BENDIX Intellipark Service Data page 39

SPN FMI
516112 2 Intellipark Tractor LED
Failure
516112 12 Intellipark Tractor LED
Failure
516113 2 Intellipark Trailer LED
Failure
Table 6 – Diagnostic Trouble Codes (DTCs)
Description
Possible ECU damage
Possible ECU damage
Possible ECU damage
Cause
•
•
•
•
•
•
•
•
•
Corrective Action
Power Intellipark off then back
on; observe LEDs as they
perform the bulb check at start-
up (three [3] seconds on, then
two [2] seconds off). Verify
all LEDs turn on and off as
expected. If a part faults, replace
the ECU.
If this DTC does not occur at
start-up, dim the dash brightness
and see if the DTC occurs when
the vehicle requests the LEDs
are dimmed. If the DTC occurs,
replace the ECU.
This DTC should resolve once
the cause is addressed.
Power Intellipark off then back
on; observe LEDs as they
perform the bulb check at start-
up (three [3] seconds on, then
two [2] seconds off). Verify
all LEDs turn on and off as
expected. If a part faults, replace
the ECU.
If this DTC does not occur at
start-up, dim the dash brightness
and see if the DTC occurs when
the vehicle requests the LEDs
are dimmed. If the DTC occurs,
replace the ECU.
This DTC should resolve once
the cause is addressed.
Power Intellipark off then back
on; observe LEDs as they
perform the bulb check at start-
up (three [3] seconds on, then
two [2] seconds off). Verify
all LEDs turn on and off as
expected. If a part faults, replace
the ECU.
If this DTC does not occur at
start-up, dim the dash brightness
and see if the DTC occurs when
the vehicle requests the LEDs
are dimmed. If the DTC occurs,
replace the ECU.
This DTC should resolve once
the cause is addressed.
39
