ASSEMBLY INSTRUCTIONS FOR SIDE
BLOWER CONFIGURATION KIT
Verified and tested for Canada and
the United States by an accredited
laboratory.
Eco-energy at the hearth
of your home
PA08587
CADDY ADVANCED CR FURNACE
This manual is available for free download on the
manufacturer's web site. It is a copyrighted document. Re-
sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for
problems, injuries, or damages arising out of the use of
information contained in any manual obtained from
unauthorized sources.
250, Copenhague street,
St-Augustin-de-Desmaures (Québec)
CANADA G3A 2H3
PSG
46368A
2024-03-14
Advertisement
Related Manuals for PSG Caddy PA08587
Summary of Contents for PSG Caddy PA08587
- Page 1 ASSEMBLY INSTRUCTIONS FOR SIDE BLOWER CONFIGURATION KIT PA08587 CADDY ADVANCED CR FURNACE This manual is available for free download on the manufacturer’s web site. It is a copyrighted document. Re- Verified and tested for Canada and sale is strictly prohibited. The manufacturer may update this the United States by an accredited manual from time to time and cannot be responsible for laboratory.
- Page 2 1. INTRODUCTION Your Caddy furnace can be fitted with a side-mounted blower configuration kit. Note that installation can be done on either side of the furnace. Installation must be carried out by a qualified professional. ALWAYS DISCONNECT THE POWER SUPPLY IF A CONNECTION IS TO BE MADE WITH OPTION PA01106 - ELECTRIC ELEMENT.
- Page 3 3. INSTALLING THE PA08587 BLOWER SIDE KIT 1. Remove the bottom decorative panel on the desired side by removing its 4 plastic rivets 31366. Use a flathead screwdriver to pry the rivet head away from the washer. See photos below. Set the plastic rivets aside.
- Page 4 2. Remove the bottom panel of the furnace by unscrewing the metal screws 31048. Set aside the metal screws. 3. Screw on the adapter to connect the blower duct extension, using the 31048 metal screws previously set aside. 46368A 2024-03-14...
- Page 5 4. Remove the wire cover and junction cover unscrewing metal screws 31048. Set aside the metal screws. 5. Cut off the corner of the wire cover (!) on the side where the blower extension will be. 46368A 2024-03-14...
- Page 6 6. Remove the rear connector from the furnace by unscrewing the metal screws 31048. The cover can be recycled. Set aside the metal screws. 7. Secure the furnace back panel in place using the 9 metal screws 31048 previously set aside. 46368A 2024-03-14...
- Page 7 11. Attach the deflector (!) to the blower housing using 9 metal screws. FAILURE TO DO SO MAY RESULT IN DAMAGE TO YOUR FURNACE. PSG accepts no responsibility or liability if this condition is not met. 12. Secure the blower housing to the side duct using 10 - 31048 metal screws.
- Page 8 CAUTION! FOR REGULAR INSTALLATION 13. Secure the blower housing to the side duct using 10 - 31048 metal screws. 14. Make sure that the bottom lip of the blower housing fits over the edge of the duct (!). 15. Remove the 2 remaining decorative side panels by removing the 4 plastic rivets (each) 31366.
- Page 9 16. Pass the blower extension between the blower housing and the main circuit board. Refer to the pictures to find out how and where to fit the extension lead. 46368A 2024-03-14...
- Page 10 17. Connect the blower to the extension lead (Detail A). If the ECM, PA08582, blower is used, connect the insulated 1/4" connector (!). 18. Connect the furnace circuit board to the blower extension cable (Detail B). If the PA08582 ECM blower is used, connect the insulated 1/4"...
- Page 11 19. Using 2 self-tapping 30163 screws, attach the conduit to conceal the fan extension. WARNING: Make sure the metal tab (!) is tucked under the "bridge" of the wiring conduit. 46368A 2024-03-14...
- Page 12 20. Install the grommet a top the duct and center it so as to hide the fan extension. Use 4 metal screws 31048. 21. OPTIONAL: Remove the hachured area (!) if the electrical element PA01106 is also installed. Caution, be careful not to pinch any wires! 22.
- Page 13 23. Unscrew the panel on top of the blower and position it on the side as shown. Screw back into place. 24. Install the filter support a top the blower. (Where the panel used to be.) Secure with 30154 machine screws.
- Page 14 28. Replace the middle and top decorative panels on the side of the furnace, using 4 plastic rivets 31366 for each panel. 46368A 2024-03-14...
- Page 15 29. Replace the wire and junction box covers. Use metal screws 31048 previously set a side. 46368A 2024-03-14...
- Page 16 PSG will not be held responsible failure to comply with this condition. Make sure that the bottom lip of the blower housing fits over the edge of the duct.
- Page 17 30. Install the electrical unit (!) board housing by removing its cover and using 4 self-tapping 30163 screws. The housing is positioned using the 4 recesses in the metal. See photo. 31. Make sure the opening in the wire housing (!!) has been cut.
- Page 18 34. Replace the junction box cover on the electrical unit's circuit board, using the 4 metal screws 31048 previously set aside. (Not shown) 35. Replace the decorative panels on the side of the furnace using plastic rivets 31366. 36. Remove the knockout on the left and insert a plastic connector (not...
- Page 19 CAUTION: ALWAYS TURN OFF THE CIRCUIT BREAKER WHEN INSTALLING THE ELECTRICAL ELEMENT WIRING. ** Run the high-voltage wire as shown. FOR FURTHER DETAILS, PLEASE REFER TO THE PA01106 ELECTRICAL ELEMENT MANUAL. 46368A 2024-03-14...
