Summary of Contents for Squareled Big Five
-
Page 2: Safety Instruction
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 1. Summarization Summarization: Thank you for purchasing our LED PAR64 lighting. Please read these instructions carefully before begin and operate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage. -
Page 3: Outside Size Picture
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 3. outside Size Picture 4. Main Function » high quality LED: low consumption, brightness, stable capability and long life » each color of LED with 16666 grades dimming. The refreshing rate is above 400Hz. Flicker free »... -
Page 4: Dmx Control Function
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 5. DMX Control Function DMX Channel (4CH): channel DMX value Control Function Remarks 0-255 RGB color mixing 0-255 A Dimming 0-100% 0-255 W Dimming 0-100% Color Saturation 0-255 General dimming 0-100% purity... - Page 5 Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 DMX Channel (10 CH): channel DMX value Control Function Remarks Priority 0-255 (General dimming) 0-255 Red dimming 0——100% 0-255 Green dimming 0—100% 0-255 Blue dimming 0—100% 0-255 Amber dimming 0—100% 0-255 White 0——100%...
-
Page 6: Led Display
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 4. Main Function ... -
Page 7: Menu Instruction
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 7. Menu Instruction... - Page 8 Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 1. Operating instruction: MENU (UP/DOWN)+ENTER+(UP/DOWN)+ENTER Remark: Exp: Select the DMX mode, Here are the operation details: » Press the MENU, go back to the initial setting » Press UP/DOWN, display “Addr” »...
-
Page 9: Operating Control Instruction
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 8. Operating Control Instruction Master/Slave: Master: The master should always work as a master as long as it is not set in a DMX mode whatever other modes it is. And it send out the signal so that the slave synchronous with it. To avoid the host signal and DMX512 signals interfere with each other, should cut off the DMX512 signals. -
Page 10: Connecting Picture
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 The Conversion between 3 pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable 10. Connecting picture Light connecting picture:... -
Page 11: Troubleshooting
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 11. Trouble Shooting Problem Checking Way • Check the power source plug is in normal or not Can not turn on the light • Check the switch of the lights is off or on •... -
Page 12: Technical Specification
Manual | Big Five“ PAR-64 18x10W RGBAW 5in1 12. Technical Specification • Lamp Spec:5-in-1 10W, 18PCS • Constant current driver:500MA • PWM Dimmer: 400HZ (16666 steps) • Life span: 50000hours • Control Signal: DMX512, sound activated, auto run • Control mode: stand alone/ sound activated •... - Page 13 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
