Communications Interface - BENDIX Intellipark Service Data

Dash Electronic Control Unit (DECU): J2 Connector Pin Assignments
(Non-Towing DECU Variant)
Parameter
1 GND_2
2 NC
3 NC
4 NC
5 NC
6 CAN2_LO
7 NC
8 CAN2_HI
9 NC
10 NC
11 NC
12 NC
13 NC
14 VBATT_2

COMMUNICATIONS INTERFACE

CAN1
The DECU provides support for a CAN transceiver. CAN
1 is intended for use on the vehicle J1939 bus. It can be
configured for either 250 kbps or 500 kbps operation.
CAN2
A second DECU CAN channel, designated CAN 2, is also
available. It can be configured for either 250 kbps or 500
kbps operation.
Value
Ground
No contact
No contact
No contact
No contact
CAN2 low
No contact
CAN2 high
No contact
No contact
No contact
No contact
No contact
Battery input 2
Unit
59
