4

Access Point mode operation

■ Setting the Access Point mode

DWhen using the ID-31A/E PLUS, ID-51A/E (PLUS2), ID-52A/E, ID-50A/E

In this section, set an Access Point transceiver.
L In this document, the ID-52A/ID-52E is used as an example.
[Access Point transceiver operation]
1. Push [MENU].
2. Select "DV Gateway."
3. Select "<<Access Point Mode>>."
4. Rotate [DIAL] to set the operating frequency.
L The frequency is used to communicate with the
Remote D-STAR transceiver.
L In the Access Point mode, you can change the
operating frequency.
NOTE: BE SURE to check your local regulations
or laws to select the appropriate operating
frequency.
[Windows or Android operation]
L When using the RS-MS3A application, select "USB" in
the RS-MS3A "Connection."
z Click (touch) <Start>
RS-MS3A.
L If an error message is displayed, see page 30 to
read the tips to solve the problem.
TIP: Canceling the Access Point mode
[Windows or Android operation]
1. Click (touch) <Stop>
[Access Point transceiver operation]
2. Select "<<Normal Mode>>" in the Quick Menu or "DV Gateway" on the MENU screen.
L To display the Quick Menu, push [QUICK].
NOTE: In the Access Point mode
• The Power Save function is not activated.
• Following items are automatically set.
Operating mode: VFO mode*
Frequency band: VHF* (Only when using the ID-51A (PLUS2)/ID-51E (PLUS2) and the AIR band is set.)
VHF* or UHF* (Only when using the ID-52A/ID-52E/ID-50A/ID-50E, when a frequency that is in the
AIR band is selected, when a frequency that is out of the amateur radio band is selected, or when a
frequency that cannot be set in the DV mode is selected.)
Receive mode: DV mode*
Dualwatch function: OFF* (Only when using the ID-51A (PLUS2)/ID-51E (PLUS2)/ID-52A/ID-52E/ID-50A/ID-50E.)
Duplex mode: OFF*
* These settings do not return to the previous settings even if you cancel the Access Point mode.
• The Access Point mode is not automatically canceled even if you turn OFF the transceiver, then ON it again.
in the RS-MS3W or
in the RS-MS3W or RS-MS3A.
When using the UDP Hole Punch function
Set "UDP Hole Punch" to "ON" in the RS-MS3W or
RS-MS3A. (p. 8)
Click
21
Set the
operating
frequency
"AP" is displayed
when using the
ID-31A PLUS/
ID-31E PLUS.
Touch
