BENDIX Intellipark Service Data page 21

SPN FMI
168 3 Battery Voltage Above
Normal, J1 Pin 18/1 and
J2 Pin 14/1
168 4 Battery Voltage Below
Normal, J1 Pin 18/1 and
J2 Pin 14/1
190 2 J1939 EEC1 Message
- Erratic, Intermittent, or
Incorrect (Engine Speed)
190 7 J1939 EEC1 Message
- Data Not Available
(Engine Speed)
190 19 J1939 EEC1 Message -
Error (Engine Speed)
523 2 J1939 ETC2 Message
- Erratic, Intermittent, or
Incorrect (Transmission
Current Gear)
524 2 J1939 ETC2 Message
- Erratic, Intermittent, or
Incorrect (Transmission
Select Gear)
619 12 J1939 CAN Transmission
Fault, J1 Pin 13 and 15
shorted
Table 6 – Diagnostic Trouble Codes (DTCs)
Description
Battery voltage is under 9v
Battery voltage is under 9v
Engine speed CAN data not
received when expected or
received with error
Engine speed CAN data not
received when expected or
received with error
Engine speed CAN data not
received when expected or
received with error
Transmission CAN data not
received when expected or
received with error
Transmission CAN data not
received when expected or
received with error
Intellipark unable to
broadcast on CAN network
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check battery voltage; if low,
charge battery.
Check battery connections from
J1 Pin 18/1 and J2 Pin 14/1
to fuse panel for open or bad
connections.
Check fuse panel for blown
fuses.
This DTC should resolve once
the cause is addressed.
Check battery voltage; if low,
charge battery.
Check battery connections from
J1 Pin 18/1 and J2 Pin 14/1
to fuse panel for open or bad
connections.
Check fuse panel for blown
fuses.
This DTC should resolve once
the cause is addressed.
Contact engine manufacturer or
OEM for details on the source of
the message and fix.
This DTC should resolve once
the cause is addressed.
Contact engine manufacturer or
OEM for details on the source of
the message and fix.
This DTC should resolve once
the cause is addressed.
Contact engine manufacturer or
OEM for details on the source of
the message and fix.
This DTC should resolve once
the cause is addressed.
Contact engine manufacturer or
OEM for details on the source of
the message and fix.
This DTC should resolve once
the cause is addressed.
Contact engine manufacturer or
OEM for details on the source of
the message and fix.
This DTC should resolve once
the cause is addressed.
Check high and low CAN wires,
J1 Pin 13 and 15, and the CAN
backbone connections for a short
to ground, power, or each other.
This DTC should resolve once
the cause is addressed.
