Copyright Notice

©Copyright 2002 by ICP Electronics Inc. All Rights Reserved.
Vision:3.0. Aug, 26 2002.
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the
DM-150/SRM-150/SRM-150A
part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
User Manual
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
Ver 3.0x
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
Trademarks
DM-150,SRM150,SRM-150A is a registered trademark of ICP Electronics Inc. IBM
PC is a registered trademark of International Business Machines Corporation. Intel is
a registered trademark of Intel Corporation. Other product names mentioned herein
are used for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies. If you have any questions or need other
information, please visit to our web site.
http://www.iei.com.tw
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology DM-150

Summary of Contents for IEI Technology DM-150

  • Page 1: Copyright Notice

    Trademarks DM-150,SRM150,SRM-150A is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.

  • Page 2: Table Of Contents

    DM/SRM series offer multiple mounting 2.2 LCD Installation………………………………………………...P9 options and brightness that meet your needs. The DM-150/ SRM-150/SRM-150A is a 2.3 Panel Mounting………………………………………………..P11 15.0" flat panel display specially designed to meet the applications for industrial 2.4 Arm Mounting…………………………………………………P12...
  • Page 3 LiteMax 15”LCD CP1501 15.0" high brightness TFT LCD Support driver: Supports : Linux,MS-DOS,Windows 3.1/95/ Support digital input by DVI and VGA analog connectot 98/2000/NT,OS/2,etc. Resolution: 1024X768 MAX. Colors: 16.7 M Power supply (DM-150) : Brightness: 1750cd/m Model no: UP06031120A Hor. Frequency: 15-80KHz Input requirements: Ver. Frequency: 50-85Hz Input Voltage range: 90 to 264 VAC.

  • Page 4: Product Dimensions

    1.2 Product Dimensions Power supply (SRM-150/SRM-150A) : Model no: PSA65U-120 The following diagrams indicate the dimensions of DM-150/ SRM-150/SRM-150A. Input requirements: Front Panel: 410mm x 309mm x 9mm (WxHxD) Input Voltage range: 90 to 264 VAC. Cabinet: 383.6mm x 282.6mm x 46.7mm (WxHxD) DM-150 Line frequency: 47 to 63 HZ.

  • Page 5: Chapter 2 System Setup

    Chapter 2 System Setup 2.2 LCD Installation The DM-150/ SRM-150/SRM-150A is very easy to be set up for operation. As you set DM-150/SRM-150/SRM-150A provides two features for your choosing: one is LCD up your system, please refer to the following procedures.

  • Page 6: Panel Mounting

    If you want to install LCD with Touch Screen, please connect RS232 connector from LCD to your COM port from CPU card. The driver for touch screen we used the CD DM-150/ SRM-150/SRM-150A is either suitable for panel mounting. As you mount disk with system shipping.

  • Page 7: Arm Mounting

    2.4 Arm Mounting 2.5 Wall Mounting DM-150/ SRM-150/SRM-150A are suitable for 75/100mm interface pads or for arm mounting. arm mounting and the specification conform to the proposed DM-150/ SRM-150/SRM-150A is suitable for wall mounting and the specification VESA standard. conform to the proposed.

  • Page 8: Rack Mounting

    2.6 Rack Mounting Chapter 3 User Mode OSD Information DM/SRM-150/SRM-150A provide option rackmount kit for industrial Rack. The following diagram shows how to mount DM/SRM-150/SRM-150A onto the 19" 3.1 Features(AV-0911) Rack. VGA Input : RGB VGA input -Horizontal Sync. : 15K – 80KHz -Vertical Sync.

  • Page 9: Button Function

    3.2 Button Function 3.3 User Mode OSD Structure There are six buttons on OSD panel: ON/OFF, Auto (Up) Down, Right , Left, and LEVEL 0 LEVEL 1 VALUE DISPLAY ADJUST H-Position 0-255 Menu ( Return ). The functions of these six buttons are as follows: V-Position 0-30 CLOCK...

  • Page 10: User Mode Osd Item Description

    LANGUAGE 3.4 User Mode OSD Item Description It is used to select the languages using on OSD display. AV-0911 now can support 5 language on OSD display. English is the default language. English AUTO ( Auto-Adjustment ) Espanol This item will automatically adjust the H/V position, frequency, phase, Deutsch And black level.

  • Page 11: Appendix Check List

    Appendix Check list Item Part No. Description Qty. 14106031120A-00-020 POWER SUPPLY..POTRANS POWER(DM-150) 63PSA65U120-000 POWER SUPPLY..POTRANS POWER (SRM-150/SRM150A) 32000-000002 POWER CABLE 32000-036200 VGA CABLE D-SUB 15P M TO M/180CM 32100-041000 WIRE CABLE/40CM 42011-000150 PANEL-MOUNT KIT 41014-011602 WALL-MOUNT VIBRATION KIT 41020-003302 WALL-MOUNT BRACKET...
