM-F Series Monitor Chapter Introduction Page 1...

  • Page 16: Overview

    DM-F Series Monitor 1.1 Overview Figure 1-1: DM-F Series The DM-F series LCD monitor is the latest member of IEI’s line of sophisticated LCD designs with flat bezel. It is designed to fit industrial automation, or any other applications that require minimum installation space and flexible configuration. The flat front panel provides IP 65 protection, which effectively wards off dust and water.

  • Page 17: Model Variations

    DM-F Series Monitor 1.3 Model Variations The DM-F series LCD monitor base models have a variety of variants. The model variations are listed in Table 1-1. 4 91H Model Number Touchscreen Power HDMI/DVI DisplayPort DM-F08A/R 8" Resistive 12 V DVI-D DM-F12A/R Resistive 9~36 V...

  • Page 18: Front View

    DM-F Series Monitor Factory automation HMI terminal Shop-floor/MES control  Self-service kiosk Full-service receptionist kiosk Hospital self-registration terminal Interactive photo kiosk Video rental kiosk Self-service POS terminal 1.5 Front View The front of the DM-F series LCD monitor is a flat panel LCD screen surrounded by an aluminum frame.

  • Page 19: Rear View

    DM-F Series Monitor 1.6 Rear View The rear panel provides access to retention screw holes that support VESA mounting. A 5-key/7-key membrane OSD keypad is also located on the rear panel. The following diagrams show the rear panel of the DM-F series. Figure 1-3: DM-F08A Rear View Figure 1-4: DM-F12A/15A/W15A/17A/19A/W19A/22A/24A Rear View Page 5...

  • Page 20: Connectors

    DM-F Series Monitor 1.7 Connectors The following sections show the I/O interfaces of the DM-F series LCD monitor. All connectors are fully described in Section 3.2. 49 5H 1.7.1 DM-F08A Connectors Figure 1-5: Bottom Panel Connectors (DM-F08A) Figure 1-6: Side Panel Connectors (DM-F08A) Page 6...

  • Page 21: Dm-F12A ~ Dm-F19A Connectors

    DM-F Series Monitor 1.7.2 DM-F12A ~ DM-F19A Connectors Figure 1-7: Bottom Panel Connectors (DM-F12A/15A/W15A/17A/19A/W19A) Figure 1-8: Side Panel Connector (DM-F12A/15A/17A/19A) 1.7.3 DM-F22A and DM-F24A Connectors Figure 1-9: Bottom Panel Connectors (DM-F22A/24A) Page 7...

  • Page 22: Technical Specifications

    DM-F Series Monitor 1.8 Technical Specifications The following tables show the DM-F series technical specifications. 1.8.1 DM-F08A ~ DM-F(W)15A Specifications Model DM-F08A DM-F12A DM-F15A DM-FW15A LCD Display 8" (4:3) 12.1" (4:3) 15" (4:3) 15.6" (16:9) Max. Resolution 800x600 1024 x768 1024 x768 1366x768 Brightness...

  • Page 23: Table 1-2: Dm-F08A ~ Dm-F(W)15A Specifications

    DM-F Series Monitor Model DM-F08A DM-F12A DM-F15A DM-FW15A VESA Mount Optional Wall Wall Wall Wall Mounting Kit Rack Rack Rack Rack Panel Panel Panel Panel Stand Stand Stand Stand Operating Temp. -20°C ~ 60°C (with air flow) Storage Temp. -20°C ~ 70°C Humidity 10% ~ 95% (non-condensing) I/O Ports...

  • Page 24: Dm-F17A ~ Dm-F24A Specifications

    DM-F Series Monitor 1.8.1 DM-F17A ~ DM-F24A Specifications Model DM-F17A DM-FW19A DM-F19A DM-F22A DM-F24A LCD Display 17" (5:4) 18.5" (16:9) 19" (5:4) 21.5" (16:9) 23.8" (16:9) Max. Resolution 1280x1024 1366x768 1280x1024 1920x1080 1920x1080 Brightness (cd/m²) Contrast Ratio 1000:1 1000:1 1000:1 1000:1 3000:1 LCD Color...

  • Page 25: Table 1-3: Dm-F17A ~ Dm-F24A Specifications

    DM-F Series Monitor Model DM-F17A DM-FW19A DM-F19A DM-F22A DM-F24A Storage Temp. -20°C ~ 70°C -20°C ~ 60°C Humidity 10% ~ 95% (non-condensing) I/O Ports 1 x VGA 1 x VGA 1 x VGA 1 x VGA 1 x HDMI 1 x HDMI 1 x DP 1.1 1 x HDMI 1 x DP 1.1...

  • Page 26: Physical Dimensions

    DM-F Series Monitor 1.9 Physical Dimensions The following sections describe the physical dimensions for each model of the DM-F series LCD monitor. 1.9.1 DM-F08A Physical Dimensions The physical dimensions of the DM-F08A are shown in Figure 1-11. 507H Figure 1-10: DM-F08A Physical Dimensions (Unit: mm) Page 12...

  • Page 27: Dm-F12A Physical Dimensions

    DM-F Series Monitor 1.9.2 DM-F12A Physical Dimensions The physical dimensions of the DM-F12A are shown in Figure 1-11. 507H Figure 1-11: DM-F12A Physical Dimensions (Unit: mm) Page 13...

  • Page 28: Dm-F15A Physical Dimensions

    DM-F Series Monitor 1.9.3 DM-F15A Physical Dimensions The physical dimensions of the DM-F15A are shown in Figure 1-12. 507H Figure 1-12: DM-F15A Physical Dimensions (Unit: mm) Page 14...

  • Page 29: Dm-Fw15A Physical Dimensions

    DM-F Series Monitor 1.9.4 DM-FW15A Physical Dimensions The physical dimensions of the DM-FW15A are shown in Figure 1-12. 5 07H Figure 1-13: DM-FW15A Physical Dimensions (Unit: mm) Page 15...

  • Page 30: Dm-F17A Physical Dimensions

    DM-F Series Monitor 1.9.5 DM-F17A Physical Dimensions The physical dimensions of the DM-F17A are shown in Figure 1-14. 507H Figure 1-14: DM-F17A Physical Dimensions (Unit: mm) Page 16...

  • Page 31: Dm-F19A Physical Dimensions

    DM-F Series Monitor 1.9.6 DM-F19A Physical Dimensions The physical dimensions of the DM-F19A are shown in Figure 1-11. 507H Figure 1-15: DM-F19A Physical Dimensions (Unit: mm) Page 17...

  • Page 32: Dm-Fw19A Physical Dimensions

    DM-F Series Monitor 1.9.7 DM-FW19A Physical Dimensions The physical dimensions of the DM-FW19A are shown in Figure 1-11. 5 07H Figure 1-16: DM-FW19A Physical Dimensions (Unit: mm) Page 18...

  • Page 33: Dm-F22A Physical Dimensions

    DM-F Series Monitor 1.9.8 DM-F22A Physical Dimensions The physical dimensions of the DM-F22A are shown in Figure 1-17. 507H Figure 1-17: DM-F22A Physical Dimensions (Unit: mm) Page 19...

  • Page 34: Dm-F24A Physical Dimensions

    DM-F Series Monitor 1.9.9 DM-F24A Physical Dimensions The physical dimensions of the DM-F24A are shown in Figure 1-18. 507H Figure 1-18: DM-F24A Physical Dimensions (Unit: mm) Page 20...

  • Page 35: Unpacking

    DM-F Series Monitor Chapter Unpacking Page 21...

  • Page 36: Unpacking Procedure

    DM-F Series Monitor 2.1 Unpacking Procedure To unpack the DM-F series LCD monitor, follow the steps below: WARNING: The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the DM-F series LCD monitor has been properly installed.

  • Page 37: Packing List

    DM-F Series Monitor 2.2 Packing List The DM-F series monitor is shipped with the following components: Quantity Item Image DM-F series USB cable (for touchscreen) VGA cable Touch pen (resistive touch only) 36W 12V DC adapter with lockable connector (6.5" and 8" models only) Table 2-1: Packing List If any of the above items are missing or damaged, contact the distributor or sales representative immediately.

  • Page 38: Optional Items

    DM-F Series Monitor 2.3 Optional Items The following items are optional accessories for the DM-F series monitor: DM-F08A DM-F12A DM-F15A DM-FW15A DM-F17A ARM-11-RS ARM-11-RS ARM-31-RS ARM-31-RS ARM-31-RS STAND-C19-R10 STAND-C19-R10 STAND-C19-R10 Stand STAND-B08 STAND-C12-R10 STAND-A21-R10 STAND-A21-R10 STAND-A21-R10 Wall Mount Kit AFLWK-12 WK-190MS-R10 WK-190MS-R10 WK-190MS-R10...

  • Page 39: Installation

    DM-F Series Monitor Chapter Installation Page 25...

  • Page 40: Installation Precautions

    DM-F Series Monitor 3.1 Installation Precautions CAUTION: Some SKUs of the DM-F series have more than one power supply connection point. To reduce the risk of electric shock, disconnect all power sources before installing or servicing the DM-F series. When installing the DM-F series LCD monitor, please follow the precautions listed below: Read the user manual: The user manual provides a complete description of the ...

  • Page 41: External Peripheral Device Connection

    DM-F Series Monitor avoid electrocution and static discharge to the AD board. The use of a grounded wrist strap and an anti-static work pad is recommended. 3.2 External Peripheral Device Connection The external I/O connector pinouts of the DM-F series industrial monitors are described in the following sections.

  • Page 42: Usb For Touch Panel Connector

    DM-F Series Monitor 3.2.3 USB for Touch Panel Connector Use the rear panel standard USB touch panel connector to connect the monitor to the system graphics interface. DESCRIPTION DESCRIPTION USB20_N11 USB20_P11 Table 3-1: USB Touch Panel Connector Pinouts Figure 3-3: USB Touch Panel Connector 3.2.4 VGA Connector Use the rear panel standard 15-pin female VGA connector to connect the monitor to the system graphics interface.

  • Page 43: Dvi-D Connector (F08A And F19A Only)

    DM-F Series Monitor 3.2.5 DVI-D Connector (F08A and F19A Only) The 24-pin Digital Visual Interface (DVI) connector connects to high-speed, high-resolution digital displays. The DVI-D connector supports only digital signals. DESCRIPTION DESCRIPTION TMDS Data2- TMDS Data2+ PVDD1 TMDS Data0- DDC Clock [SCL] TMDS Data0+ DDC Data [SDA] Analog vertical sync...

  • Page 44: Displayport Connector (F12A ~ F24A Only)

    DM-F Series Monitor 3.2.6 DisplayPort Connector (F12A ~ F24A Only) The DisplayPort connector transmits a digital signal to compatible DisplayPort display devices such as a TV or computer screen. DESCRIPTION DESCRIPTION ML_L3N ML_L3P ML_L2N ML_L2P ML_L1N ML_L1P ML_L0N ML_L0P C_DDI0_DP_AUXP C_DDI0_DP_AUXN C_DDI0_DP_HPD Table 3-4: DisplayPort Connector Pinouts...

  • Page 45: Hdmi Connector (F12A, F(W)15A, F17A, Fw19A, F22A, F24A Only)

    DM-F Series Monitor 3.2.7 HDMI Connector (F12A, F(W)15A, F17A, FW19A, F22A, F24A Only) The HDMI connector connects to a display device with HDMI interface. DESCRIPTION DESCRIPTION HDMI_TMDS_C_DATA2 HDMI_TMDS_C_DATA2# HDMI_TMDS_C_DATA1 HDMI_TMDS_C_DATA1# HDMI_TMDS_C_DATA0 HDMI_TMDS_C_DATA0# HDMI_TMDS_C_CLK HDMI_TMDS_C_CLK# HDMI_DDC_SCLK HDMI_DDC_SDATA +5V_HDMI HDMI_HPD Table 3-5: HDMI Connector Pinouts Figure 3-7: HDMI Connector 3.2.8 RS-232 Port for Touch Panel (Reserved for Resistive Touch) Use the side panel standard RS-232 DB-9 female touch panel connector to connect the...

  • Page 46: Installing Rs-232 Connector

    DM-F Series Monitor Figure 3-8: RS-232 Touch Panel Connector 3.2.8.1 Installing RS-232 Connector If the DM-F series doesn’t have the RS-232 connector on the side panel, the user can purchase the RS-232 Touch Cable Kit (DM-F-COMKIT-R10 or DM-F-COMKIT01-R10) and install the RS-232 connector onto the system. Please note that the RS-232 port is only available for the resistive type models of the 6.5"–19"...

  • Page 47: Figure 3-10: Rear Panel Retention Screw Removal (Dm-F12A ~ Dm-F24A)

    DM-F Series Monitor Figure 3-10: Rear Panel Retention Screw Removal (DM-F12A ~ DM-F24A) Step 2: Remove the RS-232 knockout hole on the side panel. Step 3: Connect the RS-232 flat cable to the internal RS-232 connector (1x9 pin, RS232_1) on the AD board. See Figure 3-11. Figure 3-11: Connecting RS-232 Cable Step 4: Insert the D-sub 9 connector of the RS-232 flat cable into the hole and secure...

  • Page 48: Mounting The Monitor

    DM-F Series Monitor Figure 3-12: Hex Jack Screws for Securing RS-232 Connector Step 5: Re-install the rear panel. 3.3 Mounting the Monitor The DM-F series LCD monitor can be mounted in a panel, cabinet, rack or wall. The monitor can also be mounted on a monitor arm or stand. The mounting methods are described below.

  • Page 49: Figure 3-13: Mounting Clamps Holder

    DM-F Series Monitor DM-F19A/FW19A DM-F22A DM-F24A Table 3-7: Panel Mounting Clamps Figure 3-13: Mounting Clamps Holder Figure 3-14: Mounting Clamps To mount the DM-F series LCD monitor into a panel, please follow the steps below. Step 1: Select the position on the panel to mount the monitor. Step 2: Cut out a section of the panel that corresponds to the rear panel dimensions of the monitor.

  • Page 50: Figure 3-15: Dm-F08A Cutout Dimensions (Unit: Mm)

    DM-F Series Monitor Figure 3-15: DM-F08A Cutout Dimensions (Unit: mm) Figure 3-16: DM-F12A Cutout Dimensions (Unit: mm) Figure 3-17: DM-F15A Cutout Dimensions (Unit: mm) Page 36...

  • Page 51: Figure 3-18: Dm-Fw15A Cutout Dimensions (Unit: Mm)

    DM-F Series Monitor Figure 3-18: DM-FW15A Cutout Dimensions (Unit: mm) Figure 3-19: DM-F17A Cutout Dimensions (Unit: mm) Figure 3-20: DM-F19A Cutout Dimensions (Unit: mm) Page 37...

  • Page 52: Figure 3-21: Dm-Fw19A Cutout Dimensions (Unit: Mm)

    DM-F Series Monitor Figure 3-21: DM-FW19A Cutout Dimensions (Unit: mm) Figure 3-22: DM-F22A Cutout Dimensions (Unit: mm) Figure 3-23: DM-F24A Cutout Dimensions (Unit: mm) Step 3: Secure the mounting clamps holders to the corresponding holes on the rear of the monitor (Figure 3-24). Page 38...

  • Page 53: Figure 3-24: Secure The Mounting Clamp Holders

    DM-F Series Monitor NOTE: It is not required to install the clamp holders to the DM-F08A monitors for panel/rack mounting. After sliding the monitor through the panel, simply insert the panel mounting clamps into the pre-formed holes along the top and side panels of the monitors.

  • Page 54: Figure 3-25: Slide Into The Panel

    DM-F Series Monitor Figure 3-25: Slide into the Panel Step 5: Insert the panel mounting clamps into the pre-formed holes of the clamp holders (Figure 3-26). Step 6: Tighten the screws that pass through the panel mounting clamps until the plastic caps at the front of all the screws are firmly secured to the panel (Figure 3-26).

  • Page 55: Figure 3-27: Mounting Clamps Holder Dimensions

    DM-F Series Monitor The dimensions of the clamp holder and the clamp are shown in the following diagrams. Figure 3-27: Mounting Clamps Holder Dimensions Figure 3-28: Ultra Set Plate Dimensions Page 41...

  • Page 56: Cabinet And Rack Installation (For F08A ~ F17A & Fw19A)

    DM-F Series Monitor Figure 3-29: Bolt Dimensions Figure 3-30: Steering Button Dimensions 3.3.2 Cabinet and Rack Installation (for F08A ~ F17A & FW19A) NOTE: When purchasing a cabinet/rack installation bracket, make sure it is compatible with both the monitor and the cabinet/rack into which the monitor is installed. The DM-F series LCD monitor can be installed into a cabinet or rack.

  • Page 57: Figure 3-31: Secure The Mounting Clamp Holders

    DM-F Series Monitor NOTE: For DM-F08A It is not required to install the clamp holders to the DM-F08A monitors for panel/rack mounting. After sliding the monitor through the panel, simply insert the panel mounting clamps into the pre-formed holes along the top and side panels of the monitors.

  • Page 58: Figure 3-32: Slide Into The Rack/Cabinet Bracket

    DM-F Series Monitor Figure 3-32: Slide into the Rack/Cabinet Bracket Step 3: Insert the panel mounting clamps into the pre-formed holes of the clamp holders (Figure 3-33). Step 4: Tighten the screws that pass through the rack mounting clamps until the plastic caps at the front of all the screws are firmly secured to the bracket (Figure 3-33).

  • Page 59: Cabinet And Rack Installation (For F19A)

    DM-F Series Monitor Figure 3-34: Install into a Rack/Cabinet Step 6: Once the LCD monitor with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-34). 3.3.3 Cabinet and Rack Installation (for F19A) NOTE: When purchasing a cabinet/rack installation bracket, make sure it is...

  • Page 60: Figure 3-35: Slide Dm-F19A Into The Rack/Cabinet Bracket

    DM-F Series Monitor Figure 3-35: Slide DM-F19A into the Rack/Cabinet Bracket Step 2: Secure the rack/cabinet bracket to the monitor. To do this, secure the 10 mounting brackets to the corresponding screw holes on the rear of the monitor using the provided retention screws (Figure 3-36). Figure 3-36: Secure the Mounting Brackets Page 46...

  • Page 61: Wall Mounting

    DM-F Series Monitor Step 3: Slide the LCD monitor with the attached rack/cabinet bracket into a rack or cabinet (Figure 3-37). Figure 3-37: Install DM-F19A into a Rack/Cabinet Step 4: Once the LCD monitor with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-34).

  • Page 62: Figure 3-38: Attach Wall Mounting Kit To The Wall

    DM-F Series Monitor Each model of the DM-F series LCD monitor has four holes located on the rear panel for mounting the monitor to a wall. To mount the DM-F series LCD monitor onto a wall, please follow the steps below. Step 1: Attach the wall mounting kit to the mounting surface with the included screws.

  • Page 63: Figure 3-39: Hook Onto Wall Mounting Kit

    DM-F Series Monitor Figure 3-39: Hook Onto Wall Mounting Kit Step 4: Tighten the top screw on the wall mounting kit to securely hold the DM-F series in place. After this screw is tightened, the DM-F series should not be able to move.

  • Page 64: Stand Installation

    DM-F Series Monitor 3.3.5 Stand Installation The DM-F series LCD monitor has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel. The standard holes are M4 set at 75 mm x 75 mm or 100 mm x 100 mm apart (Figure 3-41 and Figure 3-42). Figure 3-41: VESA Mounting Holes (DM-F08A) Figure 3-42: VESA Mounting Holes (DM-F12A ~ DM-F24A) Page 50...

  • Page 65: Arm Installation

    DM-F Series Monitor To mount the DM-F series LCD monitor onto a stand, please follow the steps below. Step 1: Line up the threaded holes on the monitor rear panel with the screw holes on the monitor stand mounting plate. Step 2: Secure the monitor to the stand with the supplied retention screws ( Figure...

  • Page 66: Figure 3-44: Monitor Arm Mounting

    DM-F Series Monitor Figure 3-44: Monitor Arm Mounting Page 52...

  • Page 67: On-Screen-Display (Osd) Controls

    DM-F Series Monitor Chapter On-Screen-Display (OSD) Controls Page 53...

  • Page 68: Osd Keypad

    DM-F Series Monitor 4.1 OSD Keypad There are several on-screen-display (OSD) control buttons of the OSD keypad on the monitor rear panel. Figure 4-1 shows the 5-key membrane OSD keypad of the DM-F08A LCD monitors. Figure 4-1: OSD Keypad for DM-F08A The function of each button is described in the following table.

  • Page 69: Figure 4-2: Osd Keypad For Dm-F12A ~ Dm-F24A

    DM-F Series Monitor Figure 4-2 shows the 7-key membrane OSD keypad of the DM-F12A ~ DM-F24A. Figure 4-2: OSD Keypad for DM-F12A ~ DM-F24A The function of each button is described in the following table. LCD on/off Turn on or turn off the LCD screen. Auto Automatically adjust the screen.

  • Page 70: Osd Menu Structure

    DM-F Series Monitor 4.2 OSD Menu Structure The following table shows the OSD menu structure for all models of the DM-F series LCD monitor. Level 1 Level 2 Value Default Value Picture Backlight 0 to 100 Brightness 0 to 100 Contrast 0 to 100 Sharpness...

  • Page 71: Using The Osd

    DM-F Series Monitor 4.3 Using the OSD OSD menu options are described below. 4.3.1 Picture Menu Image menu features are shown in Figure 4-3. Figure 4-3: Picture Menu Backlight Adjusts the intensity of the LCD backlight. The brightness option adjusts the brightness of screen. This function Brightness adjusts the offset value of ADC.

  • Page 72: Display Menu

    DM-F Series Monitor 4.3.2 Display Menu Display menu features are shown in Figure 4-4. The Display menu is only available when using VGA connection. Figure 4-4: Display Menu Auto Adjust Automatically adjusts the LCD screen position. H Position Adjusts the horizontal position of the display screen V Position Adjusts the vertical position of the display screen Clock...

  • Page 73: Color Setting

    DM-F Series Monitor 4.3.3 Color Setting Color settings are shown in Figure 4-3. Figure 4-5: Color Menu Gamma This item allows adjustment of the Gamma. Color temp This item allows adjustment of the following items. 9300k – NTSC standard Kelvin ...

  • Page 74: Input Menu

    DM-F Series Monitor 4.3.4 Input Menu Input options are shown in Figure 4-6. Figure 4-6: Input Menu Input options are described below. Auto Select Selects the input device to use automatically. This item sets the input device to VGA. This item sets the input device to DisplayPort. This item sets the input device to HDMI or DVI.

  • Page 75: Other Menu

    DM-F Series Monitor 4.3.5 Other Menu The Other options are shown in Figure 4-7. Figure 4-7: Other Menu The options are described below. Restores the default OSD settings. Note that this will restore all Reset default display settings. Determines how many seconds the OSD screen stays on screen Menu Time before it disappears when OSD is left unattended.

  • Page 76: Information Menu

    DM-F Series Monitor 4.3.1 Information Menu The Information menu provides information on the LCD monitor, such as firmware version, input type and input resolution. Figure 4-8: Information Menu Page 62...

  • Page 77: Software Drivers

    DM-F Series Monitor Chapter Software Drivers Page 63...

  • Page 78: Introduction

    DM-F Series Monitor 5.1 Introduction The touch panel controller enables analog resistive touch panels for four-wire, five-wire & eight-wire models. The controller directly communicates with the PC system through the touch panel communications interface. The controller design is superior in sensitivity, accuracy, and friendly operation.

  • Page 79: Touch Panel Driver Installation

    DM-F Series Monitor NOTE: The default touchscreen interface for the DM-F series monitor is USB interface. The RS-232 interface is only reserved for the models with resistive type touchscreen.  RS-232 Interface: If the touchscreen interface connection is an RS-232 connection, connect the RS-232 connector on the single board computer to the DB-9 connector of the DM-F series monitor.
  • Page 80 DM-F Series Monitor Step 2: Download the touch driver from IEI website. Go to https://download.ieiworld.com. Type the model name of the DM Series and press Enter. Step 3: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result. Step 4: Click the driver file name on the page and you will be prompted with the ...

  • Page 81: Figure 5-1: Welcome Screen

    DM-F Series Monitor Step 5: Select the PenMount Touch Driver folder. Double click the setup icon in the folder. Step 6: The Welcome screen in Figure 5-1 appears. Figure 5-1: Welcome Screen Step 7: Click Next to continue. Step 8: The license agreement in Figure 5-2 appears.

  • Page 82: Figure 5-2: License Agreement

    DM-F Series Monitor Figure 5-2: License Agreement Step 9: The installation destination screen appears. See Figure 5-3. Click Install. Figure 5-3: Initiate Install Step 10: The installation of the program begins. See Figure 5-4. Page 68...

  • Page 83: Figure 5-4: Installation Starts

    DM-F Series Monitor Figure 5-4: Installation Starts Step 11: When the installation is complete, the complete screen appears. See Figure 5-5. To complete the installation process click Finish. Figure 5-5: Finish Installation Page 69...

  • Page 84: Change The Touchscreen Interface

    DM-F Series Monitor 5.4 Change the Touchscreen Interface If the touchscreen interface must be changed from a USB interface to an RS-232 interface or from an RS-232 interface to a USB interface, the following steps must be followed. Step 1: Uninstall the touchscreen driver Step 2: Remove the interface cable i.e.

  • Page 85: Figure 5-8: Configuration Screen

    DM-F Series Monitor Step 5: Click Control Panel in the pop up menu shown in Figure 5-7. Step 6: The configuration screen in Figure 5-8 appears. Figure 5-8: Configuration Screen Step 7: Double click the PenMount 6000 icon as shown in Figure 5-8. Step 8: The calibration initiation screen in Figure 5-9 appears.

  • Page 86: Figure 5-9: Calibration Initiation Screen

    DM-F Series Monitor Figure 5-9: Calibration Initiation Screen Step 10: The calibration screen in is shown. See Figure 5-10. Figure 5-10: Calibration Screen Step 11: Follow the instructions. The user is asked touch the screen at five specified points after which the screen is calibrated. Step 0: Page 72...

  • Page 87: Ad Boards

    DM-F Series Monitor Chapter AD Boards Page 73...

  • Page 88: Ad Board Overview

    DM-F Series Monitor 6.1 AD Board Overview The DM series LCD monitor AD board provides a wide variety of control interfaces. There are two AD boards used for the DM series monitors: AV-2525 and AV-25251. Refer to Table 1-2 for a listing of DM series monitors and their associated AD board. The following 526H sections describe each AD board in detail.

  • Page 89: Av-2525 Peripheral

    DM-F Series Monitor 6.2.1 AV-2525 Peripheral Interface Connectors Table 6-2 shows a list of the peripheral interface connectors on the AV-2525 AD board. 527H Pinouts of the connectors that are used in the DM-F series can be found in the following sections.

  • Page 90: Interface Connectors Connector (Inverter1)

    DM-F Series Monitor 6.2.2 Backlight Inverter Connector (INVERTER1) PIN NO. DESCRIPTION ON/OFF Table 6-3: Backlight Inverter Connector (INVERTER1) Pinouts 6.2.3 LVDS Connector (LVDS1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION A0P_C A0M_C A1P_C A1M_C A2P_C A2M_C CLK1P_C CLK1M_C A3P_C A3M_C A4P_C A4M_C A5P_C A5M_C...

  • Page 91: Osd Keypad Connector

    DM-F Series Monitor 6.2.4 OSD Keypad Connector (CN14) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +5V_OSD +12V OSD1 OSD2 OSD3 OSD4 OSD5 OSD6 OSD7 KEYPAD_GLED SC_3V3 Table 6-5: OSD Keypad Connector (CN14) Pinouts 6.2.5 Power Input Connector (CN9) PIN NO. DESCRIPTION Table 6-6: Power Input Connector (CN9) Pinouts 6.2.6 RS-232 Connector for Touchscreen (RS232_1) PIN NO.

  • Page 92: Resistive Touchscreen

    DM-F Series Monitor 6.2.7 USB Connector for Touchscreen (USB_TOUCH1) PIN NO. DESCRIPTION VCC_TOUCH D2F- D2F+ Table 6-8: USB Connector for Touchscreen (USB_TOUCH1) Pinouts 6.2.8 ResistiveTouchscreen Connector (J1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SENSE Table 6-9: Resistive Touchscreen Connector (J1) Pinouts Page 78...

  • Page 93: Av-25251 Ad Board

    DM-F Series Monitor 6.3 AV-25251 AD Board The connector locations of the AV-25251 are shown in Figure 6-1. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below. The connector pinouts for these connectors are listed in the following sections. Figure 6-2: AV-25251 AD Board Layout Diagram 6.3.1 AV-25251 Peripheral Interface Connectors Table 6-11 shows a list of the peripheral interface connectors on the AV-25251 AD board.

  • Page 94: Table 6-10: Peripheral Interface Connectors (Av-25251)

    DM-F Series Monitor Power input connector 3-pin wafer, p=3.96 mm PWR2 Power input connector (+12 V) 2-pin wafer, p=2.50 mm CN15 RS-232 connector for touchscreen 6-pin wafer, p=1.25 mm RS232_1 USB connector for touchscreen 4-pin wafer, p=1.25 mm USB_TOUCH1 Touchscreen connector 9-pin wafer, p=1.25 mm VGA connector 10-pin box header, p=2.00 mm VGA2...

  • Page 95: Interface Connectors Connector (Inverter1)

    DM-F Series Monitor 6.3.2 Backlight Inverter Connector (INVERTER1) PIN NO. DESCRIPTION BKL_POWER1 BKL_POWER1 ENABKL BRIGHTNESS Table 6-12: Backlight Inverter Connector (INVERTER1) Pinouts 6.3.3 LVDS Connector (LVDS1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION A0P_C A0M_C A1P_C A1M_C A2P_C A2M_C CLK1P_C CLK1M_C A3P_C A3M_C A4P_C...

  • Page 96: Osd Keypad Connector

    DM-F Series Monitor 6.3.4 OSD Keypad Connector (KEYPAD1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +5V_OSD(NC) +12V(NC) Left Auto Right Power Menu Led_GREED (UP) Down (NC) Led_RED +3.3V_DVDD(NC) Table 6-14: OSD Keypad Connector (KEYPAD1) Pinouts 6.3.5 Power Input Connector (PWR2) PIN NO. DESCRIPTION +9 V ~ +36 V to external power module +12 V input...

  • Page 97: Vga Connector

    DM-F Series Monitor 6.3.7 USB Connector for Touchscreen (USB_TOUCH1) PIN NO. DESCRIPTION VCC_TOUCH D2F- D2F+ Table 6-17: USB Connector for Touchscreen (USB_TOUCH1) Pinouts 6.3.8 Touchscreen Connector (J1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SENSE Table 6-18: Touchscreen Connector (J1) Pinouts 6.3.9 VGA Connector (VGA2) PIN NO.
  • Page 98 DM-F Series Monitor Appendix Regulatory Compliance Page 84...
  • Page 99 DM-F Series Monitor DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.
  • Page 100 DM-F Series Monitor Appendix Safety Precautions Page 86...
  • Page 101 DM-F Series Monitor WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the DM-F Series. B.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times.
  • Page 102 DM-F Series Monitor B.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the DM-F Series may result in permanent damage to the DM-F Series and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the DM-F Series.
  • Page 103 DM-F Series Monitor B.1.3 Product Disposal CAUTION: Risk of explosion if the battery is replaced by an incorrect type; Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types); Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion;...
  • Page 104 DM-F Series Monitor B.2 Maintenance and Cleaning Precautions When maintaining or cleaning the DM-F Series, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the DM-F Series, please read the details below. ...
  • Page 105 DM-F Series Monitor  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas.  Foam swabs - Whenever possible, it is best to use lint free swabs such as foam swabs for cleaning.
  • Page 106 DM-F Series Monitor Appendix smartOSD Page 92...
  • Page 107 DM-F Series Monitor C.1 IEI smartOSD Quick Installation Guide NOTE: The host computer must have a VGA port to best support smartOSD. IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that enables easy, remote monitor setting adjustments in a Windows environment. IEI smartOSD delivers excellent performance and provides more flexibility than the typical OSD hardware solutions when adjusting a monitor.
  • Page 108 DM-F Series Monitor Figure C-1: smartOSD Welcome Screen Step 4: Click Next to continue. Step 5: The Folder Select screen in Figure C-2 appears. 592H Figure C-2: smartOSD Folder Select Screen Step 6: Select the installation folder in Figure C-2 shown above. 5 93H Step 7: Click Next to continue.
  • Page 109 DM-F Series Monitor Figure C-3: smartOSD Confirm Installation Step 9: Confirm the installation by clicking Next in the screen above. Step 10: The program starts to install and the progress bar shown in FIgure C-4 appears. 595H Figure C-4: smartOSD Installation Progress Step 11: When the installation is complete the “Complete Installation”...
  • Page 110 DM-F Series Monitor Figure C-5: smartOSD Installation Complete Step 12: Click Close in the screen above. Step 13: After quick setup is complete, the IEI smartOSD wizard logo appears on the desktop as shown in the screen below. Step 14: To access the smartOSD, click the smartOSD wizard logo.Step 0: Page 96...
  • Page 111 DM-F Series Monitor C.4 Software Illustration The table below shows the smartOSD menu structure for all IEI LCD monitors. NOTE: To update the display setting status immediately, push the refresh button on every page To turn the system on, press ALT + P. Item Elements Management...
  • Page 112 DM-F Series Monitor PIP Source Input (disabled in the DM-F Series) PIP Size (disabled in the DM-F Series) Monitor Power Control System Auto Brightness (disabled in the DM-F Series) Main Source Input (YPbPr, S-Video and CVBS disabled) Volume (disabled in the DM-F Series) Factory Presets/OSD Lock/OSD Unlock Mute (disabled in the DM-F Series) Table C-1: SmartOSD Menu Structure...
  • Page 113 DM-F Series Monitor C.4.1 Manage Page Figure C-6: Manage Page Page 99...
  • Page 114 DM-F Series Monitor C.4.2 EDID Page Figure C-7: EDID Page Page 100...
  • Page 115 DM-F Series Monitor C.4.3 Image Page Figure C-8: Image Page Page 101...
  • Page 116 DM-F Series Monitor C.4.4 Display Page (for analog signal) Figure C-9: Display Page Page 102...
  • Page 117 DM-F Series Monitor C.4.5 Color Page Figure C-10: Color Page Page 103...
  • Page 118 DM-F Series Monitor C.4.6 PIP Page NOTE: The functions in the PIP page are only available in the MLCD-KIT Series and AFOLUX Series monitors. Figure C-11: PIP Page Page 104...
  • Page 119 DM-F Series Monitor C.4.7 System Page Figure C-12: System Page NOTE: Some of the functions in the System Page are only available to some of the IEI LCD series as following:  Auto Brightness: SRM, MLCD-KIT and AFOLUX series only ...
  • Page 120 DM-F Series Monitor C.4.8 About Page Figure C-13: About Page Page 106...
  • Page 121 DM-F Series Monitor C.5 smartOSD FAQ For troubleshooting, please see the steps below: C.5.1 Windows 2000 Installation Failure Installation fails under Windows 2000 and shows the following image: Figure C-14: DLL Missing Solution: Download and install service pack Windows Installer 3.1 C.5.2 Vista Installation Failure Installation fail under Vista while showing following image: Figure C-15: Windows Vista Error...
  • Page 122 DM-F Series Monitor Solution: Install SmartOSD.exe as the administrator authority Figure C-16: Install as Administrator C.5.3 Model Failure The Model Fail error message shown below appears. Figure C-17: Firmware Incompatibility Solution: SmartOSD only supports firmware version 2.0 and following versions. Page 108...
  • Page 123 DM-F Series Monitor C.5.4 DDC Port Failure The DDC port fail error message shown below appears. Figure C-18: DDC Port Failure Solutions:  Check VGA or HDMI cable  Check an IEI monitor is being used  Make sure the version is version 2.3 for the AFOLUX/MDM series and version 1.5 for the DM/ISDM/TDM/SRM/LCD-KIT series that have the SmartOSD functions ...
  • Page 124 DM-F Series Monitor Appendix Hazardous Materials Disclosure Page 110...
  • Page 125 DM-F Series Monitor D.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).
  • Page 126 DM-F Series Monitor D.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 112...
