3 Product Package and Connections

3.1 Packing List

A Carton L:50cm W:30cm H:30cm (20pcs, 12~17Kg/ carton, 0.045m3), not shown in the photo
3-A safety equipment case: L:28cm W:23cm H:15cm (1pcs, 3.9Kg/ box); carton size: L:28.2cm W:16.7cm H:25.5cm (TBD), not shown in
B
the photo
C ATR series camera (M42x0.75 Mount+2" adapter)
D Power adapter: input: AC 100~240V 50Hz/60Hz, output: DC 12V 3.3A
E Power cable
F High-Speed USB3.0 A male to B male gold-plated connectors cable /1.5m
M48-M42 extender 0mm
G
M42M-M42F extender 21mm (TBD)
H
M48F - M42M extender 16.5mm (TBD)
I
M42M adapter 12.5mm
J
Cover
K
Figure 8 Packing Information of ATR2110C
Table 6 ATR2110C Packing List
Standard Package
12
ATR2110C(ATR3CMOS02300KPA) User Manual
