BENDIX Intellipark Service Data page 20

TROUBLESHOOTING - DIAGNOSTIC MODES
If the Bendix Intellipark
®
system is powered and is faulted, the inner LEDs will
blink. Loss of features is communicated through either
the vehicle instrument cluster or a standalone integrated
display. Diagnostic information is available by interfacing
with the Intellipark EPB system using the Bendix
Diagnostic Software.
ACom is a PC-based program that is designed to meet
RP 1210 industry standards developed by the Truck
Maintenance Council (TMC). This software provides the
technician with access to all available Intellipark controller's
diagnostic information and configuration capability,
including:
• Electronic Control Unit (ECU) information
• Diagnostic Trouble Codes (DTCs) and repair
information
Refer to Table 6 for the corrective action once the cause
of the fault is identified.
SPN FMI
84 2 J1939 CCVS1 Message
- Erratic, Intermittent, or
Incorrect (Wheel-Based
Vehicle Speed)
84 7 J1939 CCVS1 Message
- Data Not Available
(Wheel Based-Vehicle
Speed)
84 19 J1939 CCVS1 Message
- Error (Wheel-Based
Vehicle Speed)
91 2 J1939 EEC2 Message
- Erratic, Intermittent, or
Incorrect (Accelerator
Pedal Position)
91 7 J1939 EEC2 Message -
Not Responding Properly
(Accelerator Pedal
Position)
91 19 J1939 EEC2 Message -
Data Error (Accelerator
Pedal Position)
Table 6 – Diagnostic Trouble Codes (DTCs)
20
Electronic Parking Brake (EPB)
®
Description
ACom
® ®
Cause
Wheel-based vehicle speed
CAN data not received when
expected or received with
error
Wheel-based vehicle speed
CAN data not received when
expected or received with
error
Wheel-based vehicle speed
CAN data not received when
expected or received with
error
Accelerator pedal position
CAN data not received when
expected or received with
error
Accelerator pedal position
CAN data not received when
expected or received with
error
Accelerator pedal position
CAN data not received when
expected or received with
error
Corrective Action
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
• Contact OEM for details on the
source of the message and fix.
• This DTC should resolve once
the cause is addressed.
