Setting up the RS-MS3W/RS-MS3A

■ Setting up the RS-MS3A

The RS-MS3A is an application for Android device to use the DV Gateway function.
Download the application from Google Play.
L See page 3 for system requirements.
ID-52A PLUS/ID-52E PLUS can connect the transceiver to an Android device using the Bluetooth.

DInstalling the RS-MS3A

1. Start the Android device.
2. Touch "Play store."
3. Enter "RS-MS3A."
L Do not abbreviate the application name to certainly
find it.
4. Touch " (search)"
5. Touch "RS-MS3A."
• The RS-MS3A application information is displayed.
L If your Android device is not compatible with the RS-
MS3A, the application is not displayed.
6. Touch "Install."
7. Touch "Agree to download."
• Starts installing the application.
• After the installation is completed, the icon is
displayed on your home screen.

DWhen connecting with the data cable

Connect the transceiver to the Android device using
the data cable. (Example: ID-52A/E)
To the
[USB] port
ID-52A/ID-52E:
• Connect the USB Micro-B connector (in the case
of OPC-2417, the one with the white tube) to the
transceiver and the other to an Android device.
• If " " is not displayed when connecting the
transceiver to an Android device, set "USB
Connect" to "Serialport."
([MENU] > SET > Function > USB Connect)
ID-50A/ID-50E or ID-52A PLUS/ID-52E PLUS:
Confirm the "USB Connect" in the Set mode is set to
"Serialport."
([MENU] > SET > Function > USB Connect)
• When connecting the transceiver to an Android
device, " " is displayed on the ID-52A PLUS/
ID-52E PLUS.
ID-31A PLUS/ID-31E PLUS/
ID-51A (PLUS2)/ID-51E (PLUS2):
Connect the data cable to the [DATA] jack.
NOTE:
• Turn OFF the transceiver before connecting or
removing the data cable.
• Remove the data cable when you do not use it.
Otherwise, the battery will be quickly exhausted.
If you want to reduce the battery consumption of your
Android device while the data cable is connected, set
the following item on the transceiver to "OFF."
( [MENU] > SET > Function >
USB Power Input (Phone, Tablet, PC))
• If the application selection window is displayed, select
"RS-MS3A" to start the application.
13
Android device with
the USB host function
Data cable
To a USB port
