Page 1
CAME.COM/UK AXL-P Complete kit for a pair of swing gates weighing up to 250kg per leaf / max. width 2m QUICK SETUP GUIDE Typical gate setup & geometry Gate motor manual release Kit wiring diagram Control panel guide & safety...
Page 2
CONTENTS Control Panel: Kit Contents Quick Start Guide Safety Instructions Control Panel: Programming Transmitters Typical Gate Setup Control Panel: Safety Geometry Optional Accessories Manual Release Instructions Kit Wiring Diagram AXL-P: KIT CONTENTS AXL20DGS ZL60 AF43S Motor Control Panel Radio Frequency Card topd4Fks top-a433n DIR10...
Page 3
SAFETY INSTRUCTIONS When correctly installed in compliance to installation instructions and adhering to all current electrical, mechanical and manufacturer regulations, your automation system will provide a high degree of safety and problem free operation. Please take note of the following warnings that must be followed in order to prevent accidents during your gate operation: •...
Page 4
AXL: TYPICAL GATE SETUP OUTSIDE OF GATES INSIDE OF GATES AXL Motor Flashing Light (optional) 2nd set of Photocells (optional) Control Panel Selector Keypad (optional) Mechanical End Stop (not supplied) Reception Antenna Photocells (on outside of gate posts) Photocell column (optional accessory) CONTROL PANEL •...
Page 5
AXL-P: GEOMETRY Preliminary checks Tick 1. Check that the gate structure is sturdy enough, the hinges work efficiently and that there is no friction between the fixed and moving parts 2. Make sure that measurement does not exceed the value shown in the reference table 3.
Page 6
AXL: MANUAL RELEASE The AXI worm drive swing gate operator manual release mechanism is found towards the =============== Hand these instructions to the end user =============== rear of the motor. MANUALLY RELEASING THE GEAR MOTOR ⚠ Manually releasing the gate may cause an uncontrolled movement of the gate due to possible To manually release the gates: mechanical anomalies or unbalancing.
Page 7
230V AXL-p: wiring diagram ZL60 Control Panel AF43S Plug-in TOP-A433N Antenna 10 2 TX C NC TX 2 Mains Supply Cable/length 230 V AC RG58 Max. 5m Cable/length 1m - 20m = 3 Core 1.5mm 20m - 30m = 3 Core 2.5mm The Earth cable should be connected to the motor chassis.
Page 8
Safety inputs should now be configured and the gate force tested as required. Please refer to the full manual to complete the commissioning. Should the gates not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
Page 9
Once deletion is complete, the PRG LED stays lit and buzzer sounds off for one second. Set all the Dip switches down to the off position. Should the transmitter not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
Page 10
ZL60: SAFETY SAFETY INPUTS FUNCTIONS > C1 Input, CX Input REOPENING DURING CLOSING • When the automation is in its closing cycle and the safety circuit is triggered the automation will stop and reverse its motion until it reaches its fully open position again.
Page 11
AXL-p: ACCESSORIES Code(s) Description RADIO KEYPAD SELECTORS 806SL-0170 SELT1W4G - Surface-mounted, 433.92 MHz radio-frequency keypad selector, 12-keys, with blue backlighting. 25 savable codes and password to access the programming mode. Settable in Rolling Code or Fixed Code mode. RAL7024 Grey colour. 806SL-0180 SELT1W8G - Surface-mounted, 868.35 MHz radio-frequency keypad selector, 12-keys, with blue backlighting.
Page 12
YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
