BENDIX Intellipark Service Data page 30

SPN FMI
516101 2 Tractor Park Brake
Exhaust Valve - J1 Pin 8
Harness Related Fault
516101 3 Tractor Park Brake
Exhaust Valve - J1 Pin 8
Shorted to Battery
516101 4 Tractor Park Brake
Exhaust Valve - J1 Pin 8
Shorted to Ground
Table 6 – Diagnostic Trouble Codes (DTCs)
30
Description
Tractor exhaust wire noise or
short to another source
Tractor exhaust wire short to
battery or high source
Tractor exhaust wire short to
ground or low source
Cause
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Corrective Action
Check Pin 8 on DECU J1
connector for short to or bad
connection; if an issue is found,
re-pin at that location.
Check Pin 1 on the Tractor
solenoid connector for short or
bad connection; if an issue is
found, re-pin at that location.
Check the connections between
Pin 8 DECU J1 connector to
Pin 1 on the tractor solenoid
connector; re-pin if a short or bad
connection is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 8 on DECU J1
connector for short to a high
source; if an issue is found, re-
pin at that location.
Check Pin 1 on the tractor
solenoid connector for short to a
high source; if an issue is found,
re-pin at that location.
Check the connections between
Pin 8 DECU J1 connector to
Pin 1 on the tractor solenoid
connector; re-pin if a short to a
high source is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
Check Pin 8 on DECU J1
connector for short to ground; if
an issue is found, re-pin at that
location.
Check Pin 1 on the tractor
solenoid connector for short to
ground source; if an issue is
found, re-pin at that location.
Check the connections between
Pin 8 DECU J1 connector to
Pin 1 on the tractor solenoid
connector; re-pin if a short to
ground is found.
Cycle the battery and/or place
the key in the off position for 30
seconds.
This DTC should resolve once
the cause is addressed.
