Page 1: Com Express Evaluation Board
E6-EVBB COM Express Evaluation board www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity E6-EVBB I/O Shield SATA cable Standoff Screw If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
USB32 (USB 3.2 Gen 1 connector) ........ 26 2.2.6 USB32_LAN (RJ45 LAN + USB 3.2 Gen 1 connector) ..27 2.2.7 AUDIO (Line out + MIC in connector) ......28 2.2.8 SATAPWR, SATAPWR1, SATAPWR2, SATAPWR3 (SATA power connector) ............29 www.gigaipc.com... - Page 12 2.2.19 COM Express connector ROW A/B ....... 40 2.2.20 COM Express connector ROW C/D ....... 44 2.2.21 BKL_CN (Backlight Control header) ......48 2.2.22 LVDS (LVDS connector) ..........49 2.2.23 FP_AUDIO (Front panel audio header) ......50 2.2.24 SPKR (Speaker out connector) ........51 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 243.84±0.2 251.34 www.gigaipc.com...
-
Page 15: Specifications
Specifications Evaluation E6-EVBB Board (CICC2) ATX form factor Form Factor 305W x 244D (mm) Compatible PICMG COM Express® R3.0 models Type 6 pinout compatible Ethernet 1 x GbE LAN Port Integrated Graphics Processor: 2 x HDMI 2.0 port 1 x DP port... - Page 16 Evaluation E6-EVBB Board (CICC2) Carton size: 679 x 430 x 399 (mm) Packing Capacity: 10pcs Single Box size: 360 x 330 x 80 (mm) Packing Content Including: IO Shield x 1 (P/N: 12AIO-CICC20-00R) SATA Cable x 1 (P/N: 12CF1-2SAT1B-01R) Standoff Screw x 4 (P/N: 25KSC-720020-G0R) Operating temperature: 0°C to 60°C...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 19 SATA0, SATA1, SATA 6Gb/s connector SATA2, SATA3 SYS_PANEL Front panel header SYS_FAN System fan connector 24-pin ATX main power connector Trusted platform module connector M.2 Slot, 2230 E-Key MPCIE Mini PCIE connector FUNC_PIN, FUNC_PIN1, FUNC_PIN2, Reserved pins FUNC_PIN3, FUNC_PIN4, www.gigaipc.com...
- Page 20 PCIe x1 (Gen3 x1 bus) slot PCIEX1_4, PCIEX1_5, PCIEX1_6, PCIEX16 PCIe x16 (Gen3 x16 bus) slot COM Express connector ROW A/B CEP_M COM Express connector ROW C/D BKL_CN Backlight Control header LVDS LVDS connector Front panel audio header FP_AUDIO Speaker out connector SPKR www.gigaipc.com...
-
Page 21: Rear I/O Connector
Description HDMI_1 HDMI connector D-SUB connector HDMI connector HDMI2_DP Display port USB20 USB 2.0 connector USB32 USB 3.2 Gen 1 connector USB 3.2 Gen 1 connector USB32_LAN RJ45 LAN Port Line out Port (Green) AUDIO Mic in Port (Pink) www.gigaipc.com... -
Page 22: Hdmi_1 (Hdmi Connector)
2.2.1 HDMI_1 (HDMI connector) HDMI 1 HDMI Connector Connector PN Vendor 1165-2CG04-24P TCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com... -
Page 23: Vga (D-Sub Connector)
2.2.2 VGA (D-sub connector) D-sub Connector Connector PN Vendor DV11261-25W9-4F FOXCONN 15 11 Definition Definition Green Blue DDCSDA HSYNC VSYNC DDCSCL www.gigaipc.com... -
Page 24: Hdmi2_Dp (Hdmi + Display Port Connector)
Display port Connector Pin No. Definition Pin No. Definition Pin No. Definition Pin No. Definition TX2p TX0p CLKn TX3n TX2n TX0n TX1p TX1p AUXp TX1n TX1n TX0p TX2p AUXn Hot Plug Detect Hot Plug TX0n TX2n 3.3V Detect TX3p 3.3V CLKp www.gigaipc.com... -
Page 25: Usb20 (Usb 2.0 Connector)
2.2.4 USB20 (USB 2.0 connector) USB 2.0 Connector Connector PN Vendor UB1112C-8FDE-4F FOXCONN Pin No. Definition www.gigaipc.com... -
Page 26: Usb32 (Usb 3.2 Gen 1 Connector)
2.2.5 USB32 (USB 3.2 Gen 1 connector) USB 3.2 Gen 1 connector Connector PN Vendor UEA11121-8FS6-4F FOXCONN ABA-USB-079-K01 LOTES Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 27: Usb32_Lan (Rj45 Lan + Usb 3.2 Gen 1 Connector)
TX4+ TX2- TX4- USB Connector State Description Pin No. Definition Pin No. Definition Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate USB3_RX1n USB3_RX2n Connector PN Vendor USB3_RX1p USB3_RX2p JFM38U1B-B31G-4F FOXCONN USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 28: Audio (Line Out + Mic In Connector)
2.2.7 AUDIO (Line out + MIC in connector) Line out Port MIC in Port www.gigaipc.com... -
Page 29: Satapwr, Satapwr1, Satapwr2, Satapwr3 (Sata Power Connector)
2.2.8 SATAPWR, SATAPWR1, SATAPWR2, SATAPWR3 (SATA power connector) Pin 1 SATAPWR3 SATAPWR2 SATAPWR1 SATAPWR Hard Disk Power Connector Connector PN Vendor 743-91-045W00 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition www.gigaipc.com... -
Page 30: Sata0, Sata1, Sata2, Sata3 (Sata 6Gb/S Connector)
2.2.9 SATA0, SATA1, SATA2, SATA3 (SATA 6Gb/s connector) SATA0 SATA1 SATA2 SATA3 SATA 6Gb/s Connector Connector PN Vendor WAT3M-07A1G3BU4W WINWIN ABA-SAT-054-S15 LOTES SATA0 SATA1 SATA2 SATA3 Pin No. Definition www.gigaipc.com... -
Page 31: Sys_Panel (Front Panel Header)
2.2.10 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition HD-P MPD-P HD-N MPD-N POWER-ON Reset Reserved www.gigaipc.com... -
Page 32: Sys_Fan (System Fan Connector)
2.2.11 SYS_FAN (System fan connector) Pin 1 System FAN connector Connector PN Vendor 744-81-045W11 PINREX WF04R22WJQ195 HORNGTONG Connector type 1x4pin header, pitch 2.54mm Pin No. Definition Detect Speed Control www.gigaipc.com... -
Page 33: Atx (24-Pin Atx Main Power Connector)
2.2.12 ATX (24-pin ATX main power connector) Pin 1 ATX power Connector Connector PN Vendor 740-96-245B70 PINREX Connector type 2x12pin connector, pitch 4.2mm Pin No. Definition Pin No. Definition 3.3V 3.3V 3.3V -12V PS_ON Power Good 5VSB 3.3V www.gigaipc.com... -
Page 34: Tpm (Trusted Platform Module Connector)
2.2.13 TPM (Trusted platform module connector) Pin 1 TPM module connector Pin No. Definition Pin No. Definition Connector PN Vendor Clock 52M-90-14GBE7 PINREX 3.3V LCB25-I1424S01C-12 LIONCONN Reset Connector type 3.3V 2x7pin header, pitch 2.0mm IRQ_SERIAL SDIN www.gigaipc.com... -
Page 35: M2E (M.2 Slot, 2230 E-Key)
PCIE CLOCKn SUSCLK PCIE Clock PCIRST Pin No. Definition Pin No. Definition Request PCIE wake up BT_Disable 3.3V 3.3V WLAN_DISABLE PERST 3.3V 3.3V Connector PN Vendor Pin No. Definition Pin No. Definition 80152-8521 BELLWETHER 2E0BC21-S85BE-LH FOXCONN PCIE_TXp APCI0095-P002A LOTES PCIE_TXn www.gigaipc.com... -
Page 36: Mpcie (Mini Pcie Connector)
Pin No. Definition Pin No. Definition 3.3V PCIE WAKE 3.3V 3.3V PCIE Clock SIM VCC Request SIM DATA PCIE Clock n SIM Clock 3.3V PCIE Clock p SIM Reset UIM VPP3 Connector PN Vendor WLAN_ AS0B221-S99Q-7H FOXCONN DISABLE Reset www.gigaipc.com... -
Page 37: 2.2.16 Func_Pin, Func_Pin1, Func_Pin2, Func_Pin3
Function Function Function Pin No. pin1 pin2 pin3 pin4 TPM_PP I2C_CK HDA_SDIN1 THRMTRIP# ESPI_ALERT0 BIOS_DIS0 SER0_TX SLEEP# -USB_OC4 ESPI_EX# SPI_PWR I2C_DAT HDA_SDIN2 THRM# ESPI_ALERT1 BIOS_DIS1 SER0_RX LED# GBE_SDP SER1_TX PEG_LANE_ PCH_SLP_S5# WAKE1# eDP_HPD ESPI_CS1 USB0_HOST_ BATLOW# GBE_CTREF SER1_RX PRSNT www.gigaipc.com... -
Page 38: Pciex1_6 (Pcie X1 (Gen 3X1 Bus) Slot)
2.2.17 PCIEX1 _1, PCIEX1 _ 2, PCIEX1 _ 3, PCIEX1 _4, PCIEX1_5, PCIEX1_6 (PCIe x1 (Gen 3x1 bus) slot) PCIEX1_6 PCIEX1_4 PCIEX1_2 PCIEX1_5 PCIEX1_3 PCIEX1_1 PCIe x1 connector www.gigaipc.com... -
Page 39: Pciex16 (Pcie X16 (Gen 3X16 Bus) Slot)
2.2.18 PCIEX16 (PCIe x16 (Gen 3x16 bus) slot) PCIe x16 connector www.gigaipc.com... -
Page 40: 2.2.19 Com Express Connector Row A/B
Pin No. Definition Pin No. Definition GND (FIXED) GND (FIXED) GBE0_MDI3- GBE0_ACT# GBE0_MDI3+ LPC_FRAME#/ESPI_CS0# GBE0_LNIK100# LPC_AD0/ESPI_IO_0 GBE0_LNIK1000# LPC_AD1/ESPI_IO_1 GBE0_MDI2- LPC_AD2/ESPI_IO_2 GBE0_MDI2+ LPC_AD3/ESPI_IO_3 GBE0_LINK# LPC_DRQ0#/ESPI_ALERT0# GBE0_MDI1- LPC_DRQ1#/ESPI_ALERT1# GBE0_MDI1+ LPC_CLK/ESPI_CK GND (FIXED) GND (FIXED) GBE0_MDI0- PWRBTN# GBE0_MDI0+ SMB_CK GBE0_CTREF SMB_DATA SUS_S3# SMB_ALERT# www.gigaipc.com... - Page 41 USB_4_5_OC# USB4- USB5- USB4+ USB5+ GND (FIXED) GND (FIXED) USB2- USB3- USB2+ USB3+ USB_2_3_OC# USB_0_1_OC# USB0- USB1- USB0+ USB1+ VCC_RTC ESPI_EN# RSVD USB0_HOST_PRSNT GBE0_SDP SYS_RESET# LPC_SERIRQ/ESPI_CS1# CB_RESET# GND (FIXED) GND (FIXED) PCIE_TX5+ PCIE_RX5+ PCIE_TX5- PCIE_RX5- GPI0 GPO1 PCIE_TX4+ PCIE_RX4+ www.gigaipc.com...
- Page 42 LVDS_B3- LVDS_A3- LVDS_BKLT_EN GND (FIXED) GND (FIXED) LVDS_A_CK+ LVDS_B_CK+ LVDS_A_CK- LVDS_B_CK- LVDS_I2C_CK LVDS_BKLT_CTRL LVDS_I2C_DAT VCC_5V_SBY GPI3 VCC_5V_SBY RSVD VCC_5V_SBY eDP_HPD VCC_5V_SBY PCIE_CLK_REF+ BIOS_DIS1# PCIE_CLK_REF- VGA_RED GND (FIXED) GND (FIXED) SPI_POWER VGA_GRN SPI_MISO VGA_BLU GPO0 VGA_HSYNC SPI_CLK VGA_VSYNC SPI_MOSI VGA_I2C_CK www.gigaipc.com...
- Page 43 FAN_PWMOUT A102 SER1_RX B102 FAN_TACHIN A103 LID# B103 SLEEP# A104 VCC_12V B104 VCC_12V A105 VCC_12V B105 VCC_12V A106 VCC_12V B106 VCC_12V A107 VCC_12V B107 VCC_12V A108 VCC_12V B108 VCC_12V A109 VCC_12V B109 VCC_12V A110 GND (FIXED) B110 GND (FIXED) www.gigaipc.com...
-
Page 44: 2.2.20 Com Express Connector Row C/D
2.2.20 COM Express connector ROW C/D Pin No. Definition Pin No. Definition GND (FIXED) GND (FIXED) USB_SSRX0- USB_SSTX0- USB_SSRX0+ USB_SSTX0+ USB_SSRX1- USB_SSTX1- USB_SSRX1+ USB_SSTX1+ USB_SSRX2- USB_SSTX2- USB_SSRX2+ USB_SSTX2+ GND (FIXED) GND (FIXED) USB_SSRX3- USB_SSTX3- USB_SSRX3+ USB_SSTX3+ DDI1_PAIR6+ DDI1_CTRLDATA_AUX- www.gigaipc.com... - Page 45 RSVD DDI3_PAIR0+ DDI2_PAIR0+ DDI3_PAIR0- DDI2_PAIR0- GND (FIXED) GND (FIXED) DDI3_PAIR1+ DDI2_PAIR1+ DDI3_PAIR1- DDI2_PAIR1- DDI3_HPD DDI2_HPD RSVD RSVD DDI3_PAIR2+ DDI2_PAIR2+ DDI3_PAIR2- DDI2_PAIR2- RSVD RSVD DDI3_PAIR3+ DDI2_PAIR3+ DDI3_PAIR3- DDI2_PAIR3- GND (FIXED) GND (FIXED) PEG_RX0+ PEG_TX0+ PEG_RX0- PEG_TX0- TYPE0# PEG_LANE_RV# PEG_RX1+ PEG_TX1+ www.gigaipc.com...
- Page 46 PEG_TX7+ PEG_RX7- PEG_TX7- RSVD RSVD PEG_RX8+ PEG_TX8+ PEG_RX8- PEG_TX8- GND (FIXED) GND (FIXED) PEG_RX9+ PEG_TX9+ PEG_RX9- PEG_TX9- RSVD RSVD PEG_RX10+ PEG_TX10+ PEG_RX10- PEG_TX10- PEG_RX11+ PEG_TX11+ PEG_RX11- PEG_TX11- GND (FIXED) GND (FIXED) PEG_RX12+ PEG_TX12+ PEG_RX12- PEG_TX12- PEG_RX13+ PEG_TX13+ PEG_RX13- PEG_TX13- www.gigaipc.com...
- Page 47 PEG_RX15+ D101 PEG_TX15+ C102 PEG_RX15- D102 PEG_TX15- C103 D103 C104 VCC_12V D104 VCC_12V C105 VCC_12V D105 VCC_12V C106 VCC_12V D106 VCC_12V C107 VCC_12V D107 VCC_12V C108 VCC_12V D108 VCC_12V C109 VCC_12V D109 VCC_12V C110 GND (FIXED) D110 GND (FIXED) www.gigaipc.com...
-
Page 48: Bkl_Cn (Backlight Control Header)
2.2.21 BKL_CN (Backlight Control header) Pin 1 Backlight control connector Connector PN Vendor 721-81-05TW00 PINREX Connector type 1x5pin header, pitch 2.0mm Pin No. Definition 12V (5V optional) PWM (3.3V) Backlight Enable (3.3V) www.gigaipc.com... -
Page 49: Lvds (Lvds Connector)
2.2.22 LVDS (LVDS connector) Pin 1 LVDS Connector Pin No. Definition Pin No. Definition CLK2p CLK1p CLK2n CLK1n Pin No. Definition Pin No. Definition 3.3V 3.3V Connector PN Vendor SPEC0 712-76-40GWE0 PINREX SPED0 A1252WV-SF-2X20PD01 JOINT-TECH Connector type 2x20pin header, pitch 1.25mm www.gigaipc.com... -
Page 50: Fp_Audio (Front Panel Audio Header)
2.2.23 FP_AUDIO (Front panel audio header) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX Connector type 2x5pin header, pitch 2.0mm Definition Pin Definition MIC_Left Jacksense Detect MIC_Right LINE_Left LINE_Right www.gigaipc.com... -
Page 51: Spkr (Speaker Out Connector)
2.2.24 SPKR (Speaker out connector) Pin 1 Speaker out Connector Connector PN Vendor A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com...
