- Page 1 VGA to CGA Converter ID #40 Operation Manual...
- Page 2 Introduction The ID – 40 VGA to CGA Converter is pure Hardware design, simply Plug and Play. No software driver requirement, the ID – 40 VGA to CGA converter is compatible with any operating system. Features • Switchable NTSC, NTSC-EIAJ (for Japan), PAL, PAL-M, PAL-N, PAL - combination - N and SECAM(via RGB OUT) video system.
- Page 3 Video Signal Switch RGB OUT enable Composite & S-Video Out 1. SIZE Button: Switch between UNDERSCAN and OVERSCAN, available on 640x480 mode only. 2. ZOOM Button: Toggles between ZOOM and NORMAL display. 3. POSITION Button: Press UP, DOWN, LEFT, RIGHT buttons; and the picture will move in the direction pressed.
- Page 4 MODE and Resolution Table The TV-View Pocket support the following VGA display modes Resolution 640 1024 Horizontal 31.5 37.9 37.5 43.3 35.2 37.9 47.2 48.4 Frequency (Khz) Vertical Frequency (Hz) The TV-View Pocket support the following MAC display modes Resolution Horizontal 53.7 Frequency...
- Page 5 Specifications Installation 1. Please make sure that the DC voltage is exactly within the voltage range shown in the specifications 2. check if the signal source and converter are both connected 3. Plug the free end of the signal cable into the 6 pin RGB socket plug of the converter.
