Complete kit for a single swing gate weighing up to 400kg / max. width 5m (28 pages)
Summary of Contents for CAME AX402306
Page 1
Operator FA02022-EN for swing gates AX302304 AX402306/AX412306 AX71230 INSTALLATION MANUAL EN English...
Page 2
WARNING! important safety instructions: READ CAREFULLY! • REMISE PREVENT ANY RISK IT IS FORBIDDEN FOR USERS TO PERFORM ANY OPERATIONS THAT ARE NOT • E MPLOY THIS PRODUCT ONLY FOR THE USE FOR WHICH IT WAS EXPRESSLY MADE EXPRESSLY REQUIRED OF THEM AND WHICH ARE NOT LISTED IN THE MANUALS OR ANY REPAIRS .A.
Page 3
4.1 Gate Operator This product is engineered and manufactured by CAME S.p.A. and complies with current safety regulations. The gearmotor is made up of two aluminium alloy half shells housing the Encoder gearmotor – which features an electric blocking mechanism – and an epicyclical reduction system with endless screw.
Page 4
5) Bushing 12) Gate bracket screw for securing to M8x10 UNI5739 pin 6) M8 UNI5588 nut for securing pillar bracket 13) Securing bracket 7) Sheath holder 14) Small release door AX71230 AX302306 - AX402306 - AX412306 4.4 Dimensions 1100 1180...
Page 5
5 Installation Installation must be carried out by expert qualified personnel and in full compliance with current regulations. 5.1 Preliminary checks Before installing, do the following: • Make sure you have suitable tubing and conduits for the electrical cables to pass through and be protected against mechanical damage;...
Page 6
5.4 Standard installation 1) AXO operator 2) Control panel 3) Reception antenna 4) Flashing light 5) Selector switch 6) Photocells 7) Electric cable junction box 8) Mechanical gate stops 9) Photocell column 5.5 Installing the operator The following illustrations are only examples, given that the space available for anchoring the operator and accessories may vary from gate to gate.
Page 7
A, the opening angle and gate speed are increases, while the gearmotor thrust is decreased. Pillar bracket Gate bracket AX302304 - AX402306 - AX412306 AX71230 Gate leaves of up to 4m Gate leaves of up to 7 m...
Page 8
Weld the gate bracket to the gate leaf making sure the quotas shown in the table are met. Note: for AX71230 gearmotors, require an additional 10 mm shim between the gate and the bracket. Note: on non-metal gate leaves assemble and weld the two parts of the bracket and secure them with proper screws.
Page 9
Open the gate leaf and insert the pin into the gate bracket and secure it using a washer and nut. Gate bracket UNI6593 Ø8 washer Screw UNI5739 M8x10 Release the gearmotor (see paragraph on manual release), completely open the gate leaf, loosen the nuts of the opening mechanical stop and position it up against the attachment pin, then secure it.
Page 10
5.6 Manual release of the gearmotor Slide open the small door that protects the release, insert the tri-lobed key and turn it. 5.7 Connecting to the control panel For the electrical connection procedures, use the junction box and branching boxes. Connecting the 230 V AC delayed closing gearmotor ZM3E Control panel...
Page 11
5.8 Outward opening installation (non-issued) Supplementary bracket TABLE 1 TABLE 2 Opening Opening 90° 1100 90° Weld pillar bracket to the non-issued supplementary bracket, while gate is open, then secure the brackets to the pillar, making sure the “A” and “B” quotas shown in table 1 are met. Weld, or secure with proper screws, the gate bracket, making sure the “E” quota is met, as shown in table 1.
Page 12
Fully close the gate-leaf, place the mechanical stop against it with the pin attachment and fi x it in place. Attachment pin Opening mechanical stop Fully open the gate-leaf, place the mechanical stop against it with the pin attachment and fi x it in place. Attachment pin Closing mechanical stop Connect the gearmotors to the panel as shown in the diagram.
Page 13
7 Maintenance Extraordinary maintenance Before doing any maintenance, cut off the power supply, to prevent any hazardous situations caused by accidentally activating the operator. ☞ Periodic maintenance log kept by users (every six months) Date Notes Signature...
Page 14
Extraordinary maintenance ⚠ The following table is for logging any extraordinary maintenance jobs, repairs and improvements performed by specialized contractors. Any extraordinary maintenance jobs must be done only by specialized technicians. Extraordinary maintenance log Fitter's stamp Name of operator Job performed on (date) Technician's signature Requester's signature Job performed __________________________________________________________________________________________...
Page 15
CAME S.p.A. employs a UNI EN ISO 14001 certified and compliant environmental protection system at its plants, to ensure that environmental safeguarding. We ask you to keep protecting the environment, as CAME deems it to be one of the fundamental points of its market operations strategies, by simply following these brief guidelines when disposing.
Page 16
The contents of this manual may change, at any time, and without notice. CAME S.p.A. Via Martiri Della Libertà, 15 31030 Dosson di Casier - Treviso - Italy tel. (+39) 0422 4940 - fax. (+39) 0422 4941...
