Installation -
Typical Installation
1a. Remove the rubber plugs from the camera's mounting holes
surface using the included anchors and screws
1b. To mount the camera directly onto the mounting surface without holes to pass the wires through, use the
cable guide plate to prevent damage to the cables.
b. Use four (4) mounting screws to mount the cable guide plate to the mounting surface.
c. Use two (2) mounting screws to secure the camera to the cable guide plate and mounting surface.
Camera base mounting
Waterproof cap installation:
The waterproof cap set comes with two rubber rings. Use the rubber ring best
sized for your network cable's diameter.
NOTE:
Cables with ø4.5mm to ø5.5mm thickness should use the black
rubber ring. Cables over ø5.5mm in thickness should use the white
rubber ring.
NOTE:
To ensure moisture seal, make sure the o-ring
between
c
and
e
rated sealer is recommended.
.
B
holes
. In extreme environments use of an outdoor
and attach the camera to the mounting
A
is in place
d
9
holes
Plate's mounting
