- Page 1 MRX-G4064/MRX-Q4064 Series Quick Installation Guide Version 1.0, April 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N:1802040640010 *1802040640010*...
-
Page 2: Package Checklist
Package Checklist The Moxa MRX-G4064/MRX-Q4064 industrial rackmount switch is shipped with the following items. If any of these items are missing or damaged, please contact your customer service representative for assistance. • 1 x MRX-G4064/MRX-Q4064 switch • 2 x Rack-mounting ears •... - Page 3 1. LCM interface 12. Power input 1 for 110/220 2. System status LEDs VDC/VAC 3. LCM button 13. Dust cover 4. Console port (RS-232, RJ45) 14. Power cord retainer aperture 5. MGMT port (OOBM) 15. Upper Fan modules 6. Module 3 socket 16.
-
Page 4: Wiring Requirements
XM-4000 Ethernet Interface Modules XM-4000-16GTX XM-4000-16QGTX XM-4000-16GSFP XM-4000-16QGSFP NOTE MRX-G4064 series doesn't support 2.5GbE modules. WARNING When end users are using Optical SFP Communications modules, these must be limited to Laser Class 1. WARNING Use of the controls or adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure. - Page 5 Before completing installation, make sure the ground wire is connected. WARNING Do not disconnect modules or wires unless power has been switched off or the area is known to be non-hazardous. The device may only be connected to the supply voltage shown on the type plate.
-
Page 6: Installing And Removing Power Modules
To remove an Ethernet module: 1. Loosen the 2 screws of the module. 2. Pull the module out of the slot. 3. Secure the cover plate over the slot to improve protection against dust and EMI. 4. Fasten the cover plate using 2 screws. The tightening torque is 4 kgf-cm (0.4 Nm). - Page 7 Caution Shock hazard! Disconnect all power cords from unit before changing modules. Installing and Replacing Fan Modules The fan modules are hot-swappable. You have the option to install or replace the fan modules while the device is operating. NOTE Do not delay replacing fan modules after removal, otherwise the device may overheat.
-
Page 8: Cooling System
ATTENTION Fan modules require periodic maintenance (minimum yearly) to maintain the longevity of MRX devices. Cooling system XM-4000-FAN-R and PWR-300-HVA-IF provide ventilation to prevent the device overheating. The airflow is from front to rear. Hot air Cold air The MRX-G4064/MRX-Q4064 series supports fan modules with 6+2 redundancy level (active-active type). -
Page 9: Usb Connection
WARNING When wiring the relay contacts, we suggest using the cable type - AWG (American Wire Gauge) 16-21 (1.31-0.42 mm and the corresponding pin terminals. Wiring should be copper and rated for at least 105°C. USB Connection Use Moxa’s USB Automatic Backup Configurator ABC-02- USB to connect to the USB host port to backup and restore configuration files, auto-load configuration files, upgrade firmware, and backup system log files. -
Page 10: Led Indicators
Follow these steps to install the stickers. 1. Use a cloth to clean the surface of the screws with a 75% alcohol solution. 2. Carefully align the stickers. Use of tweezers is recommended. 3. Press the stickers down firmly (15 PSI) for at least 15 seconds. 4. - Page 11 Color State Description 1. The switch is the Master of Turbo Ring 2. The switch is the PRL owner of ERPS in a major ring domain and in idle state 1. The switch is set as the Master of Turbo Ring and the ring is broken (MSTR/ Green 2.
- Page 12 Color State Description Port active with 10Gbps link Green Blinking Activity at 10Gbps SFP+ Port inactive or link down (1G/ Port active with links at less than 2.5G/ 10Gbps 10G) Amber Blinking Activity at less than 10Gbps When the port is inactive or link down LEDs for XM-4000 Modules XM-4000-16GTX Color...
-
Page 13: Specifications
Port inactive or link down Specifications Ethernet Interface Pre-installed MRX-G4064-L3-8XG: 8 embedded 1GbE SFP slots Modules and 8 embedded 10GbE SFP+ slots MRX-Q4064-L3-16XG: 16 embedded 10GbE SFP+ slots Module 3 slots for optional Gigabit or 2.5GbE Ethernet ports or SFP 16-port modules Standards IEEE 802.3ae for 10 Gigabit Ethernet IEEE 802.3bz for 2.5GBaseX... -
Page 14: Supported Sfp Modules
Max. 284.3 W @ 300 VDC Physical Characteristics IP Rating IP30 Dimensions 440 x 88 x 420 mm Weight MRX-G4064/ Q4064: 12 kg (26 lb) XM-4000-16GTX/ 16QGTX: 0.7 kg (1.4 lb) XM-4000-16GSFP/ 16QGSFP: 0.5 kg (1.2 lb) XM-4000-FAN models: 0.1 kg (0.2 lb) PWR-300 models: 0.7 kg (1.6 lb) Installation Rack mounting... - Page 15 Module Description SFP-1G20BLC WDM-type (BiDi) SFP module with 1 1000BaseSFP port with LC connector for 20 km transmission; TX 1550 nm, RX 1310 nm, 0 to 60°C operating temperature SFP-1G40ALC WDM-type (BiDi) SFP module with 1 1000BaseSFP port with LC connector for 40 km transmission; TX 1310 nm, RX 1550 nm, 0 to 60°C operating temperature SFP-1G40BLC...
- Page 16 Module Description SFP-1GSXLC SFP module with 1 1000BaseSX port with LC connector for 300m/550m transmission, 0 to 60°C operating temperature SFP-1GZXLC SFP module with 1 1000BaseZX port with LC connector for 80 km transmission, 0 to 60°C operating temperature SFP-1GLHLC-T SFP module with 1 1000BaseLH port with LC connector for 30 km transmission, -40 to 85°C operating temperature...
-
Page 17: Rack Mounting Instructions
Rack Mounting Instructions 1. Ambient Operating Temperature: If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tam) specified by the manufacturer. - Page 18 6. Power Source: Equipment with DC power inputs is intended to be supplied by DC power, separated from AC mains by double or reinforced insulation. ATTENTION When installing the device onto a rack, make sure that the input terminal block and protective terminal do not connect, or it may cause an electric shock.
- Page 19 NOTE This device is intended for indoor use only, at • altitudes of up to 5,000 meters above sea level. Overvoltage category II • Pollution degree 2 • NOTE To preserve device label integrity and legibility, wipe with a dry cloth only.
