BENDIX Intellipark Service Data page 58

DECU: J1 Connector Pin Assignments
(Towing and Non-Towing Dash Electronic Control Unit - DECU - Variants)
Pin
1 GND_1
2 PS_GND
3 PU_PS_SPL
4 PU_PS_SIG_1
5 OCC_SEN_GND
6 OCC_SEN_1
7 OCC_SEN_GND
8 PU_SOL_EXH
9 NC
10 PU_SOL_COM
11 NC
12 PU_SOL_DEL
13 J1939_LO
14 SLS
15 J1939_HI
16 OCC_SEN_2
17 VIGN
18 VBATT_1
DECU: J2 Connector Pin Assignments
(Towing DECU Variant)
Parameter
1 GND_2
2 PS_GND
3 TU_PS_SPL
4 TU_PS_SIG_1
5 NC
6 CAN2_LO
7 TU_SOL_EXH
8 CAN2_HI
9 TU_SOL_COM
10 NC
11 TU_SOL_DEL
12 NC
13 NC
14 VBATT_2
58
Name
Ground
PVM pressure sensor supply ground
PVM power vehicle pressure sensor supply (5V)
PVM power vehicle pressure sensor signal 1
Driver occupancy sensor 1 ground
Driver occupancy sensor 1
Driver occupancy sensor 2 ground
PVM power vehicle park brake exhaust solenoid
No contact
PVM power vehicle solenoid common
No contact
PVM power vehicle park brake deliver solenoid
CAN1 low
Stop lamp switch input
CAN1 high
Driver occupancy sensor 2
Ignition input
Battery input 1
Value
Ground
PVM pressure sensor supply ground
PVM towed vehicle pressure sensor supply (5V)
PVM towed vehicle pressure sensor signal 1
No contact
CAN2 low
PVM towed vehicle park brake exhaust solenoid
CAN2 high
PVM towed vehicle solenoid common
No contact
PVM towed vehicle park brake deliver solenoid
No contact
No contact
Battery input 2
Description
Unit
