BENDIX Intellipark Service Data page 53

SPN FMI
516154 13 J1939 CAN Stop Lamp
Switch Out of Calibration
516155 2 External Park/Unpark
Request Manual Park
Erratic, Intermittent, or
Incorrect - ECU DTC
(84_11)
516156 2 External Park/Unpark
Request Manual Unpark
Erratic, Intermittent, or
Incorrect - ECU DTC
(85_11)
516156 12 Park Brake Power State
Failure
516157 2 External Park/Unpark
Request Inhibit Rollaway
Mitigation Erratic,
Intermittent, or Incorrect -
ECU DTC (8B_11)
516158 2 J1939 Seat Belt
Message - Erratic,
Intermittent, or Incorrect
516159 19 J1939 CAN Vehicle
Speed Implausible
516159 31 On the Air Lockout
Release
Mode Active
516160 2 J1939 Ignition Message
- Erratic, Intermittent, or
Incorrect
Table 6 – Diagnostic Trouble Codes (DTCs)
Description
Stop mismatch between
brake switch signal on
chassis and party CAN
XPURT CAN data not
received when expected or
received with error
XPURT CAN data not
received when expected or
received with error
Mismatch between LV1 and
LV2 signals
XPURT CAN data not
received when expected or
received with error
Seat belt message CAN data
not received when expected
or received with error
Speed CAN data not
received when expected or
received with error
There is an OTA release
lockout request ongoing
Ignition message CAN data
not received when expected
or received with error
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check the park brake release
request inhibit interlock status on
the chassis and party CAN.
Contact the OEM for details on
the source of message and the
fix.
The DTC should resolve once the
cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Check the battery and CAN
connections to the DECU.
Contact the OEM for further
assistance.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
ECU is in OTA release lockout
mode; wait for the OTA lockout
mode to exit or execute an OTA
stop.
Contact the OEM for assistance.
This DTC should resolve once
the cause is addressed.
Contact the OEM for details on
the source of the message and
the fix.
This DTC should resolve once
the cause is addressed.
53
