Dwhen Not Using The Dr Function - Icom ID-52A PLUS Manual

4
Access Point mode operation
■ Making a Gateway call through the Access point transceiver

DWhen not using the DR function

In this document, the ID-51A (PLUS2)/ID-51E (PLUS2) is
used as a Remote D-STAR transceiver as an example.
1. Enter the VFO mode.
Push [V/MHz].
2. Set the operating frequency.
Rotate [DIAL] to set the frequency that is set to the
Access Point transceiver. (Example: 430.850)
3. Set the Receive mode to "DV mode."
Push [MODE] several times until "DV" is displayed.
L When the "GPS TX Mode" is set, "DV-G" or "DV-A" is
displayed.
4. Set the duplex direction.
1. Push [QUICK].
2. Select "DUP."
3. Select "DUP–."
28
