Phantom 4 Advanced / Advanced+ User Manual
Smart RTH
Use the RTH button on the remote controller or tap the RTH button in the DJI GO 4 app and follow the on-
screen instructions when GPS is available to initiate Smart RTH. The aircraft will then automatically return
to the last recorded Home Point. Use the remote controller to control the aircraft's speed or altitude to
avoid a collision during the Smart RTH process. As the aircraft returns, it will use the primary camera to
identify obstacles as far as 300m in front, allowing it to plan a safe route home. Press and hold the Smart
RTH button once to start the process, and press the Smart RTH button again to terminate the procedure
and regain full control of the aircraft.
Low Battery RTH
The low battery level failsafe is triggered when the DJI Intelligent Flight Battery is depleted to a point that
may affect the safe return of the aircraft. Users are advised to return home or land the aircraft immediately
when prompted. The DJI GO 4 app will display a notice when a low battery warning is triggered. The
aircraft will automatically return to the Home Point if no action is taken after a ten-second countdown. The
user can cancel the RTH procedure by pressing the RTH button on the remote controller. The thresholds
for these warnings are automatically determined based on the aircraft's current altitude and distance from
the Home Point.
The aircraft will land automatically if the current battery level can only support the aircraft long enough
to descend from its current altitude. The user can still use the remote controller to alter the aircraft's
orientation during the landing process.
The Battery Level Indicator is displayed in the DJI GO 4 app, and is described below:
Critical Low battery level
warning (Red)
Battery Level
Remark
Warning
Low battery Battery power
level warning is low. Land the
aircraft.
Critical Low The aircraft
battery level must land
warning immediately.
16
©
2017 DJI All Rights Reserved.
Sufficient battery
level (Green)
Low battery
level warning (Yellow)
Power requires
to return home
Battery level Indicator
Aircraft Status
Indicator
Tap "Go-home" to have the
aircraft return to the Home
Aircraft status
point and land automatically, or
indicator
"Cancel" to resume normal flight.
blinks RED
If no action is taken, the aircraft
slowly.
will automatically go home and
land after 10 seconds. Remote
controller will sound an alarm.
Aircraft status The DJI GO 4 app display will
indicator flash red and the aircraft will
blinks RED start to descend. The remote
quickly. controller will sound an alarm.
Remaining flight time
12:29
DJI GO 4 App
Flight
Instructions
Fly the aircraft
back and land
it as soon as
possible, then
stop the motors
and replace the
battery.
Allow the
aircraft to
descend
and land
automatically.
