Copyright 2016 — Carlin Combustion Technology, Inc.
Installation
Operating
Instructions
Carlin Flame Funnel
Models 1050FFD and
SPECIFICATIONS
ITEM
Fuel Specification
Firing Range
High-Fire*
Low-Fire
Motor HP, RPM, Hz
Motor Volts, 1-phase
3-phase
Motor Amps; 115 volts, 1-phase
230 volts, 1-phase
230 volts, 3 phase
460 volts, 3 phase
Control Volts, Hz
Ignitor Volts
Burner Housing
Blower Wheel, Dia. x W.
Flame Retention Ring, O.D.
2-Stage Fuel Unit Pressure
Low and High-Fire Oil Valve
Damper Motor with End Switch
Oil Nozzle Specs.
Approximate Shipping Weight
** Gph ratings are based on sea level to 2,000 ft. elevation. For every
1,000 ft. rise over 2,000 ft., reduce the maximum gph rating by 4%.
**Motor volts and phase must be specified when ordering.
Carlin Combustion Te chnology, Inc.
126 Bailey Rd
Ph 203-680-9401
Tech Support 800-989-2275
and
For
Oil Burners
1150FFD
MODEL NUMBER
1050FFD
1150FFD
No. 2
No. 2
ASTM D396
ASTM D396
15.00-25.00*
20.00-35.00*
9.00-12.00
12.00-15.00
1
, 3450, 60
1 /2
1, 3450, 60
115/208-230**
115/208-230**
208-230/460**
208-230/460**
16.4
22.0
8.2
11.0
4.0
5.0
2.0
2.5
120, 60
120, 60
120
120
Rugged casting
Rugged casting
7" x 5"
7
" x 5"
5 /8
3
"
4
"
13 /16
1 /4
100
100
120V, 60-Hz
120V, 60-Hz
120V, 60-Hz
120V, 60-Hz
(3) 45°SS
(3) 45°SS
135 lbs.
145 lbs.
North Haven, CT 06473
Fx 203-680-9403
carlincombustion.com
®
