Nozzle Selection and
Preliminary Burner
Settings
See table below for oil nozzle selections and initial
burner settings. Follow Burner Manual and Heating
Appliance Manual for installation of nozzle if not
supplied with appliance.
The settings in Table 1 are approximate settings for
initial adjustment of the burner. Final adjustments must
be made using proper test equipment by a qualified
installer. All burner installation and adjustments must
adhere to the guidelines in the burner manual and
heating appliance manual.
Table 1
Burner specifications and preliminary settings for Thermo Pride OME Furnace
Input
Boiler Model
BTU/HR
70,000
OME 72*36
85,000*
* Factory Setting
© Copyright 2024 — Carlin Combustion Technology
Nozzle Specifications
Size
Type
0.50
70A
0.60
70A
Burner Setup for
Thermo Pride
OME Furnace
Installer/servicer – Except where specifically stated
otherwise, this Supplement must be used only by a
qualified service technician. Follow all guidelines
in the Burner Manual and Heating Appliance Manual.
Failure to comply with this or other requirements in this
manual could result in severe personal injury, death or
substantial property damage.
Installer must verify correct size nozzle for appliance
is installed and confirm it is properly tightened.
Oil Pressure
(PSI)
Manufacturer
Delavan
120
Delavan
120
Tech support 800-989-2275
Head
Air Band
Position
Setting
#0
65%
#1
30%
carlincombustion.com
MN51723 071924
