BENDIX Intellipark Service Data page 52

SPN FMI
516148 2 J1939 CAN2 Engine
Node - Erratic,
Intermittent, or Incorrect
516149 12 Internal ECU Issue
SPN516149 FMI12
516150 2 External Park/Unpark
Request Inhibit Unpark
Erratic, Intermittent, or
Incorrect - ECU DTC
(89_11)
516151 2 J1939 AIR1 Message -
Erratic, Intermittent, or
Incorrect
516152 2 Reservoir Pressure -
Erratic, Intermittent, or
Incorrect
516153 2 External Park/Unpark
Request Inhibit Park
Erratic, Intermittent, or
Incorrect - ECU DTC
(83_11)
516154 2 J1939 CAN Stop
Lamp Switch - Erratic,
Intermittent, or Incorrect
Table 6 – Diagnostic Trouble Codes (DTCs)
52
Description
Loss of CAN messages
Continuous voltage issue or
ECU damage
XPURT CAN data not
received when expected or
received with error
AIR1 CAN data not received
when expected or received
with error
Reservoir CAN data not
received when expected or
received with error
XPURT CAN data not
received when expected or
received with error
Stop Lamp Switch message
CAN data not received when
expected or received with
error
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Verify there are no open wires or
shorts on the 2 CAN inputs, Pins
13/15 on J1 and Pins 6/8 on J2
connector.
Verify the 2 CAN inputs have
terminating resistors at the DECU
side and at the backbone.
Verify the engine is broadcasting
for the source address 00 on
CAN bus that Intellipark is
connected to when the vehicle is
keyed on.
This DTC should resolve once
the CAN data is received from
SA 0B.
Verify the battery voltage is in the
nominal range of approximately
14V.
Once the battery is fully charged,
battery cycle the ECU.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed. If the
DTC persists, replace the ECU.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
