BENDIX Intellipark Service Data page 31

SPN FMI
516101 5 Tractor Park Brake
Exhaust Valve - J1 Pin 8
Open Circuit
516102 2 Tractor Park Brake
Delivery Valve - J1 Pin
12 Harness Related Fault
516102 3 Tractor Park Brake
Deliver Valve - J1 Pin 12
Shorted to Battery
Table 6 – Diagnostic Trouble Codes (DTCs)
Description
Tractor exhaust wire open
circuit
Tractor deliver wire noise or
short to another source
Tractor deliver wire short to
battery or high source
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check Pin 8 on DECU J1
connector for being disconnected
or loose; if a poor connection is
found, re-pin at that location.
Check Pin 1 on the tractor
solenoid connector for being
disconnected or loose; if a poor
connection is found, re-pin at that
location.
Check the connections between
Pin 8 DECU J1 connector to
Pin 1 on the tractor solenoid
connector; re-pin if an issue is
found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 12 on DECU J1
connector for short to or bad
connection; if an issue is found,
re-pin at that location.
Check Pin 3 on the tractor
solenoid connector for short or
bad connection; if an issue is
found, re-pin at that location.
Check the connections between
Pin 12 DECU J1 connector to
Pin 3 on the tractor solenoid
connector; re-pin if a short or bad
connection is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 12 on DECU J1
connector for short to a high
source; if an issue is found, re-
pin at that location.
Check Pin 3 on the tractor
solenoid connector for short to a
high source; if an issue is found,
re-pin at that location.
Check the connections between
Pin 12 DECU J1 connector to
Pin 3 on the tractor solenoid
connector; re-pin if a short to a
high source is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
