BENDIX Intellipark Service Data page 25

SPN FMI
3511 12 Occupancy Sensor 1
Fault J1 Pin 6 and 5
3511 19 J1939 Interlocks
Message or Hardwired
Input Implausible -
(Occupancy Sensor 1)
3512 2 J1939 DC1, CM1 or
BDS Message - Erratic,
Intermittent, or Incorrect
(Seat Belt or Door)
3512 3 Occupancy Sensor 2 -
J1 Pin 7/16 Shorted to
Voltage
3512 4 Occupancy Sensor 2 -
J1 Pin 7/16 Shorted to
Ground
3512 5 Occupancy Sensor 2 - J1
Pin 7/16 Open Circuit
3512 7 J1939 DC1, CM1, or
BDS Message - Not
Responding Properly or
Timeout (Seat Belt or
Door)
Table 6 – Diagnostic Trouble Codes (DTCs)
Description
Excess noise or invalid
signal provided from the
hard wired input
Interlock continuously
reporting not satisfied
DC1, CM1, or BDS message
not received when expected
or received with error
Hardwired interlock 2 short
to a high source
Hardwired interlock 2 short
to ground
Hardwired interlock 2
disconnected
DC1, CM1, or BDS message
not received when expected
or received with error
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check resistance in occupancy
sensor wires (J1 Pin 5/6) match.
Check for damage or shorts
from J1 Pins 5/6 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Check interlocks for your
vehicle in owners manual; verify
operation by testing ability to
unpark when it is and is not
satisfied.
Contact OEM for details on the
source of the CAN message and
fix.
This DTC should resolve once
the cause is addressed.
Contact OEM for details on the
source of the message and fix.
This DTC should resolve once
the cause is addressed.
Check resistance in occupancy
sensor wires (J1 Pin 7/16) match.
Check for damage or shorts
from J1 Pins 7/16 to the resistor
network located in the doors or
seat belts.
Check resistance in occupancy
sensor wires (J1 Pin 7/16) match.
Check for damage or shorts
from J1 Pins 7/16 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Check resistance in occupancy
sensor wires (J1 Pin 5/6) match.
Check for damage or shorts
from J1 Pins 7/16 to the resistor
network located in the doors or
seat belts.
This DTC should resolve once
the cause is addressed.
Contact OEM for details on the
source of the message and fix.
This DTC should resolve once
the cause is addressed.
25
