Digital SmartHandle AX PAS24

*M min.

19

M4x53

*M max.

20

M4x63

*L min.

21

M4x73

*L max.

22

M4x83

2× L2: door thickness + 8 mm (±3 mm)

23

24

*7 mm

25

Abbildungen/Images

8. Installing the fitting
