2 ATR2110C Specifications and Performance

2.1 Camera Specifications

Sensor
Diagonal
Image Resolution
Pixel Size
Image Area
Max FPS at Resolution (USB 3.0)
Max FPS at Resolution (USB 2.0)
Shutter Type
Exposure Time
Gain
SNR
Dynamic Range
Read Noise
QE Peak
Full Well
ADC
DDR3 Buffer
Connection Port
Camera Adaptor
Protect Windows
Spectral Range
Capture/Control SDK
Recording System
Camera Dimensions
Camera Weight
Back Focus Distance
Cooling:
Effective Cooling Temp:
Supported OS

2.2 SmartSens SC2110 QE Curve

The sensor G Sensitivity of ATR2110C is 120000 mV/Lux·s @HCG，10900 mV/Lux·s @LCG . Its QE Curve is shown in
Figure 2.
Table 1 ATR2110C Technique Specifications.
SmartSens SC2110 back illuminated sensor
27.4 mm
2.3 mega pixels (1920*1200)
12m  12m
23.2mm 14.6mm
12bit
85（LCG）/40（HCG)FPS@ 1920*1200
240（LCG）/80（HCG)FPS @ 960*600
12bit
8（LCG）/4（HCG) FPS @ 1920*1200
12（LCG）/4（HCG) FPS @ 960*600
Rolling shutter
0.1ms – 3600s
1x – 100x
50 dB
72 dB (Linear Mode)
5.01-0.4e-
>89%
17ke-
12bit
512MB (4Gb)
USB3.0/USB2.0
M42  0.75mm
IR-cut filter/AR-window
380-690nm (with IR-cut filter)
Windows/Linux/macOS/Android Multiple Platform SDK (Native C/C++, C#/VB.NET, Python, Java,
DirectShow, Twain, etc.);
Still picture and movie
Diameter 80mm * height 107.1mm
0.577kg
17.5mm
Two stage TEC
-35C below ambient under short exposure/ -42C under long exposure (> 1s)
®
Microsoft Windows® XP / Vista / 7 / 8 / 10 / 11 (32 & 64 bit)
OS x (Mac OS X)
Linux
2
ATR2110C(ATR3CMOS02300KPA) User Manual
8bit
120（LCG）/40（HCG)FPS @ 1920*1200
240（LCG）/80（HCG) FPS @ 960*600
8bit
12（LCG）/4（HCG) FPS @1920*1200
24（LCG）/8（HCG) FPS @ 960*600
