Operating In The Access Point Mode - Icom ID-52A PLUS Manual

4
Access Point mode operation

■ Operating in the Access Point mode

You can operate the Access Point transceiver as described below in the Access Point mode.
What you can do while in the Terminal mode
Display the RX HISTORY screen.
Turn the Monitor function ON or OFF
Open the MENU screen.
Turn the Key Lock function ON or OFF.
Open the Quick Menu*.
Audibly announce the displayed Call Sign.
Select 1 MHz or 10 MHz tuning steps.
Select the transmit output power.
Adjust the audio volume level.
Select an operating frequency.
Turn the transceiver ON or OFF.
* You can select the following items (Quick Menu) in
the Access Point mode.
<<Normal Mode>>
Band Select*
1
TS
ATT*
1,2,3
GPS Information
GPS Position
Home CH Set
Voltage
<<REC Start>>
<<GPS Logger Only>>
* "Band Select" and "ATT" are not displayed when using
1
the ID-31A PLUS/ID-31E PLUS.
* "ATT" is not displayed when using the
2
ID-51A (PLUS2)/ID-51E (PLUS2).
* Not displayed when using the Access Point mode on
3
the B band.
Hold down [CD] for 1 second.
Push [SQL].
L Rotate [DIAL] while pushing [SQL] to adjust the squelch level.
A weaker signal than the set squelch level is not transmitted
through the Internet.
Push [MENU].
Hold down [LOCK] for 1 second.
Push [QUICK].
Hold down [SPCH] for 1 second.
L Hold down [QUICK] for 1 second when using the
ID-31A PLUS/ID-31E PLUS.
Push [VFO/MHz].
L Push [V/MHz] when using the ID-31A PLUS/ID-31E PLUS/
ID-51A (PLUS2)/ID-51E (PLUS2)/ID-50A/ID-50E.
L You cannot select 10 MHz tuning steps in the
ID-31A PLUS/ID-31E PLUS/ID-52A/ID-52E/ID-50A/ID-50E/
ID-52A PLUS/ID-52E PLUS.
Hold down [LOW] for 1 second to select the transmit
output power between S-Low, Low1, Low2, Mid, and High.
L Hold down [LO] for 1 second to open the Select Output Power
window when using the ID-52A/ID-52E/ID-50A/ID-50E/
ID-52A PLUS/ID-52E PLUS.
L No icon appears when high power is selected.
L "SLO," "LO1," "LO2," or "MID" appears when S-low, Low 1,
Low 2, or Mid power is selected.
Rotate [VOL].
Rotate [DIAL].
Hold down [ ] for 1 second.
L The Access Point mode is not automatically canceled even if
you turn OFF the transceiver, then ON it again.
TIP: See the transceiver's manual about each key
operation.
ID-31A PLUS/ID-31E PLUS
Basic manual Section 2, 3, 11
Advanced manual Section 11
ID-51A (PLUS2)/ID-51E (PLUS2)
Basic manual Section 2, 4, 6
Advanced manual Section 9
ID-52A/ID-52E/ID-50A/ID-50E/
ID-52A PLUS/ID-52E PLUS
Basic manual Section 2, 3, D-STAR OPERATION
Advanced manual Section 5
23
