BENDIX Intellipark Service Data page 32

SPN FMI
516102 4 Tractor Park Brake
Deliver Valve - J1 Pin 12
Shorted to Ground
516102 5 Tractor Park Brake
Deliver Valve - J1 Pin 12
Open Circuit
516103 2 Trailer Park Brake
Exhaust Valve - J2 Pin 7
Harness Related Fault
Table 6 – Diagnostic Trouble Codes (DTCs)
32
Description
Tractor deliver wire short to
ground or low source
Tractor deliver wire open
circuit
Trailer exhaust wire noise or
short to another source
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check Pin 12 on DECU J1
connector for short to ground; if
an issue is found, re-pin at that
location.
Check Pin 3 on the tractor
solenoid connector for short to
ground source; if an issue is
found, re-pin at that location.
Check the connections between
Pin 12 DECU J1 connector to
Pin 3 on the tractor solenoid
connector; re-pin if a short to
ground is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 12 on DECU J1
connector for being disconnected
or loose; if a poor connection is
found, re-pin at that location.
Check Pin 3 on the tractor
solenoid connector for being
disconnected or loose; if a poor
connection is found, re-pin at that
location.
Check the connections between
Pin 12 DECU J1 connector to
Pin 3 on the tractor solenoid
connector; re-pin if an issue is
found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 7 on DECU J2
connector for short to or bad
connection; if an issue is found,
re-pin at that location.
Check Pin 1 on the trailer
solenoid connector for short or
bad connection; if an issue is
found, re-pin at that location.
Check the connections between
Pin 7 DECU J2 connector to
Pin 1 on the trailer solenoid
connector; re-pin if a short or bad
connection is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
