SIDE EXTENSION FOR ANGLED SUPPORT FOR CADDY
WARNING: THIS ACCESSORY IS MANDATORY FOR THE INSTALLATION OF GAZ FURNACE
ON THE LEFT SIDE OF CADDY ADVANCED CR.
Verified and tested for Canada and the
United States by an accredited
laboratory.
Eco-energy
hearth
of your home
Printed in Canada
ADVANCED CR FURNACE
PA08589
at
the
This manual is available for free download on the
manufacturer's web site. It is a copyrighted document. Re-sale
is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for
problems, injuries, or damages arising out of the use of
information
contained
unauthorized sources
250, Copenhague street,
St-Augustin-de-Desmaures (Québec)
CANADA G3A 2H3
in
any
manual
obtained
PSG
2024-07-10
from
46393A
Advertisement
Related Manuals for PSG Caddy PA08589
Summary of Contents for PSG Caddy PA08589
- Page 1 SIDE EXTENSION FOR ANGLED SUPPORT FOR CADDY ADVANCED CR FURNACE PA08589 WARNING: THIS ACCESSORY IS MANDATORY FOR THE INSTALLATION OF GAZ FURNACE ON THE LEFT SIDE OF CADDY ADVANCED CR. This manual is available for free download on the manufacturer’s web site. It is a copyrighted document. Re-sale Verified and tested for Canada and the is strictly prohibited.
- Page 2 1. Kit content SE66365 – Side duct extension (1x) 31048 – Metal Screw (15x) 31389 – Wire clip (2x) 30163 – Auto-tapping screw (4x)
- Page 3 2. Installation of the angled support PA08555 onto the Caddy Advanced CR furnace Warning: If the installation is to be on the left side on the furnace, the support must be installed with the extension PA08589 (!) to allow enough space to access the thermocouples for maintenance purposes SBI DISCLAIMS ALL RESPONSIBILITY IF THIS INSTRUCTIONS ARE NOT FOLLOWED.
- Page 4 Install the adapter PL66370. Use the metal screws 31048 previously removed to fix the adapter. NOTE : This adapter comes from the PL66370 kit!
- Page 5 3. Fix the extension PA08589 on the adapter using metal screw 31048. BE CAREFUL NOT TO SCREW INTO THE SMALL ROND HOLES BUT RATHER THE PASSAGE HOLES (BIGGER). (!) Don’t forget to also put the screws in the inside part of the extension (!!)
- Page 6 4. Final result should look like the following picture 5. To install the gas unit you may continue using the dedicated instructions manual for those kits.
