Page 1: User Manual
DM-F Series Monitor DM Series Industrial Monitor MODEL: DM-F Series 6.5”/8”/12”/15”/17”/19”/21.5”/24” LCD Monitor DisplayPort, HDMI, VGA, IP 65 Protection, RoHS User Manual Page I Rev. 1.16 – November 25, 2016... - Page 2 DM-F Series Monitor Revision Date Version Changes November 25, 2016 1.16 Added Section 3.3.3: Cabinet and Rack Installation (for F19A) September 20, 2016 1.15 Updated Section 1.3: Model Variations Updated Section 1.7.2: DM-F12A ~ DM-F19A Connectors Updated Section 1.8: Technical Specifications Updated Section 1.9.6: DM-F19A Physical Dimensions Modified Section 3.3.1: Panel Mounting Modified Section 3.3.2: Cabinet and Rack Installation...
-
Page 3: Safety Instructions
DM-F Series Monitor Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi. - Page 4 DM-F Series Monitor Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
- Page 5 DM-F Series Monitor Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 6 DM-F Series Monitor Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.
-
Page 7: Table Of Contents
DM-F Series Monitor Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 M ....................3 ODEL ARIATIONS 1.4 A ......................3 PPLICATIONS 1.5 F ......................4 RONT 1.6 R ........................ 5 1.7 C ...................... - Page 8 DM-F Series Monitor 3.2.2 9 V–36 V Terminal Block (Optional)..............24 3.2.3 USB for Touch Panel Connector..............25 3.2.4 VGA Connector ....................25 3.2.5 DVI-D Connector (F65A, F08A and F19A Only)..........26 3.2.6 DisplayPort Connector (F12A ~ F24A Only)..........27 3.2.7 HDMI Connector (F12A, F15A, F17A, F22A and F24A Only).......
- Page 9 DM-F Series Monitor 6.2 AV-6038 AD B ....................69 OARD 6.2.1 AV-6038 Peripheral Interface Connectors............70 6.2.2 Backlight Inverter Connector (INVERTER1) ..........71 6.2.3 LVDS Connector (LVDS1) ................71 6.2.4 OSD Keypad Connector (CN14)..............72 6.2.5 Power Input Connector (CN9)................. 72 6.2.6 RS-232 Connector for Touchscreen (RS232_1) ..........
- Page 10 DM-F Series Monitor C SMARTOSD ........................ 88 C.1 IEI OSD Q ............89 SMART UICK NSTALLATION UIDE C.2 P ..................89 INSTALLATION OTICE OSD I ..................89 SMART NSTALLATION C.4 S ..................92 OFTWARE LLUSTRATION C.4.1 Manage Page....................95 C.4.2 EDID Page ...................... 96 C.4.3 Image Page......................
- Page 11 DM-F Series Monitor List of Figures Figure 1-1: DM-F Series .........................2 Figure 1-2: Typical Monitor Front View ..................4 Figure 1-3: 6.5” and 8” Rear View ....................5 Figure 1-4: 12”–24” Rear View ......................5 Figure 1-5: Bottom Panel Connectors (DM-F65A/08A) ...............6 Figure 1-6: Side Panel Connectors (DM-F65A/08A) ..............6 Figure 1-7: Bottom Panel Connectors (DM-F12A/15A/17A/19A)..........7 Figure 1-8: Side Panel Connector (DM-F12A/15A/17A/19A) ............7 Figure 1-9: Bottom Panel Connectors (DM-F22A/24A) ...............7...
- Page 12 DM-F Series Monitor Figure 3-14: Mounting Clamps ....................32 Figure 3-15: DM-F65A Cutout Dimensions (Unit: mm) .............33 Figure 3-16: DM-F08A Cutout Dimensions (Unit: mm) .............33 Figure 3-17: DM-F12A Cutout Dimensions (Unit: mm) .............33 Figure 3-18: DM-F15A Cutout Dimensions (Unit: mm) .............34 Figure 3-19: DM-F17A Cutout Dimensions (Unit: mm) .............34 Figure 3-20: DM-F19A Cutout Dimensions (Unit: mm) .............34 Figure 3-21: DM-F22A Cutout Dimensions (Unit: mm) .............35...
- Page 13 DM-F Series Monitor Figure 4-6: System Menu ......................56 Figure 4-7: Input Options......................57 Figure 4-8: OSD Settings Menu....................58 Figure 5-1: Setup Icon ........................62 Figure 5-2: Welcome Screen .......................62 Figure 5-3: License Agreement ....................63 Figure 5-4: Initiate Install ......................63 Figure 5-5: Installation Starts ......................64 Figure 5-6: Finish Installation......................64 Figure 5-7: PenMount Monitor Icon ....................65 Figure 5-8: PenMount Monitor Popup Menu ................66...
- Page 14 DM-F Series Monitor List of Tables Table 1-1: DM-F Series Model Variations ..................3 Table 1-2: DM-F Series Specifications..................9 Table 2-1: Packing List.........................20 Table 3-1: USB Touch Panel Connector Pinouts ..............25 Table 3-2: VGA Connector Pinouts.....................25 Table 3-3: DVI-D Connector Pinouts...................26 Table 3-4: Display Port Connector Pinouts ................27 Table 3-5: HDMI Connector Pinouts ...................28 Table 3-6: RS-232 Touch Panel Connector Pinouts..............28...
- Page 15 DM-F Series Monitor Table 6-19: VGA Connector (VGA2) Pinouts ................78 Table 6-20: Backlight Voltage Select Jumper (JP5) Pinouts............78 Table 6-21: LVDS Panel Voltage Select Jumper (JP2) Pinouts..........78 Table 6-22: Power Input Setting Jumper (JP4) Pinouts............79 Table 6-23: Touchscreen Type Select Jumper (JP1) Pinouts ..........79 Table C-1: SmartOSD Menu Structure..................94 Page XV...
-
Page 17: Introduction
DM-F Series Monitor Chapter Introduction Page 1... -
Page 18: Overview
DM-F Series Monitor 1.1 Overview Figure 1-1: DM-F Series The DM-F series LCD monitor is the latest member of IEI’s line of sophisticated LCD designs with flat bezel. It is designed to fit industrial automation, or any other applications that require minimum installation space and flexible configuration. The flat front panel provides IP 65 protection, which effectively wards off dust and water. -
Page 19: Model Variations
1.3 Model Variations The DM-F series LCD monitor base models have a variety of variants. The model variations are listed in T able 1-1. Model Number Touchscreen Power HDMI/DVI DisplayPort DM-F65A/R-R10 6.5” Resistive 12 V DVI-D DM-F08A/R-R10 8” Resistive 12 V... -
Page 20: Front View
DM-F Series Monitor Shop-floor/MES control Self-service Kiosk Full-service receptionist kiosk Hospital self-registration terminal Interactive photo kiosk Video rental kiosk Self-service POS terminal 1.5 Front View The front of the DM-F series LCD monitor is a flat panel LCD screen surrounded by an aluminum frame. -
Page 21: Rear View
DM-F Series Monitor 1.6 Rear View The rear panel provides access to retention screw holes that support VESA mounting. A 5-key/7-key membrane OSD keypad is also located on the rear panel. The following diagrams show the rear panel of the DM-F series. Figure 1-3: 6.5”... -
Page 22: Connectors
DM-F Series Monitor 1.7 Connectors The following sections show the I/O interfaces of the DM-F series LCD monitor. All connectors are fully described in Section 3 .2. 1.7.1 DM-F65A and DM-F08A Connectors Figure 1-5: Bottom Panel Connectors (DM-F65A/08A) Figure 1-6: Side Panel Connectors (DM-F65A/08A) Page 6... -
Page 23: Dm-F12A ~ Dm-F19A Connectors
DM-F Series Monitor 1.7.2 DM-F12A ~ DM-F19A Connectors Figure 1-7: Bottom Panel Connectors (DM-F12A/15A/17A/19A) Figure 1-8: Side Panel Connector (DM-F12A/15A/17A/19A) 1.7.3 DM-F22A and DM-F24A Connectors Figure 1-9: Bottom Panel Connectors (DM-F22A/24A) Page 7... -
Page 24: Technical Specifications
DM-F Series Monitor 1.8 Technical Specifications T able 1-2 shows the DM-F series technical specifications. Model DM-F65A DM-F08A DM-F12A DM-F15A DM-F17A DM-F19A DM-F22A DM-F24A LCD Display 6.5” (4:3) 8” (4:3) 12” (4:3) 15” (4:3) 17” (5:4) 19” (5:4) 21.5” (16:9) 24”... -
Page 25: Table 1-2: Dm-F Series Specifications
DM-F Series Monitor Model DM-F65A DM-F08A DM-F12A DM-F15A DM-F17A DM-F19A DM-F22A DM-F24A Optional Wall Wall Wall Wall Wall Wall Wall Wall Mounting Kit Rack Rack Rack Rack Rack Panel Panel Panel Panel Panel Panel Panel Panel Stand Stand Stand Stand Stand Stand Stand... -
Page 26: Physical Dimensions
DM-F Series Monitor 1.9 Physical Dimensions The following sections describe the physical dimensions for each model of the DM-F series LCD monitor. 1.9.1 DM-F65A Physical Dimensions The physical dimensions of the DM-F65A are shown in F igure 1-12. Figure 1-10: DM-F65A Physical Dimensions (Unit: mm) Page 10... -
Page 27: Dm-F08A Physical Dimensions
DM-F Series Monitor 1.9.2 DM-F08A Physical Dimensions The physical dimensions of the DM-F08A are shown in F igure 1-12. Figure 1-11: DM-F08A Physical Dimensions (Unit: mm) Page 11... -
Page 28: Dm-F12A Physical Dimensions
DM-F Series Monitor 1.9.3 DM-F12A Physical Dimensions The physical dimensions of the DM-F12A are shown in F igure 1-12. Figure 1-12: DM-F12A Physical Dimensions (Unit: mm) Page 12... -
Page 29: Dm-F15A Physical Dimensions
DM-F Series Monitor 1.9.4 DM-F15A Physical Dimensions The physical dimensions of the DM-F15A are shown in F igure 1-13. Figure 1-13: DM-F15A Physical Dimensions (Unit: mm) Page 13... -
Page 30: Dm-F17A Physical Dimensions
DM-F Series Monitor 1.9.5 DM-F17A Physical Dimensions The physical dimensions of the DM-F17A are shown in F igure 1-14. Figure 1-14: DM-F17A Physical Dimensions (Unit: mm) Page 14... -
Page 31: Dm-F19A Physical Dimensions
DM-F Series Monitor 1.9.6 DM-F19A Physical Dimensions The physical dimensions of the DM-F19A are shown in F igure 1-12. Figure 1-15: DM-F19A Physical Dimensions (Unit: mm) Page 15... -
Page 32: Dm-F22A Physical Dimensions
DM-F Series Monitor 1.9.7 DM-F22A Physical Dimensions The physical dimensions of the DM-F22A are shown in F igure 1-16. Figure 1-16: DM-F22A Physical Dimensions (Unit: mm) Page 16... -
Page 33: Dm-F24A Physical Dimensions
DM-F Series Monitor 1.9.8 DM-F24A Physical Dimensions The physical dimensions of the DM-F24A are shown in F igure 1-17. Figure 1-17: DM-F24A Physical Dimensions (Unit: mm) Page 17... -
Page 34: Unpacking
DM-F Series Monitor Chapter Unpacking Page 18... -
Page 35: Unpacking Procedure
DM-F Series Monitor 2.1 Unpacking Procedure To unpack the DM-F series LCD monitor, follow the steps below: WARNING: The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the DM-F series LCD monitor has been properly installed. -
Page 36: Packing List
DM-F Series Monitor 2.2 Packing List The DM-F series monitor is shipped with the following components: Quantity Item Image DM-F series USB cable (for touchscreen) (P/N: 32001-006100-100-RS) VGA cable (P/N: 32000-036200-RS) Touch pen (resistive touch only) (P/N: 43125-0002C0-00-RS) 60W 12V DC adapter with lockable connector (6.5”... -
Page 37: Optional Items
DM-F Series Monitor 2.3 Optional Items The following items are optional accessories for the DM-F series monitor: Item DM-F65A DM-F08A DM-F12A DM-F15A DM-F17A DM-F19A DM-F22A DM-F24A ARM-11-RS ARM-31-RS STAND-A12-RS STAND-B08 STAND-A19-RS, STAND-C19-RS or STAND-A21-RS Stand STAND-C12-RS AFLWK-12 WK-190MS-R10 Wall Mount Kit FPK-04-R10 FPK-01-R10 FPK-02-R10... -
Page 38: Installation
DM-F Series Monitor Chapter Installation Page 22... -
Page 39: Installation Precautions
DM-F Series Monitor 3.1 Installation Precautions When installing the DM-F series LCD monitor, please follow the precautions listed below: Read the user manual: The user manual provides a complete description of the DM-F series LCD monitor, installation instructions and configuration options. -
Page 40: External Peripheral Device Connection
DM-F Series Monitor 3.2 External Peripheral Device Connection The external I/O connector pinouts of the DM-F series industrial monitors are described in the following sections. 3.2.1 DC-in Jack The lockable power connector connects to the power adapter and provides power to the monitor. -
Page 41: Usb For Touch Panel Connector
DM-F Series Monitor 3.2.3 USB for Touch Panel Connector Use the rear panel standard USB touch panel connector to connect the monitor to the system graphics interface. DESCRIPTION DESCRIPTION USB20_N11 USB20_P11 Table 3-1: USB Touch Panel Connector Pinouts Figure 3-3: USB Touch Panel Connector 3.2.4 VGA Connector Use the rear panel standard 15-pin female VGA connector to connect the monitor to the system graphics interface. -
Page 42: Dvi-D Connector (F65A, F08A And F19A Only)
DM-F Series Monitor 3.2.5 DVI-D Connector (F65A, F08A and F19A Only) The 24-pin Digital Visual Interface (DVI) connector connects to high-speed, high-resolution digital displays. The DVI-D connector supports only digital signals. DESCRIPTION DESCRIPTION TMDS Data2- TMDS Data2+ PVDD1 TMDS Data0- DDC Clock [SCL] TMDS Data0+ DDC Data [SDA]... -
Page 43: Displayport Connector (F12A ~ F24A Only)
DM-F Series Monitor 3.2.6 DisplayPort Connector (F12A ~ F24A Only) The DisplayPort connector transmits a digital signal to compatible DisplayPort display devices such as a TV or computer screen. DESCRIPTION DESCRIPTION ML_L3N ML_L3P ML_L2N ML_L2P ML_L1N ML_L1P ML_L0N ML_L0P C_DDI0_DP_AUXP C_DDI0_DP_AUXN C_DDI0_DP_HPD Table 3-4: Display Port Connector Pinouts... -
Page 44: Hdmi Connector (F12A, F15A, F17A, F22A And F24A Only)
DM-F Series Monitor 3.2.7 HDMI Connector (F12A, F15A, F17A, F22A and F24A Only) The HDMI connector connects to a display device with HDMI interface. DESCRIPTION DESCRIPTION HDMI_TMDS_C_DATA2 HDMI_TMDS_C_DATA2# HDMI_TMDS_C_DATA1 HDMI_TMDS_C_DATA1# HDMI_TMDS_C_DATA0 HDMI_TMDS_C_DATA0# HDMI_TMDS_C_CLK HDMI_TMDS_C_CLK# HDMI_DDC_SCLK HDMI_DDC_SDATA +5V_HDMI HDMI_HPD Table 3-5: HDMI Connector Pinouts Figure 3-7: HDMI Connector 3.2.8 RS-232 Port for Touch Panel (Reserved for Resistive Touch) Use the side panel standard RS-232 DB-9 female touch panel connector to connect the... -
Page 45: Installing Rs-232 Connector
DM-F Series Monitor Figure 3-8: RS-232 Touch Panel Connector 3.2.8.1 Installing RS-232 Connector If the DM-F series doesn’t have the RS-232 connector on the side panel, the user can purchase the RS-232 Touch Cable Kit (DM-F-COMKIT-R10) and install the RS-232 connector onto the system. -
Page 46: Figure 3-10: Rear Panel Retention Screw Removal (12"-24")
DM-F Series Monitor Figure 3-10: Rear Panel Retention Screw Removal (12”–24”) Remove the RS-232 knockout hole on the side panel. Step 2: Connect the RS-232 flat cable to the internal RS-232 connector (1x9 pin, Step 3: RS232_1) on the AD board. See Figure 3-11. Figure 3-11: Connecting RS-232 Cable Insert the D-sub 9 connector of the RS-232 flat cable into the hole and secure Step 4:... -
Page 47: Mounting The Monitor
DM-F Series Monitor Figure 3-12: Hex Jack Screws for Securing RS-232 Connector Re-install the rear panel. Step 5: 3.3 Mounting the Monitor The DM-F series LCD monitor can be mounted in a panel, cabinet, rack or wall. The monitor can also be mounted on a monitor arm or stand. The mounting methods are described below. -
Page 48: Figure 3-13: Mounting Clamps Holder
DM-F Series Monitor DM-F17A DM-F19A DM-F22A DM-F24A Table 3-7: Panel Mounting Clamps Figure 3-13: Mounting Clamps Holder Figure 3-14: Mounting Clamps To mount the DM-F series LCD monitor into a panel, please follow the steps below. Select the position on the panel to mount the monitor. Step 1: Cut out a section of the panel that corresponds to the rear panel dimensions of Step 2:... -
Page 49: Figure 3-15: Dm-F65A Cutout Dimensions (Unit: Mm)
DM-F Series Monitor Figure 3-15: DM-F65A Cutout Dimensions (Unit: mm) Figure 3-16: DM-F08A Cutout Dimensions (Unit: mm) Figure 3-17: DM-F12A Cutout Dimensions (Unit: mm) Page 33... -
Page 50: Figure 3-18: Dm-F15A Cutout Dimensions (Unit: Mm)
DM-F Series Monitor Figure 3-18: DM-F15A Cutout Dimensions (Unit: mm) Figure 3-19: DM-F17A Cutout Dimensions (Unit: mm) Figure 3-20: DM-F19A Cutout Dimensions (Unit: mm) Page 34... -
Page 51: Figure 3-21: Dm-F22A Cutout Dimensions (Unit: Mm)
DM-F Series Monitor Figure 3-21: DM-F22A Cutout Dimensions (Unit: mm) Figure 3-22: DM-F24A Cutout Dimensions (Unit: mm) Secure the mounting clamps holders to the corresponding holes on the rear of Step 3: the monitor (Figure 3-23). NOTE: It is not required to install the clamp holders to the DM-F65A and DM-F08A monitors for panel/rack mounting. -
Page 52: Figure 3-23: Secure The Mounting Clamp Holders
DM-F Series Monitor Figure 3-23: Secure the Mounting Clamp Holders Slide the monitor through the hole until the aluminum frame is flush against the Step 4: panel (Figure 3-24). Figure 3-24: Slide into the Panel Page 36... -
Page 53: Figure 3-25: Panel Mounting Clamp Installation
DM-F Series Monitor Insert the panel mounting clamps into the pre-formed holes of the clamp holders Step 5: (Figure 3-25). Tighten the screws that pass through the panel mounting clamps until the plastic Step 6: caps at the front of all the screws are firmly secured to the panel (Figure 3-25). Figure 3-25: Panel Mounting Clamp Installation The dimensions of the clamp holder and the clamp are shown in the following diagrams. -
Page 54: Figure 3-27: Ultra Set Plate Dimensions
DM-F Series Monitor Figure 3-27: Ultra Set Plate Dimensions Figure 3-28: Bolt Dimensions Figure 3-29: Steering Button Dimensions Page 38... -
Page 55: Cabinet And Rack Installation (For F65A ~ F17A)
DM-F Series Monitor 3.3.2 Cabinet and Rack Installation (for F65A ~ F17A) NOTE: When purchasing a cabinet/rack installation bracket, make sure it is compatible with both the monitor and the cabinet/rack into which the monitor is installed. The DM-F series LCD monitor can be installed into a cabinet or rack. The installation procedures are similar to the panel mounting installation. -
Page 56: Figure 3-31: Slide Into The Rack/Cabinet Bracket
DM-F Series Monitor Slide the rear of the DM-F series LCD monitor through the rack/cabinet bracket Step 2: until the aluminum frame is flush against the front of the bracket (Figure 3-31). Figure 3-31: Slide into the Rack/Cabinet Bracket Insert the panel mounting clamps into the pre-formed holes of the clamp holders Step 3: (Figure 3-32). -
Page 57: Cabinet And Rack Installation (For F19A)
DM-F Series Monitor Slide the LCD monitor with the attached rack/cabinet bracket into a rack or Step 5: cabinet (Figure 3-33). Figure 3-33: Install into a Rack/Cabinet Once the LCD monitor with the attached rack/cabinet bracket has been properly Step 6: inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-33). -
Page 58: Figure 3-34: Slide Dm-F19A Into The Rack/Cabinet Bracket
DM-F Series Monitor Figure 3-34: Slide DM-F19A into the Rack/Cabinet Bracket Secure the rack/cabinet bracket to the monitor. To do this, secure the 10 Step 2: mounting brackets to the corresponding screw holes on the rear of the monitor using the provided retention screws (Figure 3-35). Figure 3-35: Secure the Mounting Brackets Page 42... -
Page 59: Figure 3-36: Install Dm-F19A Into A Rack/Cabinet
DM-F Series Monitor Slide the LCD monitor with the attached rack/cabinet bracket into a rack or Step 3: cabinet (Figure 3-36). Figure 3-36: Install DM-F19A into a Rack/Cabinet Once the LCD monitor with the attached rack/cabinet bracket has been properly Step 4: inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-33). -
Page 60: Wall Mounting
DM-F Series Monitor 3.3.4 Wall Mounting CAUTION: Due to safety concerns, it is highly recommended to use the VESA mounting kits provided by IEI for wall, stand and arm mounting. If the VESA mounting kit is purchased separately, please make sure the mounting kit is UL-listed. -
Page 61: Figure 3-38: Hook Onto Wall Mounting Kit
DM-F Series Monitor Figure 3-38: Hook Onto Wall Mounting Kit Tighten the top screw on the wall mounting kit to securely hold the DM-F series Step 4: in place. After this screw is tightened, the DM-F series should not be able to move. -
Page 62: Stand Installation
DM-F Series Monitor 3.3.5 Stand Installation The DM-F series LCD monitor has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel. The standard holes are M4 set at 75 mm x 75 mm or 100 mm x 100 mm apart (Figure 3-40 and Figure 3-41). Figure 3-40: VESA Mounting Holes (6.5”... -
Page 63: Arm Installation
DM-F Series Monitor To mount the DM-F series LCD monitor onto a stand, please follow the steps below. Line up the threaded holes on the monitor rear panel with the screw holes on the Step 1: monitor stand mounting plate. Secure the monitor to the stand with the supplied retention screws ( F igure 3-42). -
Page 64: Figure 3-43: Monitor Arm Mounting
DM-F Series Monitor Figure 3-43: Monitor Arm Mounting Page 48... -
Page 65: On-Screen-Display (Osd) Controls
DM-F Series Monitor Chapter On-Screen-Display (OSD) Controls Page 49... -
Page 66: Osd Keypad
DM-F Series Monitor 4.1 OSD Keypad There are several on-screen-display (OSD) control buttons of the OSD keypad on the monitor rear panel. Figure 4-1 shows the 5-key membrane OSD keypad of the 6.5”and 8” LCD monitors. Figure 4-1: OSD Keypad for 6.5” and 8” Monitors The function of each button is described in the following table. -
Page 67: Figure 4-2: Osd Keypad For 12"-24" Monitors
DM-F Series Monitor Figure 4-2 shows the 7-key membrane OSD keypad of the 12”–24” LCD monitors. Figure 4-2: OSD Keypad for 12”–24” Monitors The function of each button is described in the following table. LCD on/off Press this button to turn on or turn off the LCD screen. Auto Press this button to automatically adjust the screen. -
Page 68: Osd Menu Structure
DM-F Series Monitor 4.2 OSD Menu Structure T able 4-3 shows the OSD menu structure for all models of the DM-F series LCD monitor. Level 0 Level 1 Level 2 Value Image Brightness 0 to 100 Contrast 0 to 100 Sharpness -4 to 4 Color... -
Page 69: Using The Osd
DM-F Series Monitor 4.3 Using the OSD OSD menu options are described below. 4.3.1 Image Menu Image menu features are shown in Figure 4-3. Figure 4-3: Image Menu The brightness option adjusts the brightness of screen. This function adjusts the offset value of ADC. Setting this value too high or too low Brightness will affect the quality of image. -
Page 70: Color Setting
DM-F Series Monitor 4.3.1.1 Color Setting Color settings are shown in Figure 4-3. Figure 4-4: Color Settings Automatically adjusts the color settings. auto This item allows adjustment of the following items. Color temp 5000k – NTSC standard Kelvin 6500k –... -
Page 71: Display Menu
DM-F Series Monitor 4.3.2 Display Menu Display menu features are shown in Figure 4-5. Figure 4-5: Display Menu Automatically adjusts the LCD screen position. Auto Adjust Adjusts the phase control of image Phase Adjusts frequency to fill display Clock Display Position Adjusts the horizontal and vertical position of the display screen This item allows adjustment of the Gamma. -
Page 72: System Menu
DM-F Series Monitor 4.3.3 System Menu System menu features are shown in Figure 4-6. Figure 4-6: System Menu Allows selection of input device to use. (Figure 4-7) Input Provides options for OSD configuration. (Figure 4-8) OSD Settings Provides information on the LCD monitor, such as firmware version, Information release date and input resolution. -
Page 73: Input
DM-F Series Monitor 4.3.3.1 Input Input options are shown in Figure 4-7. Figure 4-7: Input Options Input options are described below. This item sets the input device to display port. Display Port This item sets the input device to VGA. This item sets the input device to HDMI. -
Page 74: Osd Settings
DM-F Series Monitor 4.3.3.2 OSD Settings The OSD settings are shown in Figure 4-8. Figure 4-8: OSD Settings Menu OSD settings are described below. Determines how many seconds the OSD screen stays on screen Timer before it disappears when OSD is left unattended. Adjusts the OSD rotation angle on the screen. -
Page 75: Software Drivers
DM-F Series Monitor Chapter Software Drivers Page 59... -
Page 76: Introduction
DM-F Series Monitor 5.1 Introduction The touch panel controller enables analog resistive touch panels for four-wire, five-wire & eight-wire models. The controller directly communicates with the PC system through the touch panel communications interface. The controller design is superior in sensitivity, accuracy, and friendly operation. -
Page 77: Touch Panel Driver Installation
DM-F Series Monitor NOTE: The default touchscreen interface for the DM-F series monitor is USB interface. The RS-232 interface is only reserved for the models with resistive type touchscreen. RS-232 Interface: If the touchscreen interface connection is an RS-232 connection, connect the RS-232 connector on the single board computer to the DB-9 connector of the DM-F series monitor. -
Page 78: Figure 5-1: Setup Icon
DM-F Series Monitor Figure 5-1: Setup Icon Double click the setup icon in Figure 5-1. Step 4: The Welcome screen in Figure 5-2 appears. Step 5: Figure 5-2: Welcome Screen Click Next to continue. Step 6: The license agreement in Figure 5-3 appears. Accept the terms of the Step 7: agreement by clicking I Agree. -
Page 79: Figure 5-3: License Agreement
DM-F Series Monitor Figure 5-3: License Agreement The installation destination screen appears. See Figure 5-4. Click Install. Step 8: Figure 5-4: Initiate Install The installation of the program begins. See Figure 5-5. Step 9: Page 63... -
Page 80: Figure 5-5: Installation Starts
DM-F Series Monitor Figure 5-5: Installation Starts When the installation is complete, the complete screen appears. See Figure 5-6. Step 10: To complete the installation process click Finish. Figure 5-6: Finish Installation Page 64... -
Page 81: Change The Touchscreen Interface
DM-F Series Monitor 5.4 Change the Touchscreen Interface If the touchscreen interface must be changed from a USB interface to an RS-232 interface or from an RS-232 interface to a USB interface, the following steps must be followed. Uninstall the touchscreen driver Step 1: Remove the interface cable i.e. -
Page 82: Figure 5-8: Penmount Monitor Popup Menu
DM-F Series Monitor Figure 5-8: PenMount Monitor Popup Menu Click Control Panel in the pop up menu shown in Figure 5-8. Step 5: The configuration screen in Figure 5-9 appears. Step 6: Figure 5-9: Configuration Screen Double click the PenMount 6000 icon as shown in Figure 5-9. Step 7: The calibration initiation screen in Figure 5-10 appears. -
Page 83: Figure 5-10: Calibration Initiation Screen
DM-F Series Monitor Figure 5-10: Calibration Initiation Screen The calibration screen in is shown. See Figure 5-11. Step 10: Figure 5-11: Calibration Screen Follow the instructions. The user is asked touch the screen at five specified Step 11: points after which the screen is calibrated. Step 0: Page 67... -
Page 84: Ad Boards
DM-F Series Monitor Chapter AD Boards Page 68... -
Page 85: Ad Board Overview
DM-F Series Monitor 6.1 AD Board Overview The DM series LCD monitor AD board provides a wide variety of control interfaces. There are two AD boards used for the DM series monitors: AV-6038 and AV-60381. Refer to T able 1-2 for a listing of DM series monitors and their associated AD board. The following sections describe each AD board in detail. -
Page 86: Av-6038 Peripheral Interface Connectors
DM-F Series Monitor 6.2.1 AV-6038 Peripheral Interface Connectors T able 6-1 shows a list of the peripheral interface connectors on the AV-6038 AD board. Pinouts of the connectors that are used in the DM-F series can be found in the following sections. -
Page 87: Backlight Inverter Connector (Inverter1)
DM-F Series Monitor 6.2.2 Backlight Inverter Connector (INVERTER1) PIN NO. DESCRIPTION BKL_POWER1 BKL_POWER1 ENABKL BRIGHTNESS Table 6-2: Backlight Inverter Connector (INVERTER1) Pinouts 6.2.3 LVDS Connector (LVDS1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION A0P_C A0M_C A1P_C A1M_C A2P_C A2M_C CLK1P_C CLK1M_C A3P_C A3M_C A4P_C... -
Page 88: Osd Keypad Connector (Cn14)
DM-F Series Monitor 6.2.4 OSD Keypad Connector (CN14) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +5V_OSD +12V OSD1 OSD2 OSD3 OSD4 OSD5 OSD6 OSD7 MLED8 +3.3V_DVDD Table 6-4: OSD Keypad Connector (CN14) Pinouts 6.2.5 Power Input Connector (CN9) PIN NO. DESCRIPTION Table 6-5: Power Input Connector (CN9) Pinouts 6.2.6 RS-232 Connector for Touchscreen (RS232_1) PIN NO. -
Page 89: Usb Connector For Touchscreen (Usb_Touch1)
DM-F Series Monitor 6.2.7 USB Connector for Touchscreen (USB_TOUCH1) PIN NO. DESCRIPTION VCC_TOUCH D2F- D2F+ Table 6-7: USB Connector for Touchscreen (USB_TOUCH1) Pinouts 6.2.8 Touchscreen Connector (J1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SENSE Table 6-8: Touchscreen Connector (J1) Pinouts 6.2.9 LVDS Panel Voltage Select Jumper (JP2) DESCRIPTION Short 1-2... -
Page 90: Av-60381 Ad Board
DM-F Series Monitor 6.3 AV-60381 AD Board The connector locations of the AV-60381 are shown in Figure 6-1. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below. The connector pinouts for these connectors are listed in the following sections. Figure 6-2: AV-60381 AD Board Layout Diagram 6.3.1 AV-60381 Peripheral Interface Connectors T able 6-11 shows a list of the peripheral interface connectors on the AV-60381 AD board. -
Page 91: Backlight Inverter Connector (Inverter1)
DM-F Series Monitor Power input connector 3-pin wafer, p=3.96 mm PWR2 Power input connector (+12 V) 2-pin wafer, p=2.00 mm CN15 Power output connector 2-pin wafer, p=2.00 mm CN16 RS-232 connector for touchscreen 6-pin wafer, p=1.25 mm RS232_1 SPI flash connector 6-pin wafer, p=1.25 mm JSPI1 USB connector for touchscreen... -
Page 92: Lvds Connector (Lvds1)
DM-F Series Monitor 6.3.3 LVDS Connector (LVDS1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION A0P_C A0M_C A1P_C A1M_C A2P_C A2M_C CLK1P_C CLK1M_C A3P_C A3M_C A4P_C A4M_C A5P_C A5M_C A6P_C A6M_C CLK2P_C CLK2M_C A7P_C A7M_C Table 6-13: LVDS Connector (LVDS1) Pinouts 6.3.4 OSD Keypad Connector (KEYPAD1) PIN NO. -
Page 93: Power Input Connector (Pwr2)
DM-F Series Monitor 6.3.5 Power Input Connector (PWR2) PIN NO. DESCRIPTION +9 V ~ +36 V to external power module +12 V input Table 6-15: Power Input Connector (PWR2) Pinouts 6.3.6 RS-232 Connector for Touchscreen (RS232_1) PIN NO. DESCRIPTION NDSR NRTS NDTR Table 6-16: RS-232 Connector for Touchscreen (RS232_1) Pinouts... -
Page 94: Vga Connector (Vga2)
DM-F Series Monitor PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 6-18: Touchscreen Connector (J1) Pinouts 6.3.9 VGA Connector (VGA2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMCLK GREEN SMDATA BLUE H-SYNC V-SYNC Table 6-19: VGA Connector (VGA2) Pinouts 6.3.10 Backlight Voltage Select Jumper (JP5) DESCRIPTION Short 1-2 +3.3 V... -
Page 95: Power Input Setting Jumper (Jp4)
DM-F Series Monitor 6.3.12 Power Input Setting Jumper (JP4) DESCRIPTION Short 1-3, 2-4 +12 V from power jack (PRW1) Input with external connector Short 3-5, 4-6 (external power module is needed) Table 6-22: Power Input Setting Jumper (JP4) Pinouts 6.3.13 Touchscreen Type Select Jumper (JP1) DESCRIPTION 5-wire touchscreen 4-wire/8-wire touchscreen... -
Page 96: A Regulatory Compliance
DM-F Series Monitor Appendix Regulatory Compliance Page 80... - Page 97 DM-F Series Monitor DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.
-
Page 98: B Safety Precautions
DM-F Series Monitor Appendix Safety Precautions Page 82... -
Page 99: Safety Precautions
DM-F Series Monitor WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the DM-F Series. B.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times. -
Page 100: Anti-Static Precautions
DM-F Series Monitor B.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the DM-F Series may result in permanent damage to the DM-F Series and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the DM-F Series. -
Page 101: Product Disposal
DM-F Series Monitor B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method. -
Page 102: Maintenance And Cleaning Precautions
DM-F Series Monitor B.2 Maintenance and Cleaning Precautions When maintaining or cleaning the DM-F Series, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the DM-F Series, please read the details below. ... - Page 103 DM-F Series Monitor Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas. Foam swabs - Whenever possible, it is best to use lint free swabs such as foam swabs for cleaning.
-
Page 104: C Smartosd
DM-F Series Monitor Appendix smartOSD Page 88... -
Page 105: Iei Smartosd Quick Installation Guide
DM-F Series Monitor C.1 IEI smartOSD Quick Installation Guide IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that enables easy, remote monitor setting adjustments in a Windows environment. IEI smartOSD delivers excellent performance and provides more flexibility than the typical OSD hardware solutions when adjusting a monitor. - Page 106 DM-F Series Monitor Figure C-1: smartOSD Welcome Screen Click Next to continue. Step 4: The Folder Select screen in Figure C-2 appears. Step 5: Figure C-2: smartOSD Folder Select Screen Select the installation folder in Figure C-2 shown above. Step 6: Click Next to continue.
- Page 107 DM-F Series Monitor Figure C-3: smartOSD Confirm Installation Confirm the installation by clicking Next in the screen above. Step 9: The program starts to install and the progress bar shown in FIgure C-4 appears. Step 10: Figure C-4: smartOSD Installation Progress When the installation is complete the “Complete Installation”...
-
Page 108: Software Illustration
DM-F Series Monitor Figure C-5: smartOSD Installation Complete Click Close in the screen above. Step 12: After quick setup is complete, the IEI smartOSD wizard logo appears on the Step 13: desktop as shown in the screen below. To access the smartOSD, click the smartOSD wizard logo.Step 0: Step 14: C.4 Software Illustration... - Page 109 DM-F Series Monitor NOTE: To update the display setting status immediately, push the refresh button on every page To turn the system on, press ALT + P. Item Elements Save/Load File Management Power Management EDID contains basic information about the monitor and its EDID capabilities.
-
Page 110: Table C-1: Smartosd Menu Structure
DM-F Series Monitor Auto Brightness (disabled in the DM-F Series) Main Source Input (YPbPr, S-Video and CVBS disabled) Volume (disabled in the DM-F Series) Factory Presets/OSD Lock/OSD Unlock Mute (disabled in the DM-F Series) Table C-1: SmartOSD Menu Structure Page 94... -
Page 111: Manage Page
DM-F Series Monitor C.4.1 Manage Page Figure C-6: Manage Page Page 95... -
Page 112: Edid Page
DM-F Series Monitor C.4.2 EDID Page Figure C-7: EDID Page Page 96... -
Page 113: Image Page
DM-F Series Monitor C.4.3 Image Page Figure C-8: Image Page Page 97... -
Page 114: Display Page (For Analog Signal)
DM-F Series Monitor C.4.4 Display Page (for analog signal) Figure C-9: Display Page Page 98... -
Page 115: Color Page
DM-F Series Monitor C.4.5 Color Page Figure C-10: Color Page Page 99... -
Page 116: Pip Page
DM-F Series Monitor C.4.6 PIP Page NOTE: The functions in the PIP page are only available in the MLCD-KIT Series and AFOLUX Series monitors. Figure C-11: PIP Page Page 100... -
Page 117: System Page
DM-F Series Monitor C.4.7 System Page Figure C-12: System Page NOTE: Some of the functions in the System Page are only available to some of the IEI LCD series as following: Auto Brightness: SRM, MLCD-KIT and AFOLUX series only ... -
Page 118: About Page
DM-F Series Monitor C.4.8 About Page Figure C-13: About Page Page 102... -
Page 119: Smartosd Faq
DM-F Series Monitor C.5 smartOSD FAQ For troubleshooting, please see the steps below: C.5.1 Windows 2000 Installation Failure Installation fails under Windows 2000 and shows the following image: Figure C-14: DLL Missing Solution: Download and install service pack Windows Installer 3.1 C.5.2 Vista Installation Failure Installation fail under Vista while showing following image: Figure C-15: Windows Vista Error... -
Page 120: Model Failure
DM-F Series Monitor Solution: Install SmartOSD.exe as the administrator authority Figure C-16: Install as Administrator C.5.3 Model Failure The Model Fail error message shown below appears. Figure C-17: Firmware Incompatibility Solution: SmartOSD only supports firmware version 2.0 and following versions. Page 104... -
Page 121: Ddc Port Failure
DM-F Series Monitor C.5.4 DDC Port Failure The DDC port fail error message shown below appears. Figure C-18: DDC Port Failure Solutions: Check VGA or HDMI cable Check an IEI monitor is being used Make sure the version is version 2.3 for the AFOLUX/MDM series and version 1.5 for the DM/ISDM/TDM/SRM/LCD-KIT series that have the SmartOSD functions ...
Need help?
Do you have a question about the DM-F65A/R-R10 and is the answer not in the manual?
Questions and answers
