BENDIX Intellipark Service Data page 24

SPN FMI
3510 3 Internal ECU Issue
SPN3510 FMI3
3510 4 Internal ECU Issue
SPN3510 FMI4
3511 2 J1939 DC1, CM1 or
BDS Message - Erratic,
Intermittent, or Incorrect
(Seat Belt or Door)
3511 3 Occupancy Sensor 1
- J1 Pin 5/6 Shorted to
Voltage
3511 4 Occupancy Sensor 1
- J1 Pin 5/6 Shorted to
Ground
3511 5 Occupancy Sensor 1 - J1
Pin 5/6 Open Circuit
3511 7 J1939 DC1, CM1, or
BDS Message - Not
Responding Properly or
Timeout (Seat Belt or
Door)
Table 6 – Diagnostic Trouble Codes (DTCs)
24
Description
Trailer pressure sensor
supply wire reporting shorted
to a high source
Trailer pressure sensor
supply wire reporting shorted
to ground
DC1, CM1, or BDS message
not received when expected
or received with error
Hardwired interlock 1 short
to a high source
Hardwired interlock 1 short
to ground
Hardwired interlock 1
disconnected
DC1, CM1, or BDS Message
not received when expected
or received with error
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Verify the trailer pressure sensor
is wired correctly, J2 Pins 2-4 to
trailer pressure sensors on valve
assembly.
Check for damage/shorts on the
ground and supply wire, 21 Pin
2/3 to trailer pressure sensor Pin
2/3.
This DTC should resolve once
the cause is addressed.
Verify the tractor pressure sensor
is wired correctly, J1 Pins 2-4 to
tractor pressure sensors on valve
assembly.
Check for damage/shorts on the
ground and supply wire, J1 Pin
2/3 to tractor pressure sensor Pin
2/3.
This DTC should resolve once
the cause is addressed.
Contact OEM for details on the
source of the message and fix.
This DTC should resolve once
the cause is addressed.
Check resistance in occupancy
sensor wires (J1 Pin 5/6) match.
Check for damage or shorts
from J1 Pins 5/6 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Check resistance in occupancy
sensor wires (J1 Pin 5/6) match.
Check for damage or shorts
from J1 Pins 5/6 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Check resistance in occupancy
sensor wires (J1 Pin 5/6) match.
Check for damage or shorts
from J1 Pins 5/6 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Contact OEM for details on the
source of the message and fix.
This DTC should resolve once
the cause is addressed.
