Icom ID-52E PLUS Basic Manual page 15

11 ENTER KEY [ENT]
Push to set the selected item or option.
12 DR • D-PAD (DOWN) KEY
[DR]/D-pad()
z Hold down for 1 second to turn the
DR function ON or OFF. (p. 14)
z In the DR screen, MENU screen, or
Quick Menu window, push to move
the option or value selector bar
down. (pp. 13, 21, 49)
13 QUICK MENU • SPEECH KEY
[QUICK]/[SPCH]
z Push to open the Quick Menu
window. (p. 13)
z Hold down for 1 second to audibly
announce the displayed frequency
and operating mode, or call sign.
(p. 17)
14 MEMORY • SELECT MEMORY WRITE
KEY [MR]/[MW]
z Push to enter the Memory mode.
(p. 14)
L For the ID-52A PLUS only
In the Memory mode, push once to
enter the Weather Channel mode.
z Hold down for 1 second to open the
Select Memory Write window.
(p. 23)
z Hold down for 3 second to enter the
Memory channel contents to a blank
channel.
15 VFO/MHz • CLEAR • CALL KEY
[VFO/MHz]/[CLR]/[CALL]
z Push to enter the VFO mode.
(p. 16)
z In the VFO mode, push to select 1
MHz tuning steps. (p. 16)
z In the MENU screen, push to select
an upper-tier menu. (p. 21)
z Push to delete an entered character.
(p. 46)
z Hold down for 1 second to enter the
Call Channel mode. (p. 14)
16 LO • D-PAD (RIGHT) KEY
[LO]/D-pad()
z Hold down for 1 second to open the
Select Output Power window.
(p. 19)
z In the MENU screen, push to select
a lower-tier menu. (p. 21)
PANEL DESCRIPTION
17 RX CALL SIGN CAPTURE • D-PAD
(UP) KEY [RX→CS]/D-pad()
z In the DR screen, MENU screen, or
Quick Menu window, push to move
the value or option selector bar up.
(pp. 13, 21, 49)
z Hold down for 1 second to capture the
calling stationʼs call sign. (p. 55)
18 VOLUME CONTROL [VOL]
Rotate to adjust the audio level.
(p. 7)
19 CONTROL DIAL [DIAL]
z Rotate to select an operating
frequency. (p. 16)
z In the Memory mode, rotate to select
a Memory channel.
z Rotate to select a setting item or
value.
z In the Character Entry mode, rotate
to enter characters.
20 EXTERNAL MICROPHONE •
SPEAKER JACK [MIC/SP]
Connect an optional speaker
microphone or headset.
(SP: 3.5 mm (1/8 inch), MIC: 2.5 mm)
L Confirm that the transceiver is OFF
before connecting or disconnecting
optional equipment.
21 USB PORT (Type-C) [USB]
Connects to an external power source,
a PC, or other USB device.
22 EXTERNAL DC IN JACK [DC IN]
Connects to an optional battery charger
to charge the attached battery pack.
