MC-1100 Series
Quick Installation Guide
Version 3.5, April 2024
Technical Support Contact Information
www.moxa.com/support
 2024 Moxa Inc. All rights reserved.
P/N: 1802011000028
*1802011000028*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-1100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moxa Technologies MC-1100 Series

  • Page 1 MC-1100 Series Quick Installation Guide Version 3.5, April 2024 Technical Support Contact Information www.moxa.com/support  2024 Moxa Inc. All rights reserved. P/N: 1802011000028 *1802011000028*...
  • Page 2: Package Checklist

    Oil & Gas field site monitoring, and transportation. The MC-1100 Series comes with hardware monitoring features built in for device I/O status monitoring and alerts, system temperature monitoring and alerts, and system power management. Monitoring system status closely makes it easier to recover from errors and provides the most reliable platform for your applications.
  • Page 3 MC-1121 The following figures show the panel layouts of the MC-1121 Series: Top View Front View Rear View MC-1112 Top View Front View Rear View - 3 -...
  • Page 4: Led Indicators

    MC-1122 Top View Front View Rear View LED Indicators The following table describes the LED indicators located on the front panel of the MC-1100: LED Name Status Description Power Power is ON and computer is Green functioning normally Power is OFF Storage 1 (CFast) Yellow Blinking: Data transmission No data transmission.
  • Page 5: Installing A Wireless Module

    Installing a Wireless Module Both the MC-1121 and MC-1122 models have been provided with a built-in Mini PCIe socket for installing a wireless module. To install a wireless module on your MC-1100 computer, do the following: STEP 1: Loosen the six screws on the right panel and the two screws on the bottom panel.
  • Page 6 STEP 4: Push the wireless module card down. STEP 5: Secure the wireless module card with the 2 screws included in the package. STEP 6: Connect the antenna cable connector to the wireless module card. - 6 -...
  • Page 7: Installing The Mc-1100

    The available connectors are: • Main RF antenna (ANT) • RX Diversity Antenna (DIV) • GNSS Antenna (GPS) STEP 7: Replace the side and bottom covers and secure them with screws. STEP 8: (Optional) You can install external 3G, 4G, and Wi-Fi antennas from Moxa to increase the wireless coverage.
  • Page 8: Installation

    Installation: STEP 1: Use the 4 screws* included with the kit to attach the DIN-rail mounting bracket to the MC-1100’s rear panel and tighten the screws to secure the bracket to the MC-1100. STEP 2: Insert the top of the DIN rail into the slot just below the upper hook of the DIN-rail mounting kit.
  • Page 9: Connector Descriptions

    *The wall-mounting kit brackets require screws with the specifications: Equipment side: Length: 6 mm; diameter: 3 mm. Wall side: Length: 10 mm; diameter: 3 mm. Connector Descriptions Power Connector Use an LPS (12-36 VDC) or Class 2 power cord to connect to the MC-1100's terminal block to power jack converter and then turn on the power.
  • Page 10 MC-1111 MC-1121 MC-1112 MC-1122 WARNING Antenna connectors are NOT FOR USE IN HAZARDOUS LOCATIONS. Terminal Block Terminal block (JP1)—R/C (XCFR2, XCFR8); socket soldered on to the PWB, DINKLE ENTERPRISE CO., LTD, type 2EHDRM, rated 300 V, 15 A, 105°C. Mating with plug type 2RSDAM, 2ESDPM, 2ESDPLM or 2ESDVM, rated 300 V, 15 A, 105°C.
  • Page 11 WARNING The wiring for the input terminal block should be installed by a skilled person. • Wire Type: Cu • Wire Size: 12 to 24 AWG (3.31 to 0.21 mm2) • Torque Value: 0.5 N-m (4.4253 lb-in) Ethernet Ports The 10/100/1000 Mbps Ethernet ports use RJ45 connectors. 10/100 Mbps 1000 Mbps ETx+...
  • Page 12 DI/DO The MC-1100 is provided with a 2 x 5 terminal block that has 4 digital inputs and 4 digital outputs. The DI/DO terminal block is suitable for: Wire Size: 16 to 28 AWG (1.31 to 0.081 Recommend stripping 7 to 8 mm of the wire and securing it with the screws in the plug.
  • Page 13 ATTENTION This equipment is suitable for use in Class I Division 2, Groups A, B, C, and D or non-hazardous locations only. ATTENTION These devices are open-type devices that are intended to be used in a Restricted Access Location, such as a dedicated computer room, where access can only be gained by SERVICE PERSONS or by USERS who have been instructed about the fact that the metal chassis of the equipment is extremely hot and...
  • Page 14 BSMI Certification for Taiwan 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 嵌入式計算機 型號(型式): MC-1122-E4-TPM-T (及其系列型號) Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Unit Hexavalent Polybrominat Polybrominated...
  • Page 15 Note 3: The “−” indicates that the restricted substance corresponds to the exemption. 警告 未避免電磁干擾,本產品不應安裝或使用於住宅環境。 警告 如果更換不正確之電池型式會有爆炸的風險, 請依製造商說明書處理用過之電池。 注意 本手冊內提及的所有電信終端功能目前不提供予台灣市場, 若需要更多資訊請與 Moxa 聯繫。 製造商資訊: Moxa 四零四科技股份有限公司 +886-3-2737575 桃園市八德區和平路 1111 號 產品型號: MC-1122-E2-T MC-1122-E4-T MC-1122-E4-TPM-T - 15 -...
