2.3 12bit ADC and ROI

ATR2110C has built in 12bit ADC. It also has 12bit output mode for hardware binning and smaller resolution. The camera
also supports hardware ROI, and the smaller the ROI size is, the higher the frame rate is.
Table 2 shows the frame rate of ATR2110C in 12/8bit mode, USB3.0 / USB2.0 data transfer interface at different resolutions:
Table 2 ATR2110C Frame Rate at Different Resolution/Data Bit/Data Transfer (USB3.0/ USB2.0)
Resolution

2.4 DDR3 Buffer

The ATR2110C camera has a 512MB (4Gb) DDR3 buffer, which helps maintain the stability of data transmission, and
effectively reduce the amp-glow caused because image data can be temporarily buffered without being sent hastily to the
receiver.

2.5 Binning

ATR2110C supports digital binning from 11 to 88 in either stacking or averaging method, and hardware binning from 11
to 22 in averaging method. Hardware pixel binning is much faster than software binning.

2.6 Conversion Gain Switch

HCG
ATR2110C supports

2.7 Power and Cooling System for Precise Temperature Regulation

Please remember, the Camera can be powered only by DC12V 3A power source.
Figure 2 SC2110 QE Curve
Bit & Interface
FPS
1920*1200
40(HCG/HDR)
960*600
80(HCG/HDR)
LCG
HDR
,
and
mode switch.
12bit ADC
USB3.0
USB2.0
8(LCG)
85(LCG)
4(HCG/HDR)
240(LCG)
23(LCG)
8(HCG/HDR)
3
ATR2110C(ATR3CMOS02300KPA) User Manual
8bit ADC
USB 3.0
USB 2.0
120(LCG)
12(LCG)
40(HCG/HDR)
4(HCG/HDR)
240(LCG)
24(LCG)
80(HCG/HDR)
8(HCG/HDR)
