Moxa Technologies UC-8100 Series Hardware User Manual
Hide thumbs
Also See for UC-8100 Series:
- Quick installation manual (2 pages) ,
- Quick installation manual (9 pages)
Related Manuals for Moxa Technologies UC-8100 Series
Summary of Contents for Moxa Technologies UC-8100 Series
- Page 1 UC-8100 Series Hardware User’s Manual Edition 3.1, September 2018 www.moxa.com/product © 2018 Moxa Inc. All rights reserved.
- Page 2 UC-8100 Series Hardware User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2018 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................1-1 Overview ............................1-2 Model Descriptions ..........................1-2 Package Checklist ..........................1-2 Hardware Specifications ........................1-2 Hardware Block Diagram ........................1-3 Hardware Introduction........................2-1 Appearance ............................2-2 LED Indicators ............................ 2-3 Default Programmable Button Operations ....................2-4 Diagnosing Device and Subsystem Failures .................. -
Page 4: Introduction
Introduction The UC-8100 series computing platform is designed for embedded data acquisition applications. The computer comes with one or two RS- 232/422/485 serial ports and dual 10/100 Mbps Ethernet LAN ports, as well as a Mini PCIe socket to support cellular modules. These versatile communication capabilities let users efficiently adapt the UC-8100 computers to a variety of complex communications solutions. -
Page 5: Overview
Introduction Overview The UC-8100 Series is built around an ARMv7 Cortex-A8 RISC processor that has been optimized for use in energy monitoring systems, but is widely applicable to a variety of industrial solutions. With flexible interfacing options, this tiny embedded computer is a reliable and secure gateway for data acquisition and processing at field sites as well as a useful communication platform for many other large-scale deployments. -
Page 6: Hardware Block Diagram
UC-8100 Series Introduction Hardware Block Diagram... -
Page 7: Hardware Introduction
The LED indicators allow users to monitor performance and identify trouble spots quickly, and the multiple ports can be used to connect a variety of devices. The UC-8100 Series comes with a reliable and stable hardware platform that lets you devote the bulk of your time to application development. In this chapter, we provide basic information about the embedded computer’s hardware and its various components. -
Page 8: Appearance
UC-8100 Series Hardware Introduction Appearance Front View Top & Bottom Views Bottom... -
Page 9: Led Indicators
UC-8100 Series Hardware Introduction Dimensions [units: mm (in)] LED Indicators Refer to the following table for information about each LED. LED Name Color Function Steady On USB device is connected and working normally Green USB device is not connected. Steady On... -
Page 10: Default Programmable Button Operations
UC-8100 Series Hardware Introduction Default Programmable Button Operations The push button is used to diagnose device failure or to perform firmware restoration. After depressing the button, release it at the appropriate time to enter the desired mode to either diagnose your device or restore your device to the default configuration. -
Page 11: Reset To Default Button
UC-8100 Series Hardware Introduction Reset to Default Button Press and hold the Reset Button continuously for at least 5 seconds to load the factory default configuration. After the factory default configuration has been loaded, the system will reboot automatically. The Ready LED will blink on and off for the first 5 seconds, and then maintain a steady glow once the system has rebooted. -
Page 12: Wall Or Cabinet Mounting
UC-8100 Series Hardware Introduction Wall or Cabinet Mounting Pull out both the top and bottom sliders and align the screws accordingly. Another method for wall mounting installation is to use the optional wall mounting kit. Attach two mounting brackets on the side panel of the computer, and fasten with screws. Install the computer on a wall or cabinet by fastening two screws for each bracket. -
Page 13: Hardware Connection Description
Hardware Connection Description This section describes how to connect the UC-8100 to a network and various devices for first time testing purposes. The following topics are covered in this chapter: Wiring Requirements Connecting the Power Grounding the Unit ... -
Page 14: Wiring Requirements
UC-8100 Series Hardware Connection Description Wiring Requirements In this section, we describe how to connect various devices to the embedded computer. You should heed the following common safety precautions before proceeding with the installation of any electronic device: • Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the intersection point. -
Page 15: Connecting To The Console Port
UC-8100 Series Hardware Connection Description SG: The Shielded Ground (sometimes called Protected Ground) contact is the bottom contact of the 3-pin power terminal block connector when viewed from the angle shown here. Connect the SG wire to an appropriate grounded metal surface. -
Page 16: Connecting To A Serial Device
UC-8100 Series Hardware Connection Description Connecting to a Serial Device Use properly wired serial cables to connect the UC-8100 to serial devices. The serial ports of the UC-8100 use the 5-pin terminal block. The ports can be configured by software for RS-232, RS-422, or 2-wire RS-485. The... -
Page 17: Installing The Cellular/Wi-Fi Module
UC-8100 Series Hardware Connection Description Installing the Cellular/Wi-Fi Module The UC-8100 provides an mPCIe socket for installing a cellular/Wi-Fi socket. Follow these steps: 1. Remove the screws on the side panel, and take off the cover. 2. Find the location of the PCIe socket. Insert the cellular module into the socket, and then tighten the screws to fasten the socket. - Page 18 UC-8100 Series Hardware Connection Description 4. Plug the other end of the cable into the connector on the front panel of the UC-8100. Remove the black plastic cover first. 5. Install the connector; place the locking washer first, and then tighten the nut.
-
Page 19: Regulatory Approval Statements
Regulatory Approval Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
