Cypress Semiconductor CY7C1246V18 Specification Sheet

Features
■
36-Mbit density (4M x 8, 4M x 9, 2M x 18, 1M x 36)
■
300 MHz to 375 MHz clock for high bandwidth
■ 2-Word burst for reducing address bus frequency
■ Double Data Rate (DDR) interfaces
(data transferred at 750 MHz) at 375 MHz
■
Read latency of 2.0 clock cycles
■ Two input clocks (K and K) for precise DDR timing
❐ SRAM uses rising edges only
■ Echo clocks (CQ and CQ) simplify data capture in high speed
systems
■
Data valid pin (QVLD) to indicate valid data on the output
■ Synchronous internally self-timed writes
■ Core V = 1.8V ± 0.1V; IO V
DD
■ HSTL inputs and variable drive HSTL output buffers
■ Available in 165-ball FBGA package (15 x 17 x 1.4 mm)
■ Offered in both in Pb-free and non Pb-free packages
■
JTAG 1149.1 compatible test access port
■ Delay Lock Loop (DLL) for accurate data placement
Configurations
With Read Cycle Latency of 2.0 cycles:
CY7C1246V18 – 4M x 8
CY7C1257V18 – 4M x 9
CY7C1248V18 – 2M x 18
CY7C1250V18 – 1M x 36
Selection Guide
Description
Maximum Operating Frequency
Maximum Operating Current
Note
1. The QDR consortium specification for V
V = 1.4V to V .
DDQ DD
Cypress Semiconductor Corporation
Document Number: 001-06348 Rev. *D
Burst Architecture (2.0 Cycle Read Latency)
[1]
= 1.4V to V
DDQ DD
is 1.5V + 0.1V. The Cypress QDR devices exceed the QDR consortium specification and are capable of supporting
DDQ
• 198 Champion Court
CY7C1246V18, CY7C1257V18
CY7C1248V18, CY7C1250V18
36-Mbit DDR-II+ SRAM 2-Word
Functional Description
The CY7C1246V18, CY7C1257V18, CY7C1248V18, and
CY7C1250V18 are 1.8V Synchronous Pipelined SRAM
equipped with DDR-II+ architecture. The DDR-II+ consists of an
SRAM core with advanced synchronous peripheral circuitry.
Addresses for read and write are latched on alternate rising
edges of the input (K) clock. Write data is registered on the rising
edges of both K and K. Read data is driven on the rising edges
of both K and K. Each address location is associated with two
8-bit words (CY7C1246V18), 9-bit words (CY7C1257V18),
18-bit words (CY7C1248V18), or 36-bit words (CY7C1250V18)
that burst sequentially into or out of the device.
Asynchronous inputs include output impedance matching input
(ZQ). Synchronous data outputs (Q, which share the same
physical pins with the data inputs, D) are tightly matched to the
two output echo clocks CQ/CQ, eliminating the need to capture
data separately from individual DDR SRAMs in the system
design.
All synchronous inputs pass through input registers controlled by
the K or K input clocks. All data outputs pass through output
registers controlled by the K or K input clocks. Writes are
conducted with on-chip synchronous self-timed write circuitry.
375 MHz 333 MHz
375 333
1210 1080
,
• San Jose
300 MHz
300 MHz
1000
CA 95134-1709 • 408-943-2600
Revised March 11, 2008
Unit
mA
