Firenze-systems
User Guide
The network shall comprise:
• single PC or MAC, running the K-framework3 software with
network interface 100Mbps (or higher);
• router with DHCP server 100Mbps (or higher);
• Ethernet switch (usually integrated into the router)
100Mbps (or higher);
• Cat5 (or higher) Ethernet cables.
Since the Firenze system components are passive, they do
not include built-in amplifiers, control interfaces, or network
ports. To connect, a PC or Mac must be linked directly to the
switch and the network ports on either the K-RACK-M-208 I
or the Kommander-KA and Kommander-KALIVE amplifiers. The
(
Kommander amplifiers are also available in an 8-channel Plus
version with expanded network capabilities*
K-framework3
PC or MAC
26
LIGHT
Set
Cool
AUX
Heat
STC-1000
A B A1 A2 A3 A4
IN OUT IN OUT IN LINK IN LINK IN LINK IN LINK
PUSH PUSH PUSH PUSH
AMPLI 1 AMPLI 2 AMPLI 3
1 - 4 1 - 2 3 - 4 1 - 4 1 - 2 3 - 4 1 - 4 1 - 2 3 - 4
G G G
B F B F B F
E E E
C 5 - 6 7 - 8 C 5 - 6 7 - 8 C 5 - 6 7 - 8
D D D
1 - 8 1 - 8 1 - 8
5 - 8 5 - 8 5 - 8
L N L N L N
1 6 1 6 1 6
N L N L N L
G L N G L N G L N
B 2 5 B 2 5 B 2 5
F F F
E E E
C N L C N L C N L
D L N L N D L N L N D L N L N
3 4 3 4 3 4
EU US
2 P1 P2 P3 AUX

Discovery

1. Ensure that the Kommander-KA units and the PC/Mac
running the K-framework3 are properly connected to the
same network and belong to the same subnet.
2. Power up the Firenze-KH7P I units.
3. Launch the K-framework3.
4. Open the Network window and launch the discovery:
• If the K-framework3 finds two or more devices with the
wrong ID, a dialog window appears where unique IDs can
be assigned to the units. Retro
FAN
OUT IN OUT IN
A B
5. Once discovered, the real units are shown in the left
columns, following the order of their ID number; if the
workspace contains virtual devices of the same type you
P1 P2 P3
0
EU US
SRV
can eventually modify the IDs in order to match the units
SRV SW AUX SW
AUX
and allows the synchronization. The synchronization can
be in either directions: Workspace-to-Real or Real-to-
Workspace. Select the sync direction and synchronize all or
the single units separately
*Please see the Kommander-KA user guide for reference and the
relative products pages.
