How to distinguish the TOP and BOTTOM direction of the
CLR®/CLR®2/CLR3®/CLR® 4 materials
CORRECT DIRECTION
The material should have a white/gray color when viewed from an angle as shown below. This is how to distinguish
the correct direction of the REFLECTIVE LAYER positioned at the bottom of the material's microstructure.
TOP
Bottom
INCORRECT DIRECTION
If the material is black as shown below then it is upside down and is instead positioned to show the ABOSRBENT
LAYER.
Bottom
TOP
www.elitescreens.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR103H-CLR2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elite Screens AR103H-CLR2

Summary of Contents for Elite Screens AR103H-CLR2

  • Page 1 How to distinguish the TOP and BOTTOM direction of the CLR®/CLR®2/CLR3®/CLR® 4 materials CORRECT DIRECTION The material should have a white/gray color when viewed from an angle as shown below. This is how to distinguish the correct direction of the REFLECTIVE LAYER positioned at the bottom of the material’s microstructure. Bottom INCORRECT DIRECTION If the material is black as shown below then it is upside down and is instead positioned to show the ABOSRBENT...
  • Page 2 Examples of Correct and Incorrect direction with projection images Incorrect: Ceiling Light on Projection Correct: Ceiling Light on Projection image bright image not reflecting properly and not reflecting properly and absorbing light from above rejecting light from above Correct Correct Incorrect Ceiling Light on Close up comparison of Correct and incorrect direction.
  • Page 3 Example of screen hung up in the wrong direction with lights off. Projection may still look good but when Ceiling lights are turned on the image looks washed out. This is due to the material not absorbing overhead light. Ceiling Lights On Ceiling Lights Off www.elitescreens.com...
