8. Installing the fitting
*SI-VCN
15
8. Installing the fitting
16
Size
S
S
M
M
L
L
*S min.
17
M4x33
*S max.
18
M4x43
8 / 52
PH2
Door thickness (mm)
38 – 50
49 – 60
59 – 70
69 – 80
79 – 90
89 – 100
Digital SmartHandle AX PAS24
TX15
Screws (M4)
33
43
53
63
73
83
Abbildungen/Images
