- Page 1 DVI Digital scaler with ultra high bandwidth ID #442 Operation Manual...
- Page 2 Introduction Congratulations on your purchase of the DVI Digital scaler with ultra high bandwidth. Please read this to become familiar with the DVI Digital scaler with ultra high bandwidth and keep the manual for possible reference in the future. The DVI Digital scaler with ultra high bandwidth is designed to convert PC, SD, HD and DVI to digital DVI at a variety of HDTV and PC resolutions.
- Page 3 Operating Functions and Controls Front Panel 1. Power: Press the button to turn ON or turn OFF (standby) the power of the unit. 2. Menu/Enter: This button serves two purposes. a. Press the button to bring up OSD main menu as shown in the "OSD Operation''.
- Page 4 5. IR Sensor: Infrared remote control sensor. 6. Component Input: Connects this input connector to the Component output connector of your source equipment using the enclosed 3RCA to 3RCA cable. the DVI Digital scaler with ultra high bandwidth accepts both interlaced component input (480i, 576i) and de-interlaced progressive input (480p, 576p...
- Page 5 picture. A non-HDCP compliant display can only display non-HDCP signal and picture will become noise when input is a HDCP-encrypted signal. 5. Power jack: Connect to the 5V 2A DC power adapter. Remote Control and functions 1. Power: Press the button once to power on the DVI Digital scaler with ultra high bandwidth.
- Page 6 Remote Control (cont)
- Page 7 Installation Input Connection...
- Page 8 The DVI Digital scaler with ultra high bandwidth accepts component, PC and DVI inputs. The formats supported by these inputs are as follows: Component Input − When connecting to a PC source use a 15-pin D-sub cable to connect the output of a PC to the D-Sub input connector of the DVI Digital scaler with ultra high bandwidth.
- Page 9 − When connecting to a DVI source, use a DVI-I or DVI-D cable to connect the DVI output of a PC or DVD to the DVI input connector of the DVI Digital scaler with ultra high bandwidth. - When connecting to a HDMI source, use a HDMI cable to connect to the HDMI output of a HDMI source, such as DVD or STB, on the one end.
- Page 10 following resolutions (all in RGB format). 480i/480p/576i/576p/720p@(50/60) /1080i@ (25/30) /1080p@ (50/60) /VGA @60/ SVGA @60/XGA @60/SXGA @60/ U XGA @ 60/WXGA @60/WSXGA @60/W UXGA @60 OSD Operation After power on the unit, press the "menu" button will bring up the main menu as follows: Use +, - button to move highlight bar to your desired parameter, then press MENU/ENTER to enter into sub-menu of your selected...
- Page 11 - Overscan NR - - Low - Middle - High - Off Note (PC): Available only when PC is selected as input. To adjust picture quality, Use “+,-” to move the highlight bar to your desired adjust item, press the Menu/Enter to confirm your selection. At this point, the selected parameter will turn red, you can then use “+,-”...
- Page 12 Colour User: Select to adjust to your favorite color temperature setting. Normal: Normal color tone setting where white is pue white. Warm: Warm color tone makes white reddish. Cool: Cool color tone makes white bluish. Output: The DVI Digital scaler with ultra high bandwidth can output a wide variety of PC and HD resolutions as follows.
- Page 13 Input: Show input resolution i.e XGA. Output: Show output resolution i.e 720p. Date: Show date of firmware version. Specifications HDMI 1.2 Compliant Input format(Up to 165MHz) YpbPr/YCbCr: 480i, 480p, 576i, 576p, 720p@(50/60Hz), 1080i@(25/30), 1080p@(50/60) VGA: VGA@(60/72/75/85), SVGA@(56/60/72/75/85), XGA@(60/70/75/85). S X G A @ ( 6 0 / 7 5 / 8 5 ) , U X G A @ 6 0 , W U X G A @ 6 0 DVI:VGA@(60/72/75/85), SVGA@(56/60/72/75/85), XGA@(60/70/75/85).
